Centrometal STB 200 Manual del propietario

TECHNICAL INSTRUCTIONS

Installation, use and maintenance

of solar water heater

TU-STB-02-2022-ENG

STB 200 - 850

HEATING TECHNIQUE

Centrometal d.o.o. - Glavna 12, 40306 Macinec, Croatia, tel: +385 40 372 600, fax: +385 40 372 611

ENG

Basic parts technical data,

1. Cold domestic water inlet

2. Hot domestic water outlet

3. Recirculation

4. Top (boiler) heat exchanger

5. Bottom (solar) heat exchanger

6. Opening for cleaning

7. Temperature sensor sleeve – heating with

boiler

8. Temperature sensor sleeve – solar heating

9. Thermometar

Picture 1. - STB - Basic parts

TECHNICAL DATA

2Technical instructions STB

*¹ Internal thread

*² External thread to ermeto fitting Ø 22-3/4" for STB-200 and Ø 28-1" for STB-300, STB-600 and STB-850

STB 200

Volume

Height C

Boiler diameter Ø A

Diameter without insulation

Depth B

Heat exchanger

Rated thermal output 80°C

70°C

60°C

Heating fluid flow

Heat exchanger surface

Cold domestic water inlet*¹

Hot domestic water outlet*¹

Recirculation*¹

Heat exchanger*²

Maximum working pressure

Mass

(l)

(mm)

(kW)

(l/h)

(kW)

(l/h)

(kW)

(l/h)

(m³/h)

(m²)

(R")

(kg)

300 850600

(1)

top

16,1

395

13,3

325

8,0

195

1,5

0,42

3/4

6 / 0,6

bottom

33,1

814

26,7

658

16,5

406

1,5

0,83

top

19,5

479

16,0

391

10,1

391

0,53

3/4

6 / 0,6

bottom

37,4

916

28,5

697

18,1

443

1,5

1,06

top

37,6

922

28,9

707

18,4

450

1,06

5/4

3/4

6 / 0,6

125

bottom

63,7

1561

49,7

1216

32,5

796

1,5

2,12

top

53,1

1299

40,7

997

26,4

646

1,59

5/4

3/4

6 / 0,6

162

bottom

83,8

2053

66,3

1624

44,5

1090

1,5

3,17

198

1420

640

480

690

283

1900

640

480

690

537

1995

810

650

860

850

1940

960

800

1000

(bar/MPa)

Technical data

Slika 2. Solar domestic hot water heater dimensions

ØA

295

695

775

855

1055

1145

295

865

965

1065

1345

1645

330

985

1085

1185

1585

1725

Height D

Height E

Height F

Height G

Height H

Height I

Height J

(mm)

STB

200

STB

300

STB

600

320

1075

1375

1270

1540

1635

STB

850

Technical instructions STB

Introduction, purpose

1.0. INTRODUCTION

The solar domestic hot water heater STB, by company Centrometal d.o.o., is produced with latest

welding technology, made from quality materials, which ensures high efficiency and the overall product

quality. It is made of stainless steel (INOX) and tested under air pressure of 12 bars. It has two stainless

steel coil heat exchangers. It is delivered factory insulated by 80mm of foam covered with PS jacket.

The technical manual provides information regarding construction, operation, installation and

maintenance, so following to this manual will ensure economic and undisturbed heater operation.

2.0. PURPOSE

Solar water heater is intended for production of the domestic hot water in households, restaurants,

hotels and other area where larger water amount is needed.

The advantage of STB is in using the different energy sources (sun, oil, gas, solid fuel, electrical...),

possibility of producing larger DHW amount, racional consumption of energy sources (oil, gas, solid

fuel, el. energy), excellent insulation and modern effecient construction, which combined results in

lower costs of energy input per produced DHW unit.

Solar heating circuit is connected to the bottom heat exchanger and boiler heating circuit is connected

to the top heat exchangers.

500

1000

2000

3000

4000

5000

6000

7000

Heating fluid flow in kg/h

BOTTOM HEAT EXCHANGER

Heating fluid pressure drop

500

1000

2000

3000

4000

5000

6000

7000

0,001

0,002

0,003

0,004

0,005

0,006

0,007

0,008

0,009

0,01

0,02

0,03

0,04

0,05

Heating fluid flow in kg/h

Pressure drop in MPa

TOP HEAT EXCHANGER

Heating fluid pressure drop

0,001

0,002

0,003

0,004

0,005

0,006

0,007

0,008

0,009

0,01

0,02

0,03

0,04

0,05

Pressure drop in Mpa

HEAT EXCHANGER PRESSURE DROP FOR STB 200, 300, 600, 850

200

300

600

850

4Technical instructions STB

Montage, connection to a water supply

4.0. CONNECTION TO A WATER SUPPLY

The water heater connection to a water supply system must be done with accordance with valid

technical standards by a qualified person (Scheme 1). The cold water inlet is the lowest connection on

the heater, marked with a blue rosette, and the hot water outlet is the highest connection, marked with a

red rosette.

On the cold water inlet is obligatory to install following elements:

- domestic hot water expansion vessel

- water heater drain cock (obligatory install it with the T-piece)

- the safety valve (certified to open at 6 bar)

- check valve

- pressure reduction valve to decrease a cold water inlet pressure to the 4 bar (if the pressure is

higher).

The safety valve must be regulary conterolled, limescale must be removed becauce it can block the

flow to the safety valve. The safety valve outlet must be installed in barometric pressure enviroment that

never freezes.

In order to have a longer operation life it is recommend to install a water softener, especially if the heater

is connected to a municipal water supply system (hard water and water with chlorine), and if galvanized

water tubes are used, which can harm stainless steel materials. Recirculation connection is placed

between the top and bottom heat exchanger, marked with red rosette.

A thermostatic 3-way valve and recirculation pump installation must be done upon one of two ways,

depending on the purpose or position of taps.

Scheme 2. shows the recirculation pump installation in the system with two or more thermostatic 3-way

valves. Different temperature can be set for certain group of taps that are placed after the thermostatic

3-way valve. Smaller valve can be selected depending on the number of taps.

Scheme 3. shows the thermostatic 3-way valve installation for all taps, right on the heater hot water

outlet. If even one of the shown elements in the scheme is missing, the recirculation will not work

properly.

The schemes 2. And 3. do not show required elements for connection to the municipal water supply

system, but those elements must be installed as it is shown in Scheme 1.

3.0. MONTAGE

The water heater is factory insulated, with thermometer and ermeto fittings on heat exchanger

connections, and it is delivered on the palette. If it cannot pass through a door, insulation can be taken

off and put on in the room afterwads.

STB is intended for mounting on the flat surface in the room for such application (boiler room, energy

station,…).

Technical instructions STB

Connection to a water supply

Scheme 1. Connection to the municipal water supply system

45 6 7

SOLAR DOMESTIC

COLD WATER (ENTRANCE)

1 - Solar domestic hot water heater STB

2 - Domestic hot water expansion vessel

3 - Drain cock (T-piece must be used)

4 - Safety valve (6bar)

5 - Check valve

6 - Pressure reduction valve

7 - Shut-off valve

it is required to install if the water supply pressure

is higher than 4bars

Legend

SOLAR DOMESTIC

HOT WATER

Scheme 2. Recirculation pump installation to the system

with two or more thermostatic 3-way mixing

valves

Scheme 3. Thermostatic 3-way mixing valve

installation for all taps, right on the heater

hot water outlet, with recirculation pump

1 – water heater

2 – thermostatic 3-way mixing valve

3 – check valve

4 – recirculation pump

5 – shut-off valve

Legend

6Technical instructions STB

Connection to the solar and boiler installation

Schema 4. - example of connection to the solar and boiler installation

On scheme 4. is shown an example of solar domestic hot water heater to the solar and boiler heating

circuit. Connections on the heat exchangers are marked with rosettes (red ones on the inlets and blue

ones on the outlets). Connection must be done with ermeto fittings that are factory mounted at the heat

exchanger ends. Before commissioning, air-vent must be done in both systems (solar and boiler).

5.0. CONNECTION TO THE SOLAR AND BOILER INSTALLATION

bar

- solar collector (CPK 7210N, CVSKC-10)

- flat or slope roof collector mounting set

- solar boiler STB

- solar pump group CSPG-TL6600

- solar expansion vessel

- solar air-vent with shut-off valve

- DHW thermostatic 3-way mixing valve

- boiler (EKO-CUP, EKO-CK, El-Cm)

- collector temperature sensor

- boiler temperature sensor

- Cm Sol

- collector return flow

temperature sensor

bar

°C

912

Technical instructions STB

As required (depending on the water quality) the hot water heater has to be checked and cleaned from

limescale and the sediment. The opening for cleaning is placed on the lower part of the hot water heater,

at the front, behind the a plastic cover. It is recommended that the cleaning and servicing is carried out

by an authorised technician.

Warranty rights are described in the warranty. Failures and damages of the heater should be reported to

an authorized Centrometal service at the telephone number: +385 (0) 40 372 622

6.0. MAINTENANCE, CLEANING, WARRANTY AND SERVICE

Maintenance, cleaning, warranty and service

8Technical instructions STB

Declaration of conformity

Technical instructions STB

10 Technical instructions STB

Notes
