INSTRUCTION MANUAL

CM 21

PYRANOMETER

WARRANTY AND ASSISTANCE

This equipment is warranted by CAMPBELL SCIENTIFIC (CANADA) CORP. (“CSC”) to

be free from defects in materials and workmanship under normal use and service for

twelve (12) months from date of shipment unless specified otherwise. ***** Batteries

are not warranted. ***** CSC's obligation under this warranty is limited to repairing or

replacing (at CSC's option) defective products. The customer shall assume all costs of

removing, reinstalling, and shipping defective products to CSC. CSC will return such

products by surface carrier prepaid. This warranty shall not apply to any CSC products

which have been subjected to modification, misuse, neglect, accidents of nature, or

shipping damage. This warranty is in lieu of all other warranties, expressed or implied,

including warranties of merchantability or fitness for a particular purpose. CSC is not

liable for special, indirect, incidental, or consequential damages.

Products may not be returned without prior authorization. To obtain a Return

Merchandise Authorization (RMA), contact CAMPBELL SCIENTIFIC (CANADA) CORP.,

at (780) 454-2505. An RMA number will be issued in order to facilitate Repair Personnel

in identifying an instrument upon arrival. Please write this number clearly on the outside

of the shipping container. Include description of symptoms and all pertinent details.

CAMPBELL SCIENTIFIC (CANADA) CORP. does not accept collect calls.

Non-warranty products returned for repair should be accompanied by a purchase order to

cover repair costs.

IMPORTANT USER INFORMATION

Reading this entire manual is recommended for full

understanding of the use of this product.

The exclamation mark within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance instructions in the

literature accompanying the instrument.

Should you have any comments on this manual we will be pleased to receive

them at: Kipp & Zonen B.V.

Röntgenweg 1 2624 BD Delft

P.O. Box 507 2600 AM Delft

Holland

Phone +31 (0)15 2698000

Fax +31 (0)15 2620351

Email info.hol[email protected]

Kipp & Zonen reserve the right to make changes to the specifications without

prior notice.

WARRANTY AND LIABILITY

Kipp & Zonen guarantees that the product delivered has been thoroughly

tested to ensure that it meets its published specifications. The warranty

included in the conditions of delivery is valid only if the product has been

installed and used according to the instructions supplied by Kipp & Zonen.

Kipp & Zonen shall in no event be liable for incidental or consequential

damages, including without limitation, lost profits, loss of income, loss of

business opportunities, loss of use and other related exposures, however

caused, arising from the faulty and incorrect use of the product.

User made modifications can affect the validity of the CE declaration.

retrieval system or transmitted in any form or by any means, without

permission in written form from the company.

DECLARATION OF CONFORMITY

According to EC guideline 89/336/EEC 73/23/EEC

We Kipp & Zonen B.V.

Röntgenweg 1

2624 BD Delft

Declare under our sole responsibility that the product

Type: CM 21

Name: Pyranometer

To which this declaration relates is in conformity with the following standards

Imissions EN 50082-1 Group standard

Emissions EN 50081-1 Group standard

EN 55022

Safety standard IEC 1010-1

Following the provisions of the directive

B.A.A Dieterink

President

KIPP & ZONEN B.V.

TABLE OF CONTENTS

IMPORTANT USER INFORMATION 3

DECLARATION OF CONFORMITY 4

TABLE OF CONTENTS 5

1. GENERAL INFORMATION 7

1.1 INTRODUCTION 7

1.2 PHYSICAL PRINCIPLES OF THE PYRANOMETER 8

1.2.1 Zero offsets 9

1.2.3 Directional error 10

1.2.4 Low temperature dependency of sensitivity 11

2TECHNICAL DATA 13

2.1 SPECIFICATIONS OF CM 21 PYRANOMETER ACCORDING

TO ISO 9060 LISTING 13

2.2 ACCURACY 16

3INSTALLATION 19

3.1 DELIVERY 19

3.2 MECHANICAL INSTALLATION 20

3.2.1 Installation for measurement of global radiation 20

3.2.2 Installation for measurement of solar radiation on inclined surfaces 23

3.2.3 Installation for measurement of reflected global radiation 24

3.2.4 Installation for measurement of diffuse radiation 25

3.2.5 Installation for measurement of albedo 25

3.2.6 Underwater use 26

3.3 ELECTRICAL CONNECTION 27

4OPERATION 31

5MAINTENANCE 33

TABLE OF CONTENTS

6CALIBRATION 35

6.1 INITIAL CALIBRATION 35

6.2 RECALIBRATION 35

6.3 CALIBRATION PROCEDURE AT KIPP & ZONEN 37

6.3.1 The facility 37

6.3.2 Procedure 37

6.3.3 Calculation 38

6.3.4 Zero offset 38

6.3.5 Traceability to World Radiometric Reference 39

7FREQUENTLY ASKED QUESTIONS (FAQ’s) 41

8TROUBLE SHOOTING 43

9PART NUMBERS / SPARE PARTS / OPTIONS 45

APPENDIX I CLASSIFICATION ACCORDING TO WMO GUIDE 1996 47

APPENDIX II RADIOMETRIC LEVELING 49

APPENDIX III LIST OF WORLD AND REGIONAL

RADIATION CENTRES 51

APPENDIX IV PYRANOMETER MEASUREMENT REPORT 53

APPENDIX V THERMISTOR SPECIFICATIONS 55

APPENDIX VI PT-100 SPECIFICATIONS 57

APPENDIX VII RECALIBRATION SERVICE 59

1. GENERAL INFORMATION

1.1 INTRODUCTION

The CM 21 pyranometer is designed for measuring the irradiance (radiant-

flux, Watt/m2) on a plane surface, which results from the direct solar

radiation and from the diffuse radiation incident from the hemisphere above.

CM 21 is a high precision pyranometer with strictly selected domes. Because

of the high optical quality of these domes the directional error is reduced to

less than 10 W/m2.

The special features of the CM 21 are:

•High sensitivity, which could result in lower specifications for the

data acquisition system.

•Low impedance, which reduces sensitivity for interference and

noise.

•Low temperature response, which is an advantage when working

under extreme climatological conditions.

•Low non-linearity.

Like the CM 11 pyranometer, the CM 21 complies with the specifications for

the best of three classes, “High quality”, as defined in the 'Guide to

meteorological Instruments and Methods of Observation', sixth edition, 1996,

of the World Meteorological

GENERAL INFORMATION

Organisation (*WMO) - Geneva - Switzerland. Some specifications of the

CM 21 are twice as good as required.

For measuring the diffuse component of solar radiation only, the direct solar

component can be shielded semi-automatically from the pyranometer by the

Kipp & Zonen shadow ring CM 121. Fully automatic shielding can be done

with the 2AP tracker with shading device.

* The WMO classification is adapted from the international standard ISO 9060 (1990).

Herein “high quality“ class is referred to as “secondary standard”.

1.2 PHYSICAL PRINCIPLES OF THE PYRANOMETER

The pyranometer CM 21 is provided with a thermal detector. This type of

detector responds to the total power absorbed and theoretically it is non-

selective as to the spectral distribution of the radiation. This implies that the

naked thermal detector is also sensitive to long wave infrared radiation

(thermal radiation λ> 3000 nm) from the environment. (e.g. the inner dome)

The radiant energy is absorbed by a black painted disk. The heat generated

flows through a thermal resistance to the heatsink (the pyranometer body).

The temperature difference across the thermal resistance of the detector is

converted into a voltage.

The rise of temperature is easily affected by wind, rain and thermal radiation

losses to the environment ('cold' sky). Therefore the detector is shielded by

two glass domes. These domes allow equal transmittance of the direct solar

component for every position of the sun on the celestial sphere. A dessicator

in the body prevents dew on the inner side of the domes, which can cool

down considerably on clear windless nights.

When the pyranometer is illuminated a temperature difference arise between

the centre and the border of the black absorber. Natural convection inside

the inner dome due to this temperature difference is small and therefore

tilting the CM 21 causes no significant change of sensitivity.

Figure 1 Construction details of a CM 21 pyranometer

1.2.1 Zero offsets

Zero offset type B

Heat flows in the sensing element e.g. due to rising or falling body

temperature normally cause a spurious voltage., called zero offset. To

compensate for this offset, a second non-illuminated element is installed, in

which the same heat flow will arise. By anti-series arrangement of both

elements the spurious voltage is cancelled out greatly. The white plastic

screen reduces the body temperature variations due to solar radiation and

(cold) rain showers.

Zero offset type A

This zero offset is present when there is a temperature difference between

the inner dome and the cold junctions of the sensor.

In practice a zero offset will be present when there is a clear sky. Because of

the low effective sky temperature (<0ºC) the earth surface emits roughly 100

W/m2longwave infrared radiation upwards. The outer glass dome of a

pyranometer also has this emission and is cooling down several degrees

below air temperature (the emissivity of glass for the particular wavelength

GENERAL INFORMATION

region is nearly 1). The emitted heat is extracted from the body (by

conduction in the dome), from the air (by wind) and from the inner dome

(through infrared radiation). The inner dome is cooling down too and will

extract heat from the body by conduction and from the sensor by the net

infrared radiation again. The latter heat flow is opposite to the heat flow from

absorbed solar radiation and causes the well known zero depression at

night. This negative zero offset is also present on a clear day, however,

hidden in the solar radiation signal. Because the temperature difference

between the body and the (clear) sky is higher during day time, the zero-

offset will also be higher.

During indoor measurements with a solar simulator, the inner dome can

become warmer than the pyranometer body due to net thermal radiation

from the lamp housing. A positive zero offset type A is the result.

Zero offset type A can be checked by placing a light and IR reflecting cap

over the pyranometer. The response to solar radiation will decay

with a time constant (1/e) of 5 s, but the dome temperature will go to

equilibrium with a time constant of several minutes. So after half a

minute the remaining signal represents mainly zero offset type A.

Good ventilation of domes and body is the solution to reducing zero offsets

even further. Kipp & Zonen advises the CV 2 for optimal ventilation and

suppression of zero offset type A.

1.2.3 Directional error

The directional error is an individual feature and depends on imperfections of

the glass domes, angular reflection properties of the black paint and

tolerances on the pyranometer construction. The directional error is a

combination of the error in zenith and azimuth directions.

This Kipp & Zonen CM 21 pyranometer is manufactured with great care.

Each pyranometer is constructed with selected glass domes. The glass

domes are matched and positioned with high precision.

Tabla de contenidos

Otros manuales de Instrumento de medición de Campbell

Campbell

Campbell cs215 Manual de usuario

Campbell

Campbell WindSonic Manual de usuario

Campbell

Campbell CMP6-L Manual de usuario

Campbell

Campbell CS110 Manual de usuario

Campbell

Campbell CR10X Manual de usuario

Campbell

Campbell CSAT3 Manual de usuario

Campbell

Campbell SR30 Manual de usuario

Campbell

Campbell SN500SS Manual de usuario

Campbell

Campbell EPPLEY PSP Manual de usuario

Campbell

Campbell HMP35C Manual de usuario

Campbell

Campbell 109B Manual de usuario

Campbell

Campbell HMP45C Manual de usuario

Campbell

Campbell Bowen Ratio Instrumentation Manual de usuario

Campbell

Campbell TGA200 Manual de usuario

Campbell

Campbell Wind Monitor Series Manual de usuario

Campbell

Campbell LI200S-LC Manual de usuario

Campbell

Campbell TEMPERATURE PROBE 109SS Manual de usuario

Campbell

Campbell LI200RX Manual de usuario

Campbell

Campbell MS-80 Manual de usuario

Campbell

Campbell CS525 Manual de usuario

Campbell

Campbell CS616 Manual de usuario

Campbell

Campbell CSAT3B Manual de usuario

Campbell

Campbell NR-LITE2 Manual de usuario

Campbell

Campbell 108 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
