Americas Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Installing Online Help for Cisco Unified

Videoconferencing 3500 Products (Release 5.x)

Revised Date: January 10, 2008, OL-12052-03

Contents

•Introduction, page 1

•Installing Cisco Unified Videoconferencing 3515 MCU Online Help Files, page 2

•Installing Cisco Unified Videoconferencing 3545 MCU Online Help Files, page 3

•Installing Cisco Unified Videoconferencing 3527 PRI Gateway Online Help Files, page 4

•Installing Cisco Unified Videoconferencing 3545 PRI Gateway Online Help Files, page 5

•Installing Cisco Unified Videoconferencing 3522 BRI Gateway Online Help Files, page 6

•Installing Cisco Unified Videoconferencing 3545 Serial Gateway Online Help Files, page 7

•Netscape Navigator Users, page 7

•Obtaining Documentation, Obtaining Support, and Security Guidelines, page 8

Introduction

The Cisco Unified Video Conferencing 3500 Series Utilities and Documentation CD-ROM contains the

online help files for Cisco Unified Videoconferencing 3500 Products.

This document describes how to install the online help files for each of these products.

To use the online help, you can place the help files in a shared directory either on a computer in your

network or on your PC.

In both cases, you register the directory location in the Administrator interface.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3515 MCU Online Help Files

Installing Cisco Unified Videoconferencing 3515 MCU Online

Help Files

The 3515mcu\mcu folder contains the online help files for the Cisco Unified Videoconferencing 3515

MCU12 and Cisco Unified Videoconferencing 3515 MCU24.

To install the online help in a Cisco Unified Videoconferencing 3515 MCU, follow the procedure below.

Procedure

Step 1 Copy the mcu folder to a HTTP server on your network that the Cisco Unified Videoconferencing 3515

MCU can access

–or–

Copy the mcu folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3515 MCU that you want to

access the online help.

Step 3 On the sidebar, click Device.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the mcu folder as follows:

http://.../3515mcu/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the mcu

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3515mcu

Step 7 Click Upload in the Cisco Unified Videoconferencing 3515 MCU Administrator toolbar, followed by

Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3515 MCU

Administrator for the change to take effect.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3545 MCU Online Help Files

Installing Cisco Unified Videoconferencing 3545 MCU Online

Help Files

The 3545mcu\mcu folder contains the online help files for the Cisco Unified Videoconferencing 3545

MCU.

To install the online help in a Cisco Unified Videoconferencing 3545 MCU, follow the procedure below.

Procedure

Step 1 Copy the mcu folder to a HTTP server on your network that the Cisco Unified Videoconferencing 3545

MCU can access

–or–

Copy the mcu folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3545 MCU that you want to

access the online help.

Step 3 On the sidebar, click Board.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the mcu folder as follows:

http://.../3545mcu/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the mcu

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3545mcu

Step 7 Click Upload in the Cisco Unified Videoconferencing 3545 MCU Administrator toolbar, followed by

Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3545 MCU

Administrator for the change to take effect.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3527 PRI Gateway Online Help Files

Installing Cisco Unified Videoconferencing 3527 PRI Gateway

Online Help Files

The 3527gw1p\gw folder contains the online help files for the Cisco Unified

Videoconferencing 3527 PRI Gateway.

To install the online help in a Cisco Unified Videoconferencing 3527 PRI Gateway, follow the

procedure below.

Procedure

Step 1 Copy the gw folder to a HTTP server on your network that the Cisco Unified

Videoconferencing 3527 PRI Gateway can access

–or–

Copy the gw folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3527 PRI Gateway that you

want to access the online help.

Step 3 On the sidebar, click Device.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the gw folder as follows:

http://.../3527gw1p/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the gw

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3527gw1p

Step 7 Click Upload in the Cisco Unified Videoconferencing 3527 PRI Gateway Administrator toolbar,

followed by Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3527 PRI Gateway

Administrator for the change to take effect.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3545 PRI Gateway Online Help Files

Installing Cisco Unified Videoconferencing 3545 PRI Gateway

Online Help Files

The 3545gw2p\gw folder contains the online help files for the Cisco Unified

Videoconferencing 3545 PRI Gateway Module.

To install the online help in a Cisco Unified Videoconferencing 3545 PRI Gateway Module, follow the

procedure below.

Procedure

Step 1 Copy the gw folder to a HTTP server on your network that the Cisco Unified

Videoconferencing 3545 PRI Gateway can access

–or–

Copy the gw folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3545 PRI Gateway that you

want to access the online help.

Step 3 On the sidebar, click Board.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the gw folder as follows:

http://.../3545gw2p/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the gw

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3545gw2p

Step 7 Click Upload in the Cisco Unified Videoconferencing 3545 PRI Gateway Administrator toolbar,

followed by Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3545 PRI Gateway

Administrator for the change to take effect.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3522 BRI Gateway Online Help Files

Installing Cisco Unified Videoconferencing 3522 BRI Gateway

Online Help Files

The 3522gw4b\gw folder contains the online help files for the Cisco Unified

Videoconferencing 3522 BRI Gateway.

To install the online help in a Cisco Unified Videoconferencing 3522 BRI Gateway, follow the

procedure below.

Procedure

Step 1 Copy the gw folder to a HTTP server on your network that the Cisco Unified

Videoconferencing 3522 BRI Gateway can access

–or–

Copy the gw folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3522 BRI Gateway that you

want to access the online help.

Step 3 On the sidebar, click Device.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the gw folder as follows:

http://.../3522gw4b/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the gw

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3522gw4b

Step 7 Click Upload in the Cisco Unified Videoconferencing 3522 BRI Gateway Administrator toolbar,

followed by Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3522 BRI Gateway

Administrator for the change to take effect.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Installing Cisco Unified Videoconferencing 3545 Serial Gateway Online Help Files

Installing Cisco Unified

Videoconferencing 3545 Serial Gateway Online Help Files

The 3545gw4s folder contains the online help files for the Cisco Unified

Videoconferencing 3545 Serial Gateway Module.

To install the online help in a Cisco Unified Videoconferencing 3545 Serial Gateway Module, follow the

procedure below.

Procedure

Step 1 Copy the gw folder to a HTTP server on your network that the Cisco Unified

Videoconferencing 3545 Serial Gateway can access

–or–

Copy the gw folder to a shared directory on your PC.

For example, C:/Program Files/OnlineHelp/ where OnlineHelp is a shared directory.

Step 2 Launch the Administrator interface of the Cisco Unified Videoconferencing 3545 Serial Gateway that

you want to access the online help.

Step 3 On the sidebar, click Board.

Step 4 Click the Web tab.

Step 5 If you have copied the help files to a network location:

In the Online Help URL field, paste the URL where the online help is located up to, but not including,

the gw folder as follows:

http://.../3545gw4s/

Step 6 If you have copied the help files to a shared location on your PC:

In the Online Help URL field, paste the URL to the online help files up to, but not including, the gw

folder as follows:

file://computerName/sharedDirectory

where computerName is the name of your computer and sharedDirectory is the path to, but not including,

the mcu folder on the CD-ROM.

For example, file://myComputer/OnlineHelp/3545gw4s

Step 7 Click Upload in the Cisco Unified Videoconferencing 3545 Serial Gateway Administrator toolbar,

followed by Refresh.

Step 8 You may need to log out and log back in to the Cisco Unified Videoconferencing 3545 Serial Gateway

Administrator for the change to take effect.

Netscape Navigator Users

Online help files located on the local network and accessed using Netscape Navigator 4.x must be

located on a mapped network drive.

Installing Online Help for Cisco Unified Videoconferencing 3500 Products (Release 5.x)

OL-12052-03

Obtaining Documentation, Obtaining Support, and Security Guidelines

Obtaining Documentation, Obtaining Support, and Security

Guidelines

For information on obtaining documentation, obtaining support, providing documentation feedback,

security guidelines, and also recommended aliases and general Cisco documents, see the monthly

What's New in Cisco Product Documentation, which also lists all new and revised Cisco technical

documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and

figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and

coincidental.

CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is

a service mark of Cisco Systems, Inc.; and Access Registrar, Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco

Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity,

Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS,

iPhone, IP/TV, iQ Expertise, the iQ logo, iQ Net Readiness Scorecard, iQuick Study, LightStream, Linksys, MeetingPlace, MGX, Networkers,

Networking Academy, Network Registrar, PIX, ProConnect, ScriptShare, SMARTnet, StackWise, The Fastest Way to Increase Your Internet Quotient,

and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.

All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a

partnership relationship between Cisco and any other company. (0711R)

Otros manuales para Aironet 3500 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de conferencias de Cisco

Cisco

Cisco Webex Room Kit Mini Manual de usuario

Cisco

Cisco TelePresence System 1100 Manual de usuario

Cisco

Cisco TelePresence SpeakerTrack 60 Manual de usuario

Cisco

Cisco EX60 Manual de usuario

Cisco

Cisco TelePresence Profile 55 Manual de usuario

Cisco

Cisco TelePresence MXP Series Manual de servicio

Cisco

Cisco Webex Room 70 Panorama Manual de usuario

Cisco

Cisco Quick Set C20 Manual de usuario

Cisco

Cisco TelePresence SX10 Manual de usuario

Cisco

Cisco Webex Room 70 Dual Manual de usuario

Cisco

Cisco TelePresence SX20 Instrucciones originales

Cisco

Cisco TelePresence Profile Series Manual de usuario

Cisco

Cisco TelePresence IX5000 Manual

Cisco

Cisco TelePresence DX70 Manual de usuario

Cisco

Cisco TelePresence IX5000 Guía de configuración

Cisco

Cisco MX200 G2 Manual de usuario

Cisco

Cisco TelePresence SX10 Manual de usuario

Cisco

Cisco Spark Room Kit Plus Manual de usuario

Cisco

Cisco TelePresence MX Series Manual de servicio

Cisco

Cisco TelePresence SX20 Manual de servicio

Cisco

Cisco TelePresence System Codec C40 Manual de servicio

Cisco

Cisco TelePresence SpeakerTrack 60 Manual de usuario

Cisco

Cisco Codec C Series Manual de usuario

Cisco

Cisco Profile Series Manual de usuario

Manuales populares de Sistema de conferencias de otras marcas

Kramer

Kramer VIA GO Manual de usuario

AVT

AVT MAGIC AC1 Go Manual de usuario

ProSoft Technology

ProSoft Technology AN-X4-AB-DHRIO Manual de usuario

Sony

Sony PCS-I150 Manual de usuario

Middle Atlantic Products

Middle Atlantic Products VTC Series Manual de usuario

Prentke Romich Company

Prentke Romich Company Vanguard Plus Guía

Speakerbus

Speakerbus iD 712 Manual de usuario

Trelleborg

Trelleborg SafePilot CAT PRO Manual de usuario

Sennheiser

Sennheiser ADN Manual de usuario

ADTRAN

ADTRAN NetVanta 7100 Manual de usuario

AINA

AINA PTT Voice Responder Manual de usuario

Yamaha

Yamaha ProjectPhone PJP-100H Manual de usuario

vissonic

vissonic VLI Series Manual de usuario

Panasonic

Panasonic KX-VC500 Manual de usuario

Poly

Poly Trio 8300 Manual de usuario

Crestron

Crestron Mercury CCS-UCA-SMK Dibujo dimensional

Inmarsat

Inmarsat mini M Manual de usuario

Tenveo

Tenveo ALL-IN-ONE Manual de usuario
