Canon ImageCLASS MF113w Manual de usuario

Getting Started

Mise en route

Introducción

Introdução

Quick Operation P.21

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

canon.com/oip-manual

Quick Setup

Getting Started

Please read "Important Safety Instructions" before

operating this product. P. 2 6

After you finish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Mise en route

Prenez connaissance des "Consignes de sécurité

importantes" avant toute utilisation de ce produit. P.36

Après en avoir pris connaissance, conservez ce guide dans

un endroit sûr en vue de consultations ultérieures.

Les informations contenues dans ce document peuvent

être modifiées sans avis préalable.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de

usar este producto. P. 4 6

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modificada

sin previo aviso.

Introdução

Leia "Instruções de segurança importantes" antes de operar

este produto. P.56

Depois de ler este guia, guarde-o em um local seguro para

referência futura.

As informações contidas neste documento estão sujeitas a

alterações sem aviso prévio.

You can access

canon.com/oip-manual to read the User's Guide that

describes all functions of this machine.

Le guide de l'utilisateur,

qui décrit toutes les fonctions de cet appareil se trouve sur

canon.com/oip-manual.

Puede acceder a

canon.com/oip-manual para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

Você pode acessar

canon.com/oip-manual para ler o Guia do usuário que

descreve todas as funções desta máquina.

Quick Setup

Installation of the Machine

× 1 × 1

Toner cartridge and drum cartridge (included with the

machine)

Before starting the installation

• Remove all of the tape.

• Do not remove the sticker that covers the USB

port.

Sticker

Installation Requirements

Provide a space of 4" (100 mm) or more around

the machine.

(197 mm)

7 3/4" (58 mm)

2 1/4"

(276 mm)

10 7/8"

(372 mm)

14 5/8"

(320 mm)

12 5/8"

(255 mm)

10"

(249 mm)

9 7/8"

Items Included with the

Machine Installing the Machine

Quick Setup

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Configuring the Machine

• Configure the initial settings, according to the

screen.

2. Set the language and country/region.

3. Set the time zone and current date/time.

Before starting the configuration

• The machine cannot be connected to

both wired and wireless LANs at the same

time.

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

• The machine does not come with a

router. Please have one ready, if

necessary.

• Even in an environment without wireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device (Direct Connection).

User's Guide

Specifying the connection method

Use wireless LAN to

connect to network?

(Can config. later.)

Yes No

• To connect via wireless LAN : <Yes>

• To connect via wired LAN or USB : <No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

Configure the settings in the following order.

NOTE

Parts and functions of the operation panel

P.22 "Start the Operation from the Operation

Panel"

Configuring the Initial Settings

of the Machine Configuring the Method of

Connecting to a Computer

Quick Setup

2. Check the network settings on the computer.

3. Take note of the SSID and network key.

• Check the label on the router. User's Guide

• The setting operation is easier if the router is

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

For more

information, refer

to the manual.

1. Select <OK>.

2. Select <SSID Settings>.

3. Select <Select Access Point>.

4. Select the access point (SSID).

5. Enter a network key, and Select <Apply>.

6. Select <Yes>.

• The IP address will be automatically

configured in a few minutes.

• "Connected." is displayed.

5. Install the driver and software.

P.8 "Installing the software"

To view a video guide on the process

You can find a video and guide to assist the

process for the Wireless Network connection

from the URL below. Viewing these guides will

ensure a smooth setup of the device into your

existing wireless environment.

http://www.usa.canon.com/WirelessHelp

Now you are finished with the

configuration of the initial settings.

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few minutes

(until the IP address is set automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.8 "Installing the software"

Now you are finished with the

configuration of the initial settings.

For details

"Setting Up Using the Setup Guide" in the User's Guide

Quick Setup

Installing the software

• The procedure described here is only applicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

• For the installation when your computer runs on

the macOS, see the driver's manual.

• Your machine may not come with the driver for

the macOS, depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly,

re-insert the CD-ROM/DVD-ROM or search

for "D:\MInst.exe" on the Windows platform

(This description assumes that "D:" is the

CD-ROM/DVD-ROM drive name).

To connect via USB

• The machine does not come with a USB cable.

Please have one ready, if necessary.

• Make sure that the USB cable you

use has the following mark.

• Do not connect the USB cable

before installing the driver. If you did, disconnect

the USB cable from the computer, close the

dialog box, and then perform the following

procedure from step 1.

1. Install the driver and software.

P.8 "Installing the software"

• When a screen with instructions for

connecting the USB cable to the machine is

displayed, remove the sticker that covers the

USB port.

Now you are finished with the

configuration of the initial settings.

Configuring the Machine

Memo

Configuration rapide

Configuration de l'appareil

• Configurez les réglages initiaux en suivant les

instructions à l'écran.

2. Spécifiez la langue et le pays/la région.

3. Spécifiez le fuseau horaire et réglez la date et

l'heure.

Avant commencer la configuration

• Cet appareil ne peut pas être connecté

simultanément par des réseaux sans fil et

filaires.

• Si l'appareil est connecté à un réseau non

sécurisé, vos informations personnelles

pourraient être divulguées à un tiers.

Soyez conscient de cette situation et

agissez prudemment.

• L'appareil n'est pas livré avec un routeur.

Vous devez vous en procurer un.

• Même dans un environnement sans

routeur de réseau sans fil, vous pouvez

utiliser le mode Point d'accès pour établir

directement une connexion sans fil entre

l'appareil et votre appareil mobile

(connexion directe).

Guide de l'utilisateur

Spécification de la méthode de connexion

Util rés sans fil

pour conn. rés. ?

(Config. ult.)

Oui Non

• Connexion par réseau sans fil: <Oui>

• Connexion par réseau filaire ou USB: <Non>

Connexion par réseau sans fil

1. Assurez-vous que l'ordinateur est correctement

connecté à un routeur.

Configurez les réglages dans l'ordre suivant.

REMARQUE

Sections et fonctions du panneau de commande

P.32 "Démarrage à partir du panneau de

commande"

Configuration des réglages

initiaux de l'appareil Configuration de la méthode

de connexion à un ordinateur
