1.0. GENERAL
The hot water boiler CentroPlus has a modern design and construction. It is made out of controlled
high-quality materials, welded with the most modern technology and meets all special requirements for
connection to the central heating system.
1.1. BOILER DESCRIPTION
Steel hot water boiler CentroPlus has two separate combustion chambers inside the common boiler's
water chamber. The left combustion chamber is intended for firing with solid or liquid fuel. It has a large
heating area and small resistance, and large door which enables simple heating with big-size fuel. The
right combustion chamber is intended for firing with wooden pellets or liquid fuel and it is characterised
by 3-passes flue gas system with turbolators and large heating area which provides high boiler
efficiency. A large amount of water in the boiler enables longer pellet burner work (in that way it is
reduced the number of switching on the burner and extends the burner life time). The boiler cleaning is
very simply and can be done from the front or back side. Depending on the installed additional
equipment, there are three models of boiler use:
- solid fuel firing,
- solid fuel and wooden pellets firing,
- solid fuel and EL fuel oil firing.
The boiler is supplied without above mentioned additional equipment, which can be additionaly
ordered. The additional equipment is delivered in a separate packing and it is installed onto the boiler
after the boiler is istalled into the boiler room and connected to the central heating system.
1.2. DELIVERY OF THE BOILER CentroPlus
Due to easier transport and positioning into the boiler room, the boiler CentroPlus is not delivered with
built-in thermal insulation and casing (it is delivered separately):
- the boiler body with boiler door is delivered on a wooden pallet (with lid of the left firebox door,
lid of the right firebox register, ashtrays, left and right firebox grates and turbulators);
- the cardboard box with boiler casing, thermal insulation, themometer, draft controller ( such
as CALEFFI 543 or ESBE ATA200), back ash box, cleaning accessories (accessories holder,
brush, scraper and poker), protective box for extension for the pellet burner and set of screws
and bolts.
1.3. OBLIGATORY ADDITIONAL EQUIPMENT FOR THE BOILER CentroPlus
WHICH IS INSTALLED TO CLOSED CENTRAL HEATING SYSTEM
CentroPlus 25/35:
- thermal valve (such as CALEFFI 543) -1 piece
CentroPlus 50:
- thermal valve (such as CALEFFI 543) -2 pieces
- thermal protection exchanger Centrometal - 2 pieces
