USING A MEMORY CARD

125

USING A MEMORY CARD

You can expand the storage

capabilities of your camera by using

a commercially available memory

card (SD memory card or

MultiMediaCard). You can also

copy files from built-in flash

memory to a memory card and from

a memory card to flash memory.

•Normally, files are stored in built-in flash memory. When

you insert a memory card, however, the camera

automatically stores files to the card.

•Note that you cannot save files to built-in memory while a

memory card is installed in the camera.

IMPORTANT!

•Use only an SD memory card or a MultiMediaCard

with this camera. Proper operation is not guaranteed

when any other type of card is used.

•See the instructions that come with the memory card

for information about how to use it.

•Certain types of cards can slow down processing

speeds.

•SD memory cards have a write protect switch, which

you can use to protect against accidental deletion of

image data. Note, however, if you write protect an

SD memory card, you must remove write protection

whenever you want to record to it, format it, or delete

any of its files.

•Electrostatic charge, electrical noise, and other

phenomena can cause data to become corrupted or

even lost. Always make sure that you always back

up important data on other media (CD-R, CD-RW,

MO disc, computer hard disk, etc.)

USING A MEMORY CARD

126

To remove a memory card from the

camera

Press the memory card

into the camera and then

release it. This will cause

the card to come part way

out of the camera.

Pull the memory card out

of the slot.

Using a Memory Card

IMPORTANT!

•Make sure you turn off the camera before inserting or

removing a memory card.

•Be sure to orient the card correctly when inserting it.

Never try to force a memory card into the slot when

you feel resistance.

To insert a memory card into the camera

Positioning the memory

card so its back is facing

in the same direction as

the camera’s lens,

carefully slide it into the

card slot.

Contacts

BackFront

USING A MEMORY CARD

127

IMPORTANT!

•Never insert any other object besides a memory card

into the camera’s card slot. Doing so creates the risk

of damage to the camera and card.

•Should water or any foreign object ever get into the

card slot, immediately turn off the camera, remove

the battery, and contact your dealer or nearest

CASIO authorized service center.

•Never remove a card from the camera while the

operation/flash charge lamp is flashing. Doing so can

cause the file save operation to fail, and even

damage the memory card.

Formatting a Memory Card

Formatting a memory card deletes any data already stored

on it.

IMPORTANT!

•Be sure to use the camera to format a memory card.

Formatting a memory card on a computer and then

using it in the camera can slow down data

processing by the camera. In the case of an SD card,

formatting on a computer can result in non-

conformity with the SD format, causing problems with

compatibility, operation, etc.

•Note that data deleted by a memory card format

operation cannot be recovered. Check to make sure

you do not need any of the data on the memory card

before you format it.

•Formatting a memory card that contains files deletes

all the files, even those that are protected (page

100).

USING A MEMORY CARD

128

Load the memory card into the camera.

Turn on the camera. Next, enter the REC

mode or PLAY mode and press [MENU].

Select the “Set Up”tab, select “Format”, and

then press [].

Use [] and [] to select “Format”, and then

press [SET].

•To exit the format operation without formatting,

select “Cancel”.

Memory Card Precautions

•If a memory card starts to behave abnormally, you can

restore normal operation by reformatting it. However, we

recommend that you always take along more than one

memory card whenever using the camera far away from

the home or office.

•We recommend that you format a memory card before

using it for the first time after purchasing it, or whenever

the card you are using seems to be the cause of

abnormal images.

•Before starting a format operation, check to make sure

that the battery is fully charged. Power interruption during

the format operation can result in improper formatting,

and even damage the memory card and make it

unusable.

USING A MEMORY CARD

129

Copying Files

Use the procedures below to copy files between built-in

memory and a memory card.

IMPORTANT!

•Only snapshot, movie files, audio snapshot (EX-M20

only), and voice recording files (EX-M20 only)

recorded with this camera can be copied. Other files

cannot be copied.

•Copying an audio snapshot (EX-M20 only) copies

both the image file and the audio file.

To copy all the files in built-in memory to

a memory card

Load the memory card into the camera.

Turn on the camera. Next, enter the PLAY

mode and press [MENU].

Select the “PLAY”tab,

select “Copy”, and

then press [].

Use [] and [] to select “Built-in Card”,

and then press [SET].

•This starts the copy operation and displays the

message “Busy.... Please wait...”.

•After the copy operation is complete, the monitor

screen shows the last file in the folder.

USING A MEMORY CARD

130

To copy a file from a memory card to

built-in memory

With this procedure you can copy one file at a time.

Perform steps 1 through 3 of the procedure

under “To copy all the files in built-in memory

to a memory card”.

Use [] and [] to select “Card Built-in”,

and then press [SET].

Use [] and [] to select the file you want to

copy.

Use [] and [] to select “Copy”, and then

press [SET].

•This starts the copy operation and displays the

message “Busy.... Please wait...”.

•The file reappears on the monitor screen after the

copy operation is complete.

•Repeat steps 3 through 4 to copy other images, if

you want.

Press [MENU] to exit the copy operation.

NOTE

•Files are copied to the folder in built-in memory

whose name has the largest number.

VIEWING IMAGES ON A COMPUTER

131

VIEWING IMAGES ON A COMPUTER

After using the USB cradle to establish a USB connection

between the camera and your computer, you can use your

computer to view images in file memory and copy images

to your computer’s hard disk or other storage media. In

order to do this, you first need to install the USB driver

located on the CD-ROM that comes bundled with the

camera onto your computer.

Note that the procedure you need to perform depends on

whether you are using computer running under Windows

(see below) or a Macintosh (see page 136).

Using the Camera with a Windows

Computer

The following are the general steps for viewing and copying

files from a computer running under Windows. You can find

details about each operation in the procedures that follow

below. Note that you should also refer to the

documentation that comes with your computer for other

information about USB connections, etc.

1. If you are running Windows 98, Me, or 2000, install

the USB driver onto your computer.

• You need to perform this step only once, the first

time you connect to your computer.

• If you are running Windows XP, you do not need to

install the USB driver.

2. Use the USB cradle to establish a connection between

the camera and computer.

3. View and copy the images you want.

VIEWING IMAGES ON A COMPUTER

132

What you should do first depends on whether

your computer is running under Windows 98/

Me/2000 or Windows XP.

■Windows 98/Me/2000 Users

• Start from step 2 to install the USB driver.

• Note that the example installation presented here

uses Windows 98.

■Windows XP Users

• Installation of the USB driver is not required, so jump

directly to step 6.

Set the bundled CD-ROM into the CD-ROM

drive of your computer.

On the menu screen

that appears, click

“English”.

Click [USB driver] and then [Install].

• This starts installation.

• The following steps show installation under the

English version of Windows.

On the screen that appears after installation

is complete, select the “Yes, I want to restart

my computer now.” check box and then click

[Finish] to restart your computer.

IMPORTANT!

• Do not try to establish a connection between the

camera and computer before installing the USB

driver onto the computer.

• If you want to transfer files from the camera’s built-in

memory to a computer, make sure there is no

memory card loaded in the camera before you place

it onto the USB cradle.

VIEWING IMAGES ON A COMPUTER

133

Connect the AC power cord to the bundled

AC adaptor, and then plug the other end of

the AC power cord into a household power

outlet.

Connect the AC adaptor to the [DC IN 5.3V]

connector of the USB cradle.

Connect the USB cable that comes bundled

with the camera to the USB cradle and your

computer’s USB port.

• Take care when connecting the USB cable to the

USB cradle or your computer. USB ports and cable

plugs are shaped for proper positioning.

• Plug the USB cable plugs into the ports securely, as

far as they will go. Proper operation is not possible if

connections are not correct.

USB port

Connector A

USB cable

(bundled)

[USB]

Connector B

VIEWING IMAGES ON A COMPUTER

134

DISP

After making sure the camera is turned off,

place the camera onto the USB cradle.

• Do not place the camera onto the USB cradle while it

is turned on.

10.

Press the USB cradle’s [USB] button.

• This will cause the “Add New Hardware...” dialog box

to appear on the computer screen as the computer

automatically detects the camera’s file memory. After

you install the USB driver, “Add New Hardware...”

dialog box will no longer appear when you perform

the above steps to establish a USB connection.

• Pressing the [USB] button enters the USB mode,

which causes the USB cradle’s [USB] lamp to light

green (page 177).

• At this point, some operating systems will display a

“Removable Disk” dialog box. If your operating

system does, close the dialog box.

DISP

[USB] button

[USB] lamp

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Casio

Casio

Casio QV-R40 Guía de configuración

Casio

Casio EXILIM EX-FC300S Manual de usuario

Casio

Casio Exilim EX-FH100 Manual de usuario

Casio

Casio Exilim EX-Z6 Manual de usuario

Casio

Casio EX-Z200RD - EXILIM ZOOM Digital Camera Manual de usuario

Casio

Casio EX-TR60 Manual de usuario

Casio

Casio Exilim EX-Z850 Manual de usuario

Casio

Casio EXILIM EX-FH20 Manual de usuario

Casio

Casio Exilim EX-Z1050 Guía de solución de problemas

Casio

Casio EX-ZS5SR Manual de usuario

Casio

Casio Exilim EX-Z600 Manual de usuario

Casio

Casio EXILIM EX-ZS5 Manual de usuario

Casio

Casio EX-S20 - EXILIM Digital Camera Manual de usuario

Casio

Casio Exilim EX-Z600 Guía de solución de problemas

Casio

Casio Exilim EX-ZR10 Manual de usuario

Casio

Casio EX-Z80BK Manual de usuario

Casio

Casio QV-780 Guía de solución de problemas

Casio

Casio EXILIM EX-ZR310 Guía

Casio

Casio Exilim EX-FH100 Manual de usuario

Casio

Casio QV-2400UX Manual de usuario

Casio

Casio QV-700 Manual de usuario

Casio

Casio EX-M20 - 2 Manual de usuario

Casio

Casio EX-ZR3600 Manual de usuario

Casio

Casio Exilim EX-Z29 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
