Canyon Marzipan Manual de usuario
Smartwatch
With extra leather strap
«Marzipan»
Quick Guide v 2
SW75
1. SMARTWATCH. WITH EXTRA LEATHER
STRAP.
• Durable metal watch-case
• 6H hardness tempered glass
• Compatibility with iOS and Android OS
• Multi-sport mode
• Weather display
• IP68 waterproof
• Camera remote
• Woman calendar
2. COMPLETE SET INCLUDES:
• Smartwatch
• Silicone strap
• Leather strap
• Battery (built-in)
• USB charging kit
• User manual
3. USAGE
Make sure that your smartwatch is fully charged
before using. It takes up to 5 hours to be fully charged.
EN
Charging: Use the magnetic charger to connect to the
magnetic contacts on the back of the watch (magnetic
contacts will attract cable end). After that, put the USB
plug into the USB port of your computer, a wall socket
adapter or a power bank. The charging progress
will be indicated on the screen. For better charging
compatibility, it is advisable to use a Power Bank or
wall charger produced by Canyon. Do not use a fast
charging device as it could result in a short circuit
and risk of re.
Charger requirements: 5V/1A
Charging time: 2-5 hours
depending on a source of charge.
Turning on: Hold your nger on the
screen for a few seconds until the
device is turned on.
Turning off: Tap the screen to activate it. Swipe your
nger from right to left to see menu items. Scroll
up until you see “Power off” on the display, choose
“Power off”, and you will see : “V” and “X”, choose “V”,
then it will turn off.
Connecting to a smartphone: charge the smartwatch,
turn it on, activate Bluetooth on your smartphone,
download and install Canyon Smart Watch
application Canyon Life by scanning the QR code
below. Open Canyon Life app->“Bluetooth Devices”->
EN
EN
”Start”-> choose on your watch from the Pair
Device list >(SW75) -> press ”ADD DEVICE” and
you will see Device successfully connected. Use
the application to apply the settings you need, for
example you can: turn on sedentary reminder, select
apps that you want to receive notications from, etc.
Usage: from main screen swipe to left to enter main
menu, swipe up or down to move through main
menu. Hold or press to select a function or go to the
sub-menu. From main screen swipe up to see activity
menu, hold or press to select a function or go to the
sub-menu.
Scan this QR code to
download and install the
application Сanyon Life:
4. FEATURES.
EN
1. Main screen
Left swipe on the main screen to enter the menu,
select Style. Swipe left or right to select style. Tap the
screen to select it.
3. Sleep monitoring
Users who wear the watch during
sleep can record the length of
sleep, as well as their deep sleep
and light sleep status and can
adjust sleeping times according to
the data references and improve
body health index. The defaulted sleep monitoring
time is from 10 pm to 8 am, the sleeping data results
from the previous night will be displayed after 8 am.
2. Pedometer
The watch can record the
number of steps taken every
day, the pedometer data can
be synchronized to the App, the
walking distance traveled, calories
and other data details can be
viewed from the App (the number of steps, distance,
calories, etc., recorded in the watch will be cleared at
00:00 every day).
EN
The data can be synchronized with the App and the
detailed sleep data information and analysis of the
record can be viewed from the App.
4. Heart Rate
Select heart rate function interface,
the heart rate monitoring will start
automatically after 2 seconds
(you can also click the heart
rate icon to stop/start during the
measurement). The results will be displayed when
the measurement is completed. The heart rate
monitoring data can be synchronized to the App
(Please utilize the correct posture when measuring,
the measurement results are for reference only,
cannot be used as medical data).
5. Multi-Sport mode
Click the sport mode icon to enter
the multi-sport mode: walking,
running, cycling, skipping,
badminton, basketball, football and
swimming. Swipe up and down to
select a sport, click to start activity, swipe left or right
on the sports mode interface to pause or to stop. The
sport mode data can be synchronized with the App
EN
and the detailed sport data information and analysis
of the record can be viewed from the App.
6. Oxygen
Swipe onto the oxygen interface,
the oxygen will be automatically
measured after 2 seconds
(the oxygen measure can also
be stopped/started during the
measurement), the test data will be displayed when
measurement is completed. (Please utilize the
correct posture when measuring, the measurement
results are for reference only, cannot be used as
medical data).
7. Weather forecast
Displays current weather
information and tomorrow’ s
weather information. Note: it needs
to be connected to the App to get
weather information.
8. Notications reminder
On the main screen swipe to right to see message
display interface. When there is a new message, the
EN
watch will vibrate to remind you to view the message
content. The watch stores the last three messages
received from a mobile phone, and automatically
overwrites the rst stored message when the later
message is received. Includes SMS and other
information, you can select what apps you want
notications from in Canyon Life App.
If you will use woman calendar, set up
your data In APP to get notication from
the calendar:
9. Device information
You can check the version’ s information, BT MAC
address, power display and Bluetooth connection
status.
5. FUNCTIONS
Slide left on the main screen to enter other functions
menu:
1. Сamera Control
Open “Take photo” screen in App and you will see
capture icon on watch. Press icon on watch or shake
the arm to make a photo.
2. Timer
Click the Timer function to enter the timer interface,
EN
click the blue button to pause/start, and click the red
button to reset.
3. Brightness
Click the brightness adjustment function to adjust
the screen brightness you need according to your
requirements.
4. Restore Factory
When you click to restore the factory settings,
the watch returns to the initial state and restarts
automatically. At this time, all data on the wristband
is cleared.
5. Shut down
Scroll up until you see “Power off” on the display,
choose “Power off”, and you will see: “V” and “X”,
choose “ V”, then it will shut down.
6. Sedentary reminder
This function reminds the user to walk around every
hour (if switched on in the app). (The sedentary
reminder only takes effect from 10 am till 10 pm).
7. lncoming call
When the APP is connected and call reminder function
is switched on in App bracelet will vibrate when there
is an incoming call.
EN
8. Alarm clock
You can set up to 3 alarms in App. Please note, alarm
time should be set to 2 minutes or more later then
current time)
Troubleshooting
Problem Solution
Your smartwatch doesn’t
turn on
Connect to a USB cable
to charge device and
wait for a few minutes
Your smartwatch
isn’t detected by a
smartphone
Make sure that
Bluetooth, GPS Location
Services with high
precision are active on
your smartphone
Your smartwatch
is detected by a
smartphone, but fails to
connect
Turn the smartwatch off
and then turn it back on
If the actions from above-mentioned list do not help,
please contact support service at Canyon web-site:
http://canyon.eu/ask-your-question/
Download extended functional guide by the link:
https://canyon.eu/les/manuals/quickquides/
smartwatches/functional-guide.pdf
