Canon EOS 1200D Guía de instalación

This basic manual covers only the most basic operations.

For other features and more details, see the

Camera Instruction Manual pdf le on the DVD-ROM.

Basic Instruction Manual

CEL-SV1LA211 © CANON INC. 2014 PRINTED IN THE EU

The descriptions in this Instruction Manual are current as of October 2014. For

information on the compatibility with any products introduced after this date,

contact any Canon Service Center. For the latest version Instruction Manual,

refer to the Canon Web site.

CANON INC.

30-2 Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan

Europe, Africa & Middle East

CANON EUROPA N.V.

PO Box 2262, 1180 EG Amstelveen, The Netherlands

For your local Canon ofce, please refer to your warranty card or to www.canon-europe.com/Support

The product and associated warranty are provided in European countries by Canon Europa N.V.

ENGLISH

The EOS 1200D is a digital single-lens reflex camera featuring a

fine-detail CMOS sensor with approx. 18.0 effective megapixels, DIGIC

4, high-precision and high-speed 9-point AF, approx. 3.0 fps continuous

shooting, Live View shooting, and Full High-Definition (Full HD) movie

shooting.

Before Starting to Shoot, Be Sure to Read the Following

To avoid botched pictures and accidents, first read the “Safety

Precautions” (p.100-102) and “Handling Precautions” (p.12, 13).

Refer to This Manual While Using the Camera to Further

Familiarize Yourself with the Camera

While reading this manual, take a few test shots and see how they

come out. You can then better understand the camera.

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images or copyrighted music and images with music in the memory

card for anything other than private enjoyment. Also be aware that

certain public performances, exhibitions, etc., may prohibit photography

even for private enjoyment.

Introduction

Before starting, check that all the following items have been included

with your camera. If anything is missing, contact your dealer.

* Battery Charger LC-E10 or LC-E10E is provided. (The LC-E10E comes with a

power cord.)

The Instruction Manual and DVD/CD-ROMs provided are listed on the next

page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, lens instruction manuals may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack LP-E10

(with protective cover)

Battery Charger

LC-E10/LC-E10E*

Wide Strap

Camera

(with eyecup and body cap)

Interface Cable

The instruction manual consists of a booklet and PDF manuals in

electronic form (provided on the DVD-ROM).

EOS Camera Instruction Manuals Disk DVD-ROM

Contains the following PDF manuals:

• Instruction Manual (Detailed version)

• Software Instruction Manuals for the software on the

EOS Solution Disk.

* Instructions for viewing the Instruction Manuals on the DVD-ROM are on page

91-92.

EOS Solution Disk

Contains various software. For outlines and installation

procedure of the software, see pages 95-97.

Instruction Manual and DVD/CD-ROMs

Basic Instruction

Manual

(this booklet)

The Basic Instruction Manual explains the basic procedures and features. For

detailed instructions, see the EOS Camera Instruction Manuals Disk (DVD-ROM).

EOS Camera Instruction Manuals Disk XXX

XXXXX

CEL-XXX XXX

EOS Solution Disk XXX

CEL-XXX XXX

Windows XXX XXX

Mac OS X XXX XXX

XXXXX

The camera can use the following cards regardless of capacity: If the

card is new or was previously formatted by another camera or

computer, it is recommended that you format the card with this

camera (p.42).

• SD memory cards

• SDHC memory cards

• SDXC memory cards

When shooting movies, use a large-capacity SD card rated SD

Speed Class 6 “ ” or higher.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

If you want to shoot still photos while shooting a movie, you will need

an even faster card.

To check the card’s reading/writing speed, refer to the card

manufacturer’s website.

Compatible Cards

Cards that Can Record Movies

The camera can use UHS-I cards, but since it is not compatible with the

UHS-I standard, reading/writing speeds will be equivalent to SD Speed

Class 10 at most.

In this manual, “card” refers to SD memory cards, SDHC memory

cards, and SDXC memory cards.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

Quick Start Guide

1Insert the battery (p.24).

To charge the battery, see page 22.

2Insert a card (p.24).

With the card’s label facing toward

the back of the camera, insert it into

the card slot.

3Attach the lens (p.32).

Align the lens’s white or red index

with the camera’s index in the

matching color.

4Set the lens focus mode switch

to <AF> (p.32).

5Set the power switch to <1>

(p.27).

When the LCD monitor displays the

date/time/zone setting screens, see

page 29.

White index Red index

Quick Start Guide

6Set the Mode Dial to <A>

(Scene Intelligent Auto) (p.48).

All the necessary camera settings

will be set automatically.

7Focus on the subject (p.37).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway, and

the camera will focus on the subject.

If necessary, the built-in flash will be

raised automatically.

8Take the picture (p.37).

Press the shutter button completely

to take the picture.

9Review the picture.

The image just captured will be

displayed for 2 sec. on the LCD

monitor.

To display the image again, press

the <x> button (p.65).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.67).

To view the images captured so far, see “Image Playback” (p.65).

To delete an image, see “Erasing Images” (p.88).

Icons in this Manual

<6> : Indicates the Main Dial.

<W><X><Y><Z> : Indicates the <S> cross keys on the top,

bottom, left, and right.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that the corresponding function

remains active for 4 sec., 6 sec., 10 sec., or 16

sec. respectively after you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button and changing the setting.

M: Shown at the upper right of a page title to indicate a

function that is available only in the Creative Zone modes

(p.18).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Problem-solving advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is <1> (p.27).

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-55mm f/3.5-5.6 IS II lens as an example.

Conventions Used in this Manual

Introduction 2

Item Check List .................................................................................3

Instruction Manual and DVD/CD-ROMs ...........................................4

Compatible Cards .............................................................................5

Quick Start Guide..............................................................................6

Conventions Used in this Manual .....................................................8

Handling Precautions......................................................................12

Nomenclature..................................................................................14

Getting Started 21

Charging the Battery .......................................................................22

Installing and Removing the Battery and Card ...............................24

Turning on the Power......................................................................27

Setting the Date, Time, and Zone...................................................29

Selecting the Interface Language ...................................................31

Attaching and Detaching a Lens.....................................................32

Lens Image Stabilizer .....................................................................35

Basic Operation ..............................................................................36

QQuick Control for Shooting Functions........................................38

3Menu Operations ..................................................................40

Formatting the Card........................................................................42

Switching the LCD Monitor Display.................................................44

Feature Guide .................................................................................45

Contents

Basic Shooting and Image Playback 47

AFully Automatic Shooting (Scene Intelligent Auto) ................... 48

AFull Auto Techniques (Scene Intelligent Auto) ......................... 51

7Disabling Flash......................................................................... 53

CCreative Auto Shooting ............................................................ 54

2Shooting Portraits...................................................................... 57

3Shooting Landscapes............................................................... 58

4Shooting Close-ups................................................................... 59

5Shooting Moving Subjects........................................................ 60

6Shooting Night Portraits ............................................................ 61

QQuick Control ............................................................................ 63

xImage Playback........................................................................ 65

Shooting with the LCD Monitor (Live View Shooting) 67

AShooting with the LCD Monitor ................................................ 68

Using AF to Focus (AF Method)..................................................... 71

Shooting Movies 77

kShooting Movies....................................................................... 78

Setting the Movie Recording Size .................................................. 80

Otros manuales para EOS 1200D

Tabla de contenidos

Otros manuales de Cámara digital de Canon

Canon

Canon PowerShot A3200 IS Manual de usuario

Canon

Canon PowerShot SX60 HS Manual de instrucciones

Canon

Canon EOS-1D Mark II Digial Manual de usuario

Canon

Canon PowerShot ELPH 150 IS Manual de usuario

Canon

Canon 4342B001 Manual de usuario

Canon

Canon PowerShot SD430 DIGITAL ELPH WIRELESS Manual de usuario

Canon

Canon POWERSHOT SD3500IS Manual de usuario

Canon

Canon PELLIX QL Manual de usuario

Canon

Canon 8861A003 - EOS Digital Rebel Camera SLR Instrucciones de montaje

Canon

Canon IXY DIGITAL Manual de instrucciones

Canon

Canon Digital IXUS 500HS Manual de usuario

Canon

Canon EOS-1Ds Mark III Manual de usuario

Canon

Canon Powershot SD40 Manual de usuario

Canon

Canon EOS 70D Manual de usuario

Canon

Canon EOS 10D Digital Manual de usuario

Canon

Canon EOS REBEL T6i Especificaciones técnicas

Canon

Canon PowerShot A95 Manual de usuario

Canon

Canon IXUS 1100 HS Manual de usuario

Canon

Canon PowerShot SD100 Manual de usuario

Canon

Canon EOS M50 Manual de usuario

Canon

Canon EO-1Ds Manual de instrucciones

Canon

Canon EOS REBEL T2I Manual de usuario

Canon

Canon POWERSHOT A85 Manual de usuario

Canon

Canon PowerShot A590 IS Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Nikon

Nikon Coolpix 100 Manual de usuario
