Cisco ESR-PRE2 Manual de usuario

Americas Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Quick Start Guide

Cisco Performance Routing Engine (ESR-PRE2)

Upgrade Installation

First Published: December 28, 2004

Last Updated: February 22, 2011

Document Revision History

The Document Revision History table below records technical changes to this document. The table

shows the document revision number for the change, the date of the change, and a brief summary of the

change. Note that not all Cisco documents use a Document Revision History table.

Contents

•Description, page 2

•Upgrading to a PRE2, page 2

•Troubleshooting, page 5

•Technical Specifications, page 6

•Related Documentation, page 6

•Obtaining Documentation and Submitting a Service Request, page 7

Revision Date Change Summary

OL-24535-01 February 22, 2011 Moved document to online only and updated format.

78-16710-01 December 28, 2004 Initial publication.

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Description

Warning

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

Caution Always wear a grounding wrist strap to avoid ESD damage to the module.

Description

The Cisco Performance Routing Engine (ESR-PRE2) is a single-slot module that performs Layer 2 and

Layer 3 packet routing and forwarding using Parallel eXpress Forwarding (PXF).

Upgrading to a PRE2

This upgrade should be performed by a qualified engineer who is familiar with the Cisco router console

interface.

Upgrade Considerations

•This is a service-impacting hardware upgrade. The router will not be available for user traffic during

the upgrade, and traffic cannot resume until the upgrade is complete.

•PREs or PRE1s cannot operate with a PRE2 in the same chassis and should never be installed in a

chassis together.

•PRE2 modules to be installed must have the helper image (eboot) stored in the onboard boot flash,

no configuration, and must be set to boot into ROMMON. Individual PRE2 modules ship in this

state.

•The new PRE2 image must exist on the TFTP server.

Saving the Startup and Running Configuration Information

When the PRE or PRE1 is removed from the chassis, any local configuration is lost. You must save your

configuration information to the TFTP server or media card before removing the module.

If you plan to use the media card from your current PRE or PRE1, you can save your startup

configuration, running configuration, and the latest PRE2 image (from the TFTP server) to the media

card.

Saving to a Media Card

Step 1 Connect the console to the primary PRE or PRE1.

Step 2 Copy the startup configuration and running configuration to the existing removable media card.

Step 3 Download the full PRE2 image from the TFTP server to the media card.

Step 4 If you have a redundant PRE or PRE1, save this information on the redundant PRE or PRE1 media card.

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Upgrading to a PRE2

Step 5 Remove the media cards from the modules and set them aside.

Saving to the TFTP Server

Step 1 Connect to the primary PRE or PRE1 console.

Step 2 Save the startup configuration and running configuration to the TFTP server.

Removing the PRE or PRE1 Module

Note Modules can be hot-swapped. However, removing a module terminates all traffic. We recommend that

you power down the router to ensure a successful installation.

Warning

Hazardous voltage or energy is present on the backplane when the system is operating. Use caution

when servicing.

Statement 1034

Step 1 Ensure that you are properly grounded.

Step 2 Power down the router

Step 3 Disconnect the cables from the PRE/PRE1.

Step 4 Unscrew the captive screws.

Step 5 Simultaneously pivot both ejector levers away from each other to disengage the module from the

backplane.

Step 6 Slide the PRE/PRE1 out of the slot and place it on an anti-static surface or in an anti-static bag.

Step 7 If you are replacing a redundant PRE/PRE1, repeat Step 3 through Step 6.

Installing a PRE2 Module

Note To ensure proper operation, always install a single PRE2 in slot A. If you are installing a redundant PRE2

in slot B, wait until after you have installed and configured the primary PRE2 in slot A.

Equipment

ESD wrist strap

Replacement PRE2 modules

Step 1 Ensure that you are properly grounded.

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Upgrading to a PRE2

Step 2 Inspect the connectors on both the PRE2 and the backplane. Bent or broken pins can cause a system

malfunction.

Step 3 Carefully align the PRE2 module with the guides in slot A in the chassis.

Step 4 Slide the module into the slot until you can feel it seat in the backplane.

Figure 1 Cisco uBR10012 Router

Figure 2 Cisco ESR10000 Router

Step 5 Simultaneously close the ejector levers to firmly seat the PRE2 in the backplane.

Step 6 Tighten the captive screws.

Step 7 Reconnect all the cables to the PRE2 and connect to the console.

Step 8 If you saved files to the old media card, replace the new media card with the old media card.

Step 9 Power on the router. The PRE2 cycles through its power-on self-test. The FAIL LED stays on briefly,

goes off, and then boots into ROMMON mode.

Step 10 Boot the full image (if available) from the media card or from the TFTP server.

If the full image is not available, boot the helper image from the onboard boot flash. After

booting the router prompts for an initial configuration dialog.

122201

ALARMS

CISCO

10000

FAIL

PERFORMANCEROUTING ENGINE

CONSOLE

STATUS

ACO

CRITICAL

MINOR

MAJOR

ETHERNE

LINK

ACTIVITY

AUX

SLOT0

SLOT1

PERFORMANCEROUTING ENGINE

CISCO

10000

CONSOLE

ETHERNET

LINK

ACTIVITY

AUX

PERFORMANCEROUTING ENGINE

ESR-PRE2

ALARMS

FAIL

STATUS

ACO

CRITICAL

MINOR

MAJOR

SLOT

POWER

MISWIRE

FAULT

POWER

MISWIRE

FAULT

CISCO

10000

CONSOLE

ETHERNET

LINK

ACTIVITY

AUX

PERFORMANCEROUTING ENGINE

ESR-PRE2

ALARMS

FAIL

STATUS

ACO

CRITICAL

MINOR

MAJOR

SLOT

122202

240A

PROCESSORONLY

0B 5678

PROCESSORONLY

POWER

FAULT

MISWIRE

POWER

FAULT

MISWIRE

CISCO

10000

LINK

FAIL

GIGABITETHERNET

CISCO

10000

CARRIER

ALARM

LOOP

FAIL

CHOC-12-DSO SM-IR

CISCO

10000

CARRIER

ALARM

LOOP

FAIL

6XCT3–DS0

CISCO

10000

CARRIER

ALARM

LOOP

FAIL

6XCT3–DS0

FAIL

PERFORMANCEROUTING ENGINE

CONSOLE

STATUS

ACO

CRITICAL

MINOR

MAJOR

ETHERNET

LINK

ACTIVITY

AUX

SLOT0

SLOT1

CISCO

10000

FAIL

PERFORMANCEROUTING ENGINE

CONSOLE

STATUS

ACO

CRITICAL

MINOR

MAJOR

ETHERNET

LINK

ACTIVITY

AUX

SLOT0

SLOT1

CISCO

10000 CISCO

10000

CARRIER

ALARM

LOOP

FAIL

6XCT3–DS0

CISCO

10000

CARRIER

ALARM

LOOP

FAIL

6XCT3–DS0

CISCO

10000

CARRIER

ALARM

LOOP

FAIL

6XCT3–DS0

CISCO

10000

CARRIER

FAIL

OC–12/STM–4POS SM–IR

FANS

FAN

FAILURE

MULTI-

FAN

FAILURE

When hot swappingthis fan tray,

removaland replacement must

be done in under twominutes or

system shutdownwill occur.

CAUTION

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Troubleshooting

Step 11 If you need to access the TFTP server to obtain the full image or the saved configuration files, enter the

configuration dialog and provide the information necessary to access the TFTP server.

If you booted the full image, restore the startup configuration and running configuration

information, and set the boot variable for the new image. The upgrade is now complete.

If you booted from the helper image, download the full image, restore the startup and running

configuration information, set the boot variable to the new image, and reload the router. The

upgrade is now complete.

Installing a Redundant PRE2

Step 1 Repeat Step 1 through Step 8 for slot B.

Step 2 From the console ROMMON prompt, set the configuration to boot the full image and reload.

Troubleshooting

The PRE2 goes through a specific LED sequence at startup.

1. The FAIL LED briefly comes on and then goes off, and the STATUS LED starts flashing and

progress messages appear on the PRE2 display.

2. IOS RUN appears after a successful bootup.

3. The STATUS LED on the PRE2 turns green.

4. The redundant PRE2 boot sequence is similar, except that the STATUS LED remains off and the

final message is IOS STBY, indicating that the PRE2 is in standby state.

If this sequence does not occur, the STATUS LED is off, or the FAIL LED is yellow, check the following:

1. Are the LEDs on other modules on? If not, check for a problem in the power subsystem.

2. If other module’s LEDs are on, remove the PRE2 from the slot, check for bent or broken pins on the

connectors, and reinsert it. Ensure that there is solid contact with the backplane and that the PRE2

is securely locked in place.

3. Verify the status of the PRE2 module’s internal Ethernet interface (ethernet0/0/0). If this internal

interface is down, it could indicate that the PRE2 is not fully seated in the slot or that a hardware

failure has occurred. Do not confuse the PRE2 internal Ethernet interface (ethernet 0/0/0) with the

module’s external Fast Ethernet interface (fastethernet 0/0/0), which is used for network

management and remote access.

Table 1 provides LED status details for PRE2.

Table 1 LED and Switch Description

LEDs/Switch Description

ACTIVITY

Green/Off

Packets are being transmitted and received

No packet activity

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Technical Specifications

Table 2 lists technical specifications for PRE2.

Ta b l e 2 Te c h n i c a l S p e c i f i c a t i o n s

Related Documentation

Cisco uBR10012 Universal Broadband Router Performance Routing Engine Module

http://www.cisco.com/en/US/docs/interfaces_modules/cable/performance_routing_engine/installation/

guide/pre5096.html

Cisco uBR10012 Router Release Notes

http://www.cisco.com/en/US/products/hw/cable/ps2209/prod_release_notes_list.html

Regulatory Compliance and Safety Information for the Cisco uBR10012 Universal Broadband Router

http://www.cisco.com/en/US/docs/cable/cmts/ubr10012/regulatory/compliance/ub10rcsi.html

LINK

Green/Off

Carrier detected; passing traffic

No carrier detected; not passing traffic

CRITICAL

MAJOR

MINOR

Off/Yellow

No alarm

Alarm condition

STATUS

Green/Off

PRE2 is ready.

No power to the PRE2, or it is acting as the redundant PRE2

FAIL

Off/Yellow

PRE2 is operating properly

PRE2 disabled by major failure

PCMCIA slot 0 Flash card in Slot 0 is active

PCMCIA slot 1 Flash card in Slot 1 is active

ACO1switch Disables the audible alarm

1. Alarm cutoff switch

Table 1 LED and Switch Description (continued)

LEDs/Switch Description

Description Specification

PRE2

PRE2 spare

ESR-PRE2/R

ESR-PRE2=

Weight 8.45 lb (3.84 kg)

Power consumption per module 200 Watts

(682.4 btu per hour)

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Obtaining Documentation and Submitting a Service Request

For information on obtaining documentation, submitting a service request, and gathering additional

information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and

revised Cisco technical documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Subscribe to the What’s New in Cisco Product Documentation as an RSS feed and set content to be

delivered directly to your desktop using a reader application. The RSS feeds are a free service. Cisco currently

supports RSS Version 2.0.

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of

Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The

use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)

Cisco Performance Routing Engine (ESR-PRE2) Upgrade Installation

OL-24535-01

Obtaining Documentation and Submitting a Service Request

Tabla de contenidos

Otros manuales de Hardware de red de Cisco

Cisco

Cisco Firepower 4100 Series Manual de usuario

Cisco

Cisco MGX 8260 Guía de inicio rápido

Cisco

Cisco ISA550 Manual de instrucciones

Cisco

Cisco Firepower 1010 FPR1010-NGFW-K9 Manual

Cisco

Cisco NAC3350-PROF-K9 - NAC Profiler Server Manual de usuario

Cisco

Cisco ATM Cable Interface Processor ACIP-SM(=) Manual del operador

Cisco

Cisco MXE 3000 Manual

Cisco

Cisco Cisco ONS 15600 SDH Manual de usuario

Cisco

Cisco NCS 2006 Manual

Cisco

Cisco NCS 4201 Manual

Cisco

Cisco Cisco ASA Series Manual de usuario

Cisco

Cisco NTP-E157 Manual de lista de piezas

Cisco

Cisco GS7000 Instrucciones de funcionamiento

Cisco

Cisco ONS 15327 Manual

Cisco

Cisco ONS 15454 SDH Manual

Cisco

Cisco CGR 1000 Series Manual de usuario

Cisco

Cisco 5500 Series Manual de usuario

Cisco

Cisco NCS 1010 Hoja de instrucciones

Cisco

Cisco ASA Guía de inicio rápido

Cisco

Cisco Linksys Business Series Network Storage System... Manual de usuario

Cisco

Cisco IAD2430 Series Guía de instalación

Cisco

Cisco RSP4+ Bootflash Memory Upgrade to 16MB... Manual del operador

Cisco

Cisco 2600 Series Documento técnico

Cisco

Cisco SA-VAM - VPN Acceleration Module Manual del operador

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
