PLAYBACK

Use [왘] (forward) or [왗] (back) to scroll

through files on the monitor screen.

NOTES

•Holding down [왗] or [왘] scrolls images at high

speed.

•Note that the images produced on the monitor

screen of this camera are simplified versions of the

actual image stored in memory.

You can use the camera’s built-in monitor screen to view

images after you record them.

Basic Playback Operation

Use the following procedure to scroll through files stored in

the camera’s memory.

Press the power

button to turn on the

camera.

•This causes an image

or a message to appear

on the monitor screen.

Align the mode

selector with “PLAY”.

•This enters the PLAY

mode.

RECPLAY

Mode selector

ON/OFF

Power button

PLAYBACK

SET

[SET]

Shutter release button

Flipping the Display

The following procedure flips the image 180 degrees. This

comes in handy when you want to show someone standing

in front of you an image on the monitor screen.

In the PLAY mode, use [왗] and [왘] to scroll

through images on the monitor screen and

display the one you want.

Press the shutter release button and [SET] at

the same time.

•This flips the image 180 degrees. The histogram or

any other display information you had displayed is

cleared automatically whenever you flip the image.

•While an image is flipped, you can use [왗] and [왘] to

scroll to another image, if you want.

To return the image to its normal orientation,

press any button other than [왖], [왔], [왗], or

[왘].

IMPORTANT!

•Note that you cannot play a movie on the monitor

screen while a flipped image is displayed.

•You cannot use the above procedure to flip an image

while a zoomed image, 9-image screen, or calendar

screen is on the display, or while a movie is playing.

PLAYBACK

Zooming the Display Image

Perform the following procedure to zoom the image

currently on the monitor screen up to four times its normal

size.

In the PLAY mode, use [왗] and [왘] to display

the image you want.

Press the zoom

button ( ) to enlarge

the image.

•This displays an

indicator that shows the

current zoom factor.

•You can toggle between

the zoomed image and

normal image by

pressing [MENU].

Current zoom factor

Use [왖], [왔], [왗], and [왘] to shift the image

up, down, left, or right.

Press [MENU] to return the image to its

original size.

IMPORTANT!

•You cannot enlarge a movie image.

•Depending on the original size of the recorded

image, you may not be able to zoom a display image

the full four times its normal size.

PLAYBACK

Resizing an Image

You can use the following procedure to change a snapshot

image to either SXGA size (1280 x 960 pixels) or VGA size

(640 x 480 pixels).

•VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

In the PLAY mode, press [MENU].

Select the “PLAY”

tab, select “Resize”,

and then press [왘].

Use [왗] and [왘] to scroll through images and

display the one you want to resize.

IMPORTANT!

•Resizing an image creates a new file that contains

the image in the size you select. The file with the

original image also remains in memory.

•Images smaller than 640 x 480 pixels cannot be

resized.

•Note that you can resize snapshots recorded with

this camera only.

•If the message “The function is not supported for this

file.”appears, it means that the current image cannot

be resized.

•The resize operation cannot be performed if there is

not enough memory to store the resized image.

Use [왖] and [왔] to select the setting you

want, and then press [SET].

To do this:

Resize to 1280 x 960 pixels (SXGA)

Resize to 640 x 480 pixels (VGA)

Cancel the resizing operation

Select this:

1280 x 960

640 x 480

Cancel

PLAYBACK

Cropping an Image

Use the following procedure when you want to crop a

portion of an enlarged image and use the remaining part of

the image as an e-mail attachment, Web page image, etc.

In the PLAY mode, use [왗] and [왘] to scroll

through images and display the one you want

to crop.

Press [MENU].

Select the “PLAY”

tab, select

“Trimming”, and then

press [왘].

•This causes a cropping

boundary to appear.

Use the zoom button ( ) to make the

cropping boundary larger or smaller.

•The size of the cropping boundary depends on the

size of the image on the display.

Use [왖], [왔], [왗], and [왘] to move the

cropping boundary up, down, left, or right

until the area of the image you want to extract

is within the boundary.

Press [SET] to extract the part of the image

enclosed in the cropping boundary.

•If you want to cancel the procedure at any point,

press [MENU].

IMPORTANT!

•Cropping an image creates a new file that contains

the cropped image. The file with the original image

also remains in memory.

•A Movie mode image cannot be cropped.

•An image recorded using another camera model

cannot be cropped.

•If the message “The function is not supported for this

file.”appears, it means that the current image cannot

be cropped.

•The cropping operation cannot be performed if there

is not enough memory to store the cropped image.

PLAYBACK

Playing a Movie

Use the following procedure to play back a movie that was

recorded in the movie mode.

In the PLAY mode,

press [왗] and [왘] to

scroll through images

until the movie you

want to play is

displayed.

Press [SET].

•This start playback of the movie.

Movie icon

IMPORTANT!

•You cannot repeat play a movie. To play a movie

more than once, repeat the steps of the above

procedure.

•Note that this camera cannot play back a movie’s

audio. You need to transfer the movie file to a

computer (page 124) to hear the audio.

•You can perform the following operations while a

movie is playing.

To do this:

Fast forward or fast reverse

the movie

Pause and unpause movie

playback

Skip forward or back one

frame while paused

Cancel playback

Do this:

Hold down [왗] or

[왘].

Press [SET].

Press [왗] or [왘].

Press [MENU].

PLAYBACK

Displaying the 9-image View

The following procedure displays nine images on the

monitor screen at the same time.

In the PLAY mode, press the zoom button

().

•This displays the 9-image screen with the image that

was on the monitor screen in step 2 in the center,

with a selection boundary around it.

•Pressing the zoom button ( ) twice displays the

calendar screen.

•When there are nine or fewer images, they are

displayed in order with Image 1 in the upper left

corner, with the selection boundary around it.

Use [왖], [왔], [왗], and [왘] to move the

selection boundary to the image you want.

Pressing [왘] while the selection boundary is

in the right column or [왗] while it is in the left

column scrolls to the next full screen of nine

images.

Pressing any button besides [왖], [왔], [왗], or

[왘] displays the full-size version of the image

where the selection boundary is located.

2 3

17 18 19

20 1 2

345

678

91011

12 13 14

15 16 17

18 19 20

Example: When there are 20 images in memory, and

Image 1 is displayed first

PLAYBACK

Selecting a Specific Image in the 9-

image View

Display the 9-image view.

Use [왖], [왔], [왗], and

[왘] to move the

selection boundary

up, down, left, or right

until it is located at

the image you want to

view.

Pressing any button

besides [왖], [왔], [왗],

or [왘] displays the

selected image.

•This displays the full-

size version of the

image you selected.

Selection boundary

Displaying the Calendar Screen

Use the following procedure to display a 1-month calendar.

While the calendar is on the display, you can select a date,

which displays the first image recorded on that date. This

helps to make it easy to find the images you want.

In the PLAY mode, press the zoom button ( )

twice.

•You can also display the calendar screen (in the

PLAY mode) by pressing [MENU], selecting the

“PLAY”tab, selecting “Calendar”, and then pressing

[왘].

Use [왖], [왔], [왗], and

[왘] to move the date

selection cursor.

•Use the procedure

under “Changing the

Date Format”on page

113 to specify the date

format.

•The image displayed on

the calendar for each

date is the first image

that was recorded on

that date.

Month/Year

Date selection cursor

PLAYBACK

•Pressing [왖] while the date selection cursor is

located anywhere in the top line of the calendar

causes the previous month to appear.

•Pressing [왔] while the date selection cursor is

located anywhere in the bottom line of the calendar

causes the next month to appear.

•To exit the calendar screen, press [MENU] or the ( )

zoom button.

•appears in place of the image when the date

contains data that cannot be displayed by this

camera.

To view the large version of a date’s image,

move the date selection cursor to the date

and then press [SET].

•This displays the first image that was recorded on

the selected date.

Playing a Slide Show

Slide Show automatically plays back images in sequence

at a fixed interval.

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Slideshow”,

and then press [왘].

PLAYBACK

Select “Start”, and then press [SET].

•This starts the slide show.

To stop Slide Show, press any button.

•The slideshow will also stop automatically after the

amount of time you specified for “Time”elapses.

Configure the slideshow settings.

•See the pages indicated below for more information.

For information about

configuring this setting:

Images

Time

Interval

Go here:

“To specify the slideshow

images”on page 90

“To specify the slideshow

time”on page 91

“To set the slideshow

interval”on page 91

IMPORTANT!

•Note that all buttons are disabled while an image

change is in progress. Wait until an image is stopped

on the monitor screen before performing a button

operation, or hold down the button until the image

stops.

•Images copied from another digital camera or a

computer may take longer time to appear than the

slideshow interval time you specify.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Casio

Casio

Casio EX-Z4 - EXILIM Digital Camera Manual de usuario

Casio

Casio Exilim EX-S100 Manual de usuario

Casio

Casio EX-V8 - EXILIM Hi-Zoom Digital Camera Manual de usuario

Casio

Casio Exilim EX-Z90 Manual de usuario

Casio

Casio QV-3500EX Instrucciones de instalación y mantenimiento

Casio

Casio EXILIM Exilim EX Z 33 Manual de usuario

Casio

Casio EX-M20 - 1 Manual de usuario

Casio

Casio EX-S2 - Exilim 2MP Digital Camera Manual de usuario

Casio

Casio EXILIM EX-Z350 Manual de usuario

Casio

Casio Exilim EX-P700 Manual de usuario

Casio

Casio EXILIM EX - Digital Camera - 3.2 Megapixel Manual de usuario

Casio

Casio EXILIM EX-Z70 Guía de instalación

Casio

Casio EXILIM EX-ZS5 Manual de usuario

Casio

Casio QV-10 Manual de usuario

Casio

Casio Exilim EX-N5 Manual de usuario

Casio

Casio QV-R62 Manual de usuario

Casio

Casio EX-F1 - EXILIM Pro Digital Camera Manual de instrucciones y seguridad

Casio

Casio Exilim EX-H10 Manual de usuario

Casio

Casio EX-Z270 - EXILIM Digital Camera Manual de usuario

Casio

Casio QV-R3 Manual de lista de piezas

Casio

Casio EX-10 Manual de usuario

Casio

Casio Exilim EX-Z4U Manual de instrucciones y seguridad

Casio

Casio EX-S3 - Exilim 3MP Digital Camera Manual de instrucciones y seguridad

Casio

Casio Exilim EX-FS10 Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
