Canon PIXMA MG3120 Manual de usuario

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MG3120

Macintosh OS

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MG3120

Macintosh OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Installing the Drivers & Software 5

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures, there

is a risk of disclosing data such as your personal information to a third party.

•If an error message appears or if you have trouble with the network

connection, refer to the printed manual: Network Setup Troubleshooting.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection," which establishes a direct wireless connection between

the computer and printer without using an access point, is not supported.

A router or access point is required for your printer to be used on a wireless

network.

Software Installation

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of application

software to be installed.)

Installing the Drivers & Software

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

<< Previous Next >>

Installing the PIXMA MG3120 on Your Wireless Network

If you are installing your printer on your network for the first time, a step-by-step walk through of the wireless setup is built in to the installation

routine of the software that shipped with your PIXMA.

*Insert the Setup CD-ROM that came with your printer into your CD-ROM drive and proceed through the easy to follow instructions.

*If you don’t have or cannot use the Setup CD-ROM, you can still install the printer using a downloaded file. Click here for information.

Be sure to select Wireless Connection on the Connection Method Selection screen (1-2).

Installing the Drivers & Software

<< Previous Next >>

Continue carefully following the Printer Setup instructions (Steps 2-1 through 2-3) until the Setup Procedure Selection screen (3-1)

appears. This is shown on the next page.

Installing the Drivers & Software

<< Previous Next >>

On the Setup Procedure Selection screen (3-1) screen, select Wireless Setup Using the USB Cable. This is the recommended setup method.

You will need to use the supplied USB cable

Continue to follow any on-screen instructions until the Software Installation List appears. This screen is shown on the next page

Installing the Drivers & Software

<< Previous Next >>

On the Software Installation List select any additional* software to install and click Next.

*MP Drivers is required for installation and cannot be deselected. In addition, we recommend installing MP Navigator EX and Easy-

PhotoPrint EX in order to take full advantage of your printer’s features.

*If you are using the downloaded ‘Mini Master setup’ file to install the printer, only the MP Drivers will be installed. Additional software

can be downloaded separately. The software can be found in the Software section of Drivers & Software (the same page where you

downloaded the Mini Master setup file)

Installing the Drivers & Software

<< Previous Next >>

The drivers and software will install. Continue to follow the on-screen instructions.

Click Next on the Set Up New Printer window, then connect the supplied USB cable between the printer and computer and click Next

on the Connect Cable screen..

Installing the Drivers & Software

<< Previous Next >>

If the Access Points screen appears:

Select the Access Point to connect to, enter the Network Key (password) and click Connect.

*For details on how to check the Access Point name/network name (SSID) and network key, refer to the manual supplied

with your access point or contact its manufacturer.
