Casio GV-20 Manual de usuario
RECORDING IMAGES
45
3.
Compose the image on the monitor screen.
• The focusing range of the camera is approximately 60
cm (23.6˝) to infinity (∞).
• You can compose images using either the monitor
screen or the optical viewfinder (page 51).
• When using the optical viewfinder to compose im-
ages, you can use DISP to turn off the monitor screen
and conserve battery power.
4.
Press the shutter
release button about
half way to lock the
exposure (AE Lock).
This section describes the basic procedure for recording an
image.
Recording a Simple Snapshot
Use the snapshot mode to record simple snapshots. Your
camera automatically adjusts shutter speed and aperture
settings in accordance with the brightness of the subject.
1.
Move the POWER ON/
OFF switch to ON.
• This causes an image or
a message to appear on
the monitor screen.
2.
Align the dial with
(snapshot mode).
RECORDING IMAGES
Shutter release button
RECORDING IMAGES
46
• When performing this
step, take care so your
fingers do not block the
lens or any of the
sensors.
5.
Press the shutter
release button the rest
of the way to record
the image.
• Recorded images are temporarily stored in a buffer,
from which they are saved on the memory card in-
stalled in the camera. You can continue to store im-
ages as long as there is space available in the buffer.
• The number of images you can store in the camera
depends on the storage medium and the image quality
setting (page 56) you are using.
• To avoid hand movement, press the shutter release
button gently.
• When available lighting is dim, use of a tripod is rec-
ommended to protect against hand movement.
About the REC Mode Monitor Screen
• The image shown on the monitor screen in the REC mode
is a simplified image for composing purposes. The actual
image is recorded in accordance with the image quality
setting currently selected on your camera. The image
saved on the memory card has much better resolution and
detail than the REC mode monitor screen image.
• Certain levels of subject brightness can cause the re-
sponse of the REC mode monitor screen to slow down,
which causes some static noise in the monitor screen im-
age.
Recording Precautions
• Never open the battery cover, disconnect the AC adaptor
from the camera, or unplug the adaptor from the wall
socket while the operation lamp is flashing green. Doing so
will not only make storage of the current image impossible,
it can also corrupt other image data already saved on the
camera’s memory card.
• Never remove batteries, unplug the AC adapter, or remove
the memory card while the camera is saving images.
• Fluorescent lighting actually flickers at a frequency that
cannot be detected by the human eye. When using the
camera indoors under such lighting, you may experience
some brightness or color problems with recorded images.
RECORDING IMAGES
47
Image Recording when Batteries are Low
Normally, the camera temporarily stores images you record
into buffer memory, and then transfers them to the memory
card. This is done in order to shorten the wait time between
shots. When the battery level is indicated by on the
monitor screen, however, the camera bypasses buffer
memory and saves images directly to the memory card. This
causes the wait interval between shots to become longer
than it usually is.
Using Zoom
You can use the digital zoom feature of your camera to zoom
in on the center of an image. Performing a zoom operation
toggles the zoom factor between 2X and 1X.
1.
In a recording mode,
press to
change the zoom
factor.
• Each press of toggles between the two
available zoom factors and displays the current set-
ting on the monitor screen.
• Note that digital zoom is disabled in the movie mode.
• Using digital zoom produces an 800 x 600-pixel im-
age, regardless of whether the selected image size is
1600 x 1200 pixels or 800 x 600 pixels (page 56).
Zoom
(Zoom/Enlarge)
RECORDING IMAGES
48
Using the Flash
The following describes various flash settings you can make
to suit the type of image you are trying to record.
1.
In a recording mode,
press to cycle
through the flash mode
settings until the one
you want is indicated
on the monitor screen.
• Each press of cycles through the available flash
modes described below.
Flash mode
indicator
(Flash/Nine Image)
To do this:
Have the flash fire automatically
when required (Auto Flash)
Always fire the flash (Flash On)
Turn off the flash (Flash Off)
Select this setting:
No display
RECORDING IMAGES
49
Flash Status Indicators
You can find out the current flash unit status by checking the
monitor screen and the operation lamp.
Operation lamp
Monitor screen
If the operation lamp is doing this:
Flashing amber
Flashing red
It means this:
Flash unit is charging.
Flash unit cannot charge
for some reason.
■Operation Lamp
■Monitor Screen
is shown on the monitor screen when auto flash is se-
lected.
Precautions when Using Flash
• Make sure that you do not touch or block the flash or the
exposure sensor with your fingers. Doing so can soil these
components and interfere with correct flash operation.
• The effective range for the built-in flash is approximately
0.6m to 2m (2.0´ to 6.6´) (at full aperture).
Note that you may not be able to obtain the desired flash
result outside the ranges noted above.
• Depending on operating conditions (type of batteries being
used, temperature, etc. ), it may take up to 10 seconds for
the flash unit to charge.
• The flash does not fire in the continuous shutter mode or
movie mode. This is indicated by on the monitor
screen.
Flash Exposure sensor
RECORDING IMAGES
50
• The flash unit does not charge when battery power is too
low to charge the flash. The (Flash Off) indicator ap-
pears to warn you that the flash will not fire correctly, which
may affect exposure of the image. Replace batteries as
soon as possible when this happens.
• White balance is fixed while the flash is being used, so sun-
light, fluorescent lighting, or other sources of illumination in
the immediate area may affect the coloring of the recorded
image.
Recording Macro Images
You can select either normal or macro (close-up) recording
using the selector located on the left side of the camera.
The table below describes the two settings available with the
selector.
To do this:
Shoot normal images, at a distance of
about 60cm (23.6˝) to infinity (Normal)
Shoot close-ups, at a distance of about
10cm (3.9˝) (Macro)
Select this setting:
• The distances indicated above represent the distance from
the camera’s lens surface to the subject.
Normal/Macro selector
RECORDING IMAGES
51
• Selecting the macro mode causes the indicator to ap-
pear on the monitor screen.
• Normally, you should leave the Norma/lMacro selector set-
ting at .
Using the Optical Viewfinder
Note the following points whenever you use the optical
viewfinder to compose images.
When subject is
close. Viewfinder frame
RECORDING IMAGES
52
The frame that is visible inside of the viewfinder indicates the
image recorded at a distance of about three meters (9.8´).
When the subject is closer or further away than three meters
(9.8´), the recorded image will be different from what you see
inside the viewfinder frame.
When recording a subject that is closer than 10cm (0.4˝)
from the lens, set the Normal/Macro selector to .
• Entering the macro mode or continuous shutter mode
causes the monitor screen to turn on automatically. Use
the monitor screen to compose images in these modes.
Recording Consecutive Images
(Continuous Shutter Mode)
The continuous shutter mode records images as long as you
keep the shutter release button depressed. Note that the
length of the interval between images depends on the image
quality setting.
1.
Align the dial with (Continuous Shutter
Mode).
2.
Hold down the shutter release button to record
the images you want.
• Images start to be saved to the memory card when
you release the shutter release button.
IMPORTANT!
• The flash does not fire during continuous shutter re-
cording.
• You cannot use the self-timer in combination with the
continuous shutter mode.
• Continuous shutter recording is disabled while the
battery indicator is on the monitor screen.
• Never remove the batteries or memory card from the
camera or unplug the AC adaptor while images are
being saved to memory.
RECORDING IMAGES
53
Recording with the self-timer
The self-timer counts down for 10 seconds before releasing
the shutter.
1.
Align the dial with (self-timer mode).
2.
Compose the image
and then press the
shutter release button.
• The self-timer lamp
flashes and the shutter
releases in about 10
seconds.
• The monitor screen turns
off while the countdown
is being performed.
• You can interrupt an
ongoing self-timer
countdown by pressing
the shutter release button
while the self-timer lamp
is flashing.
Self-timer lamp
Recording an Image Using a Best Shot
Mode Scene
Selecting one of the 18 Best Shot scenes automatically sets
up the camera for recording a similar type of image.
■Recording Example
Select “PORTRAIT” to record the image of
a person with vertical (portrait) orientation.
■Composition Outline
Selecting certain Best Shot
scenes causes a composition
outline to appear on the
monitor screen. Use the
composition outline to
compose your image and
achieve proper balance.
Example: Portrait
Composition outline
RECORDING IMAGES
54
1.
Align the dial with (Best Shot mode).
2.
Use [+] and [–] to select the Best Shot scene
you want to use and then press the shutter re-
lease button.
3.
Compose the image and then press the shutter
release button.
NOTES
• Best Shot scenes were not recorded using this cam-
era. They are provided as samples only.
• Images recorded using a Best Shot scene may not
produce the results you expected due to shooting con-
ditions and other factors.
• The first scene that appears when you enter the Best
Shot mode is the one that was on the display when
you last exited the mode.
• You cannot use exposure compensation (EV shift) in
the Best Shot mode.
• After you select a Best Shot scene, you can change to
another scene using [+] and [–].
Otros manuales para GV-20
2
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Cámara digital de Casio
Casio
Casio QV-30 Manual de usuario
Casio
Casio QV-R40 Manual de servicio
Casio
Casio QV-10 Manual de usuario
Casio
Casio EX-M20U - 4 Manual de usuario
Casio
Casio Exilim EX-S5 Manual de usuario
Casio
Casio QV-770 Manual de usuario
Casio
Casio EXILIM EX-Z670 Manual de usuario
Casio
Casio EX-Z3 - Exilim 3.2MP Digital Camera Manual de usuario
Casio
Casio EX-M20 - 2 Manual de usuario
Casio
Casio Exilim EX-Z29 Manual de usuario
Casio
Casio Exilim EX-ZR500 Manual de usuario
Casio
Casio EX-TR600 Manual de usuario
Casio
Casio YC-430 PJ Manual de usuario
Casio
Casio EX-Z2000BK Manual de usuario
Casio
Casio Exilim EX-ZS26 Manual de usuario
Casio
Casio QV-2400UX Manual de usuario
Casio
Casio EX-Z150 - EXILIM ZOOM Digital Camera Manual de usuario
Casio
Casio EX-Z700 - EXILIM Digital Camera Manual de usuario
Casio
Casio Exilim EX-FR10CT Guía de instalación
Casio
Casio Exilim EX-Z1000 Guía de solución de problemas
