Wi-Fi Function

Instruction Manual

INSTRUCTION

MANUAL

EOS 70D (W)

COPY

This camera’s wireless LAN functions let you perform a range of tasks

wirelessly, from sending images to Web services and other cameras to

controlling the camera remotely, simply by connecting to a Wi-Fi



network or other device supporting this camera’s wireless LAN functions.

What You Can Do Using the Wireless LAN Functions

(1)Transfer images

between cameras

Exchange images

(6)View images using

a media player

View images

(5)Send images to

a Web service

Save and share images

(4)Operate the camera

remotely using EOS Utility

Remotely control the camera

(3) Print images using

a Wi-Fi printer

Print images

(2) Connect to a

smartphone

Make images

viewable

Remote shooting

(Canon Image Gateway)

CANON iMAGE GATEWAY Web services are not supported in certain countries

and areas. For information on countries and areas supporting CANON iMAGE

GATEWAY services, refer to the Canon Web site (http://canon.com/cig).

Settings for “Send images to a Web service” may not be performed from

a computer in certain countries and areas.

COPY

What You Can Do Using the Wireless LAN Functions

(1)z Transfer images between cameras (p.19)

Transfer images between this camera and other Canon cameras

with built-in wireless LAN functions.

(2)q Connect to a smartphone (p.31, 75)

View saved images or operate the camera from your smartphone.

Install the dedicated application “EOS Remote” on your smartphone

to use these functions.

(3)l Print images using a Wi-Fi printer (p.45, 87)

Connect the camera to a wireless LAN compatible printer supporting

PictBridge (DPS over IP) to print images wirelessly.

(4)DOperate the camera remotely using EOS Utility (p.93)

Connect the camera and a computer wirelessly and operate your

camera remotely using the provided software EOS Utility.

(5)wSend images to a Web service (p.103)

Upload your images to CANON iMAGE GATEWAY, an online photo

service for Canon users (free registration required), to share them

with family and friends.

(6) View images using a media player (p.131)

Display images on the camera’s memory card on your TV set, by

using a media player supporting DLNA* via a wireless LAN.

* Digital Living Network Alliance

COPY

Wi-Fi Function Flowchart

z Transfer images between cameras q Connect to a smartphone

Set up another Canon camera with

built-in wireless LAN functions Install EOS Remote on a smartphone

Connect the cameras directly via a

wireless LAN • Camera access point mode*1

• Infrastructure mode*2

Transfer images between cameras • View images on the camera

• Shoot remotely

l Print images using a Wi-Fi printer DOperate the camera remotely

using EOS Utility

Set up a Wi-Fi printer supporting

PictBridge (DPS over IP) Set up a wireless LAN and a

computer with EOS Utility installed

• Camera access point mode*1

• Infrastructure mode*2• Infrastructure mode*2

• Ad hoc mode*3

Play and print images Operate the camera remotely using

EOS Utility

Setup

Connection

method

Now you

can...

Setup

Connection

method

Now you

can...

COPY

Wi-Fi Function Flowchart

*1 Camera access point mode:

A simple wireless LAN mode where a camera and smartphone, or a camera and

printer can be directly connected via a wireless LAN.

*2 Infrastructure mode:

A wireless LAN mode that connects to each Wi-Fi device via a wireless LAN access

point. In this mode, communication to a distant Wi-Fi device can be established as

long as a wireless LAN access point is located nearby.

*3 Ad hoc mode:

A wireless LAN mode that connects directly to a computer with built-in wireless LAN

functions. When setting the computer’s wireless LAN functions to ad hoc mode, the

camera can be connected using the same operation as when set to infrastructure

mode.

wSend images to a Web service

View images using a media

player

• Set up a computer with EOS Utility

installed and a wireless LAN access

point that can access the Internet

• Sign up as a CANON iMAGE

GATEWAY member

• Configure the camera for Web

service access

• Set up devices supporting DLNA

and a wireless LAN access point

• Connect a media player to a TV set

Infrastructure mode*2Infrastructure mode*2

• Send images to Web services

• Send Emails to your acquaintances View images on the camera by

operating the media player

CANON iMAGE GATEWAY Web services are not supported in certain

countries and areas. For information on countries and areas supporting

CANON iMAGE GATEWAY services, refer to the Canon Web site

(http://canon.com/cig).

Settings for “Send images to a Web service” may not be performed from

a computer in certain countries and areas.

Setup

Connection

method

Now you

can...

COPY

In this manual, the term “wireless LAN” is used as a general term for

Wi-Fi and Canon’s original wireless communication functions.

The term “access point” indicates wireless LAN terminals (wireless

LAN access points or wireless LAN adapters) that relay wireless

LAN connection.

Brackets [ ] indicate buttons or icon names or other software

elements displayed on the computer screen. Brackets also indicate

camera menu items.

The ** (numbers) for “(p.**)” in this manual indicate reference page

numbers for more information.

Sections of this manual labeled with the following symbols contain

particular types of information as described below.

Warnings to prevent potential problems during operation.

Additional information provided to supplement the content about

basic operations.

Conventions Used in This Manual

Windows is a trademark or registered trademark of Microsoft Corporation in

the United States and other countries.

Macintosh is a registered trademark of Apple Inc. in the United States and

other countries.

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of

the Wi-Fi Alliance.

WPS used on camera settings screens and in this manual stands for Wi-Fi

Protected Setup.

UPnP is a trademark of the UPnP Implementers Corporation.

All other corporate and product names and trademarks mentioned in this

manual are the property of their respective owners.

Note that Canon cannot be held liable for any loss or damage from erroneous

wireless LAN settings for using the camera. In addition, Canon cannot be held

liable for any other loss or damage caused by use of the camera.

COPY

Chapters

Introduction 2

Basic Settings for Wireless LAN Functions 11

Transferring Images Between Cameras 19

Connecting to a Smartphone - 1 31

Printing Images Using a Wi-Fi Printer - 1

Using a Wi-Fi Wireless LAN Access Point 55

Connecting to a Smartphone - 2 75

Printing Images Using a Wi-Fi Printer - 2

Remote Operation Using EOS Utility 93

Sending Images to a Web Service 103

Viewing Images Using a Media Player 131

Using Quick Control to Connect to a Wireless LAN

139

Managing Settings 145

Troubleshooting Guide 151

Reference 169

COPY

Introduction 2

What You Can Do Using the Wireless LAN Functions..................... 2

Wi-Fi Function Flowchart.................................................................. 4

Conventions Used in This Manual.................................................... 6

Chapters........................................................................................... 7

Basic Settings for Wireless LAN Functions 11

Registering a Nickname ................................................................. 12

Basic Operation and Settings......................................................... 15

Transferring Images Between Cameras 19

Selecting the Connection Destination ............................................ 20

Sending Images ............................................................................. 22

Reconnecting ................................................................................. 26

Registering Multiple Connection Settings....................................... 27

Changing Setting Names ............................................................... 28

Connecting to a Smartphone - 1 31

Preparation..................................................................................... 32

Using Camera Access Point Mode to Establish a Connection....... 33

Operating the Camera Using a Smartphone.................................. 37

Reconnecting ................................................................................. 39

Specifying Viewable Images .......................................................... 40

Registering Multiple Connection Settings....................................... 43

Printing Images Using a Wi-Fi Printer - 1 45

Using Camera Access Point Mode to Establish a Connection....... 46

Printing........................................................................................... 50

Reconnecting ................................................................................. 51

Registering Multiple Connection Settings....................................... 52

Contents

COPY

Contents

Using a Wi-Fi Wireless LAN Access Point 55

Checking the Type of Access Point................................................56

Easy Connection via WPS (PBC Mode).........................................57

Easy Connection via WPS (PIN Mode)...........................................62

Manual Connection by Searching Networks...................................67

Connecting to a Smartphone - 2 75

Using Infrastructure Mode to Establish a Connection.....................76

Operating the Camera Using a Smartphone...................................78

Reconnecting..................................................................................80

Specifying Viewable Images...........................................................81

Registering Multiple Connection Settings.......................................84

Printing Images Using a Wi-Fi Printer - 2 87

Using Infrastructure Mode to Establish a Connection.....................88

Printing............................................................................................90

Reconnecting..................................................................................91

Registering Multiple Connection Settings.......................................92

Remote Operation Using EOS Utility 93

Configuring EOS Utility Communication Settings...........................94

Using EOS Utility ............................................................................98

Reconnecting..................................................................................99

Registering Multiple Connection Settings.....................................100

Sending Images to a Web Service 103

Preparation ...................................................................................104

Checking the Type of Access Point..............................................106

Easy Connection via WPS (PBC Mode).......................................107

Easy Connection via WPS (PIN Mode).........................................111

COPY

Contents

Manual Connection by Searching Networks ................................ 115

Sending Images to a Web Service............................................... 120

Reconnecting ............................................................................... 126

Registering Multiple Connection Settings..................................... 127

Viewing Images Using a Media Player 131

Configuring Media Player Communication Settings..................... 132

Displaying Images on a TV set..................................................... 133

Reconnecting ............................................................................... 135

Registering Multiple Connection Settings..................................... 136

Using Quick Control to Connect to a Wireless LAN 139

Connecting from Quick Control .................................................... 140

Connecting from a Playback Screen............................................ 141

Managing Settings 145

Checking or Changing Settings.................................................... 146

Clearing Wireless LAN Settings ................................................... 149

Troubleshooting Guide 151

Responding to Error Messages.................................................... 152

Troubleshooting Guide................................................................. 163

Wireless LAN Notes ..................................................................... 164

Checking Network Settings .......................................................... 166

Reference 169

Specifications ............................................................................... 170

Index............................................................................................. 171

COPY

Otros manuales para EOS 70D

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Canon

Canon

Canon 3235B001 Manual de usuario

Canon

Canon DIGITAL IXUS 400 Manual de instrucciones

Canon

Canon PowerShot G9 Manual de usuario

Canon

Canon POWERSHOT SD4500 IS Manual de usuario

Canon

Canon WP-Dc22 Manual de usuario

Canon

Canon EOS 7D HDMI Manual de usuario

Canon

Canon PowerShot SX230 HS Manual de usuario

Canon

Canon EOS REBEL T6i Guía de instalación

Canon

Canon EOS-1D C Manual de usuario

Canon

Canon PowerShot SX500 IS Manual de usuario

Canon

Canon PowerShot A410 Guía del usuario

Canon

Canon PowerShot G12 Manual de usuario

Canon

Canon IXUS 30 Manual de usuario

Canon

Canon 0206b003 - EOS Digital Rebel XT Camera SLR Manual de usuario

Canon

Canon PowerShot SX620 HS Manual de usuario

Canon

Canon EOS 6D Manual de usuario

Canon

Canon Powershot S2 IS Manual de usuario

Canon

Canon PowerShot A5 Manual de usuario

Canon

Canon DIGITAL IXUS 430 Manual de instrucciones

Canon

Canon SD550 - PowerShot Digital ELPH Camera Guía del usuario

Canon

Canon PowerShot G1X Mark II Manual de usuario

Canon

Canon VI-T Manual de usuario

Canon

Canon SD400 - PowerShot Digital ELPH Camera Manual de usuario

Canon

Canon EOS 5D Mark II Manual de instalación y operación

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Nikon

Nikon Coolpix 100 Manual de usuario
