Casio Cassiopeia IT-2000 Manual de usuario

IT-2000

I/O Box Installation

Manual

(Version 1.00 )

April 1998

Casio Computer Co., Ltd.

Table of Contents

Chapter1Overview 3

Chapter2System Configuration and Installation Method 4

2.1 Options and Software 4

2.2 System Configuration 5

2.2.1 With Single I/O Box 5

2.2.2 With Multiple I/O Boxes 5

2.2.3 With Single Master I/O Box 6

2.2.4 With Multiple Master I/O Boxes 6

2.2.5 With Master and Satellite I/O Boxes 7

2.3 Installation Method 8

2.3.1 Setup of Satellite I/O Box 9

2.3.2 Setup of Master I/O Box 11

2.3.3 Setup of Satellite I/O Box to Master I/O Box 12

2.3.4 Setup of PC 13

Chapter3Operation Method 15

3.1 File Upload 15

3.1.1 Specifying Files from PC 15

3.1.2 Specifying Files from IT-2000 17

3.2 File Download 19

3.2.1 Specifying Files from PC 19

3.2.2 Specifying Files from IT-2000 21

Chapter4Error Codes and Error Messages 23

Chapter5Q and A 26

Chapter6Reference Manuals 29

Chapter7List of SCSI Boards and SCSI Cables 30

Appendix Installation Method of Upload/Download Utility 31

1. Overview

This system performs file transfer and other operations between the Casio Data Collection Terminal

IT-2000 (hereinafter referred to as this terminal or IT-2000) and an AT architecture-based personal

computer (hereinafter referred to as PC or Host PC) via the I/O Box.

Functions provided in this system ;



File upload from IT-2000 to PC



File download from PC to IT-2000



Deletion of files in IT-2000



Setup of system date on IT-2000



Move and rename file within IT-2000



Character string display on IT-2000



Acquisition of IT-2000 drive information



Acquisition and setup of IT-2000 file information

For data transfer between IT-2000 and PC, refer to the IT-2000 Upload/Download Utility Manual.

The great advantage of this system lies in its wide range of system configurations which can allow

the combined connection of PC and two different kinds of I/O Boxes (Master I/O Box and Satellite

I/O Box).

(1) The I/O Box is available in two types: the Master I/O Box and the Satellite I/O Box.

(2) The Master I/O Box can only be connected to a PC via SCSI interface.

Each Master I/O Box (seven Boxes max. in one system) connected to a PC can have maximum

of seven Satellite I/O Boxes connected under daisy-chain.

(3) The following connection can be made with the Satellite I/O Box.



Direct connection with PC via the RS-232C interface.



The Satellite I/O Box connected directly to the PC can have a maximum of seven Satellite

I/O Boxes connected under daisy-chain.



The Master I/O Box can have a maximum of seven Satellite I/O Boxes connected under

daisy-chain.

2. System Configuration and Installation Method

2.1 Options and Software

Category Name Model Remark

Hardware

Satellite I/O Box

Master I/O Box

RS-232C cable

RS-422 cable

SCSI cable

IT-2060IOE

IT-2065IOE

DT-887AX

DT-888RSC

DT-751HF

DT-752HH

DT-753HP

Connector shape: Cross-type 9-pin, female

Connector shape: Modular cable for chaining

Connector shape: Half to Full

Connector shape: Half to Half

Connector shape: Half to Pinhalf

Data Collection Terminal IT-2000

PC Only for AT-compatible architecture (see note)

SCSI Board Only for models specified by Casio (see note)

Software

PC side Upload/Download

Utility Dedicated for Windows95

Windows3.1 ver.

FLINK Utility

IT-2000

side MS-DOS version

FLINK Utility

Table 2.1 Options and software

Note:

For information about recommended SCSI Boards and SCSI Cables refer to Chapter 7,

"List of SCSI Boards and SCSI Cables".

2.2 System Configuration

This system can be configured in various ways. See typical examples of the hardware configuration

as below.

2.2.1 With Single I/O Box

Fig.2.1 System configuration with single Satellite I/O Box

Software

Hardware PC side IT-2000 side

Satellite I/O Box

RS-232C cable

IT-2000

Upload/Download Utility FLINK of Windows 3.1 ver.

or FLINK of MD-DOS ver.

Table 2.2 Hardware and software configuration with single Satellite I/O Box

2.2.2 With Multiple I/O Boxes

Fig. 2.2 System configuration with multiple Satellite I/O Boxes

PC Satellite I/O Box IT-2000

RS-232C IrDA

PC Satellite I/O Box

Satellite I/O Box

IT-2000

IrDA

RS-422

C-out

C-in

C-out

C-in

RS-232C

Maximum 8 Satellite I/O Boxes can be connected.

SoftwareHardware PC side IT-2000 side

Satellite I/O Box

RS-232C cable

RS-422 cable

IT-2000

Upload/Download Utility FLINK of Windows3.1 version or

FLINK of MS-DOS version

Table 2.3 Hardware and software configuration with multiple Satellite I/O Boxes

2.2.3 With Single Master I/O Box

Fig.2.3 System configuration with single Master I/O Box

Software

Hardware PC side IT-2000 side

Master I/O Box

SCSI cable

SCSI Board

IT-2000

Upload/Download Utility FLINK of Windows3.1 ver. or

FLINK of MS-DOS ver.

Table 2.4 Hardware and software configuration with one Master I/O Box

2.2.4 With Multiple Master I/O Boxes

Fig. 2.4 System configuration with multiple Master I/O Boxes

PC Master I/O Box IT-2000

SCSI IrDA

SCSI

Board

PC Master I/O Box

Master I/O Box

IT-2000

IrDA

SCSI

C-out

C-in

C-out

C-in

SCSI

Maximum 7 Master I/O Boxes can be connected.

SCSI

Board

SoftwareHardware PC side IT-2000 side

Master I/O Box

SCSI cable

IT-2000

SCSI Board

Upload/Download Utility FLINK of Windows3.1 ver. or

FLINK of MS-DOS ver.

Table 2.5 Hardware and software configuration with multiple Master I/O Boxes

2.2.5 With Master and Satellite I/O Boxes

Fig.2.5 System configuration with Master and Satellite I/O Boxes

Software

Hardware PC side IT-2000 side

Satellite I/O Box

Master I/O Box

SCSI cable

RS-422 cable

IT-2000

SCSI Board

Upload/Download Utility FLINK of Windows3.1 version or

FLINK of MS-DOS version

Table 2.6 Hardware and software configuration with Master and Satellite I/O Boxes

PC Master I/O Box

Master I/O Box

Satellite I/O Box

RS-422

SCSI

Maximum 7 Master I/O Boxes and 8 Satellite I/O Boxes can be connected.

SCSI

Board

IT-2000 IT-2000

IT-2000

IrDA

IT-2000

IrDA

2.3 Installation Method

This section describes the installation and setup procedures that must be performed before I/O Box

and PC operations are started. The following diagram shows a flow of the setup procedure.

Note:



For information about the installation procedure of the Upload/Download Utility refer to the

Upload/Download Utility Manual.



For information about the I/O Box setup refer to Chapter 2.3.1 “Setup of Satellite I/O Box”,

Chapter 2.3.2 “Setup of Master I/O Box”, and Chapter 2.3.3 “Setup of Satellite I/O Box to

Master I/O Box”.



For information about the setup of Upload/Download Utility environment refer to Chapter 2.3.4

“Setup of PC”.

Turn OFF the power of the

PC.

Set the DIP switch of I/O

Box.

Connect each cable between

I/O Boxes.

Connect cable between the

PC and I/O Box.

Connect AC adaptor for

each I/O Box.

Turn ON the power of all the

I/O Boxes.

Turn ON the power of the

PC.

Star up the

Upload/Download Utility

and set the environment.

(If Master I/O Box is used)

Mount SCSI Board in the PC and

install the SCSI driver

Install Upload/Download

Utility in the PC.

.2.6 Installation flow of IT-2000

2.3.1 Setup of Satellite I/O Box

The following paragraphs explain how to set up the Satellite I/O Box and Master I/O Box to be

connected to the PC.

Note that the DIP switch settings of the Satellite I/O Box differ depending on the connection with

single Satellite I/O Box or multiple Satellite I/O Boxes.

With single Satellite I/O Box



Make sure that the POWER switch of the I/O Box is set to OFF. Set the DIP switch at the rear

of the unit as follows:

12345678910

ON OFF OFF OFF ON OFF ON ON ON ON



Set the DIP switches nos. 1 to 5, 9, and 10 as shown above.



DIP switches nos 6, 7, and 8 are used to define the RS-232C baud rate of the I/O Box. It must

be consistent with the baud rate being set on the PC for RS-232C communication.



The above DIP setup example assumes that the RS-232C baud rate is 115200 bps. If modifying

this setup, use the following table as a reference.

Baud Rate 6 7 8

2400 bps OFF OFF OFF

4800 bps ON OFF OFF

9600 bps OFF ON OFF

19200 bps ON ON OFF

38400 bps OFF OFF ON

57600 bps ON OFF ON

115200 bps OFF ON ON



Connect the I/O Box and the PC with a cross-type RS-232C cable.

With Multiple Satellite I/O Boxes

Note that the DIP switch settings of the Satellite I/O Box differ depending on the connection,

ex. Satellite I/O Box directly connected to the PC or Satellite I/O Box connected with other Satellite

I/O Boxes under daisy-chain.



Make sure that the POWER switch of the I/O Box is set to OFF. Set the DIP switch of the

first I/O Box to be connected to the PC directly as follows.

12345678910

ON OFF OFF OFF OFF OFF ON ON ON ON



Set the DIP switch of other I/O Boxes to be connected under daisy-chain as follows.

12345678910

ON OFF OFF OFF ON OFF ON ON ON ON



Set DIP switch no. 5 of the last I/O Box to ON if the C-OUT terminal does not connect another

I/O Box (This is for the termination).



The above setup example assumes that the RS-232C baud rate is 115200 bps. If modifying this

setup, refer to the “With Single Satellite I/O Box” in the previous page.



Connect the first I/O Box and the PC with a cross-type RS-232C cable.

Then connect the C-OUT terminal of the I/O Box connected to the PC to the C-IN terminal of

the other I/O Box via the RS-422 cable. Connect the rest of I/O Boxes so that the one with the

terminator setting is the last under daisy-chain.
