CAMBRIONIX PD-Sync4 Manual de usuario

PDSync-C4

User Manual

PDSync-C4 Page 1 of 43

1. Table of Contents

1. Table of Contents 1

2. Your PDSync-C4 at a glance 3

2.1. Key Features 3

3. Safety 4

3.1. Signal word panel 4

3.2. Safety alert symbol 4

3.3. Pictograms 5

3.4. Product modification 5

3.5. Power supply 6

3.6. Storage and Installation 6

3.7. Cleaning your PDSync-C4 7

4. Getting Started 9

4.1. Unpacking your product 9

4.2. What's Included 9

4.3. Consumables and Placing Orders 9

4.4. Connecting to the mains 9

4.5. Connecting to a Host 10

4.6. Connecting devices to your PDSync-C4 10

4.7. Charging 10

4.8. Registration 11

4.9. Help and Support 11

5. Using your PDSync-C4 12

5.0.1 Port LED States 12

5.0.2 Fan Behaviour 12

5.1. Using without connecting to a host 12

5.2. Using when connected to a host 12

5.2.1 Connecting the Hub to a host computer 12

5.2.2 Charging 12

5.2.3 Data Transfer 13

5.2.4 Communication Interface and Protocol 13

5.3. Scalability 15

5.4. Managing Ports & Your PDSync-C4 16

5.4.1 Port Modes 16

5.4.2 Switching port modes 16

5.4.3 Charging Profiles 16

5.4.4 Firmware 16

6. Software 19

6.0.1 Installing Software 19

6.0.2 Cambrionix Connect 19

6.0.3 Cambrionix Hub API 21

PDSync-C4 Page 2 of 43

6.0.4 Updating Software 21

6.0.5 Removing Software 22

6.0.6 Command Line Instructions (CLI) 23

7. Product Specifications 24

7.1. Features 24

7.2. PDS-C4 Specifications 24

7.3. Power Specifications 25

7.4. Port Specifications 27

7.5. Drawings 28

7.6. Product Label 28

7.7. Hub Architecture 29

8. Troubleshooting 31

8.1. Common troubleshooting tips 31

8.2. Logging through Cambrionix Connect 31

8.3. Hardware Failure 32

8.4. Device connection 32

8.5. Hub connection issues 33

8.6. Using with a headless system 34

8.7. Software troubleshooting 34

9. Returns and Damaged Products 36

9.1. What if my order arrives with an issue? 36

9.2. What happens after I have requested a Return? 36

10. Compliance and Standards 37

10.1. EU RoHS Compliance 38

10.2. Waste Electrical and Electronic Equipment (WEEE) 39

PDSync-C4 Page 3 of 43

2. Your PDSync-C4 at a glance

The PDSync-C4has been designed primarily for desktop use, being highly compact and quiet. It

provides 60W of charging power to each of its 4 Type-C ports, allowing mobile devices to be charged

quickly, safely and reliably. All ports can be controlled using Cambrionix software to enable charging

and data transfer while monitoring important port and device information.

The PDSync-C4 can charge attached USB devices without using a local computer, and our intelligent

charging algorithm allows almost any device to be charged at its optimum rate (up to 3A). The

firmware can be updated to enable new charging profiles, ensuring the PDSync-C4 can charge the

latest devices. It is ready to charge out-of-the-box and sync devices when attached to a host

computer.

When a local (host) computer is connected, the host can control the operation of the ports using

available software. Device charging and synchronisation can be monitored through

Cambrionix’s Connect App, the Application Programming Interface (API) or Command Line Interface

(CLI). Cambrionix’s free monitoring and control software can be downloaded from

www.cambrionix.com/software

You can download the latest version of this manual and all product user manuals from our website at

the following link. www.cambrionix.com/product-user-manuals

2.1. Key Features

Up To

480 Mbps

per Port

Up To

per Port

Up To

Devices

Transfer Data

Seamlessly Power Scalability

Each high-speed port can

transfer data up to 480

Mbps

Each port can charge

devices up to 3 A at 60

(W)

Up to 16 devices can be

connected at once using

multiple hubs

PDSync-C4 Page 4 of 43

3. Safety

This user manual is for informational purposes only, it contains information for the start-up and

operation of this product. Note: the contents and the product described are subject to change

without notice. To avoid injuries and damage, observe the safety instructions in the user manual.

This manual has been arranged to follow the IEC/ICEE 82079-1 standard. This is to facilitate the easier

understanding and location of information relating to the PDSync-C4. Any errors or omissions can be

reported using our support ticket system (seeHelp and Support). This way, any issues that are

discovered can be acted on quickly and we can update the documentation to reflect this.

Understanding and observing the instructions in this user manual are prerequisites for hazard-free

use and safety during operation. This user manual cannot cover all possible applications. If you would

like additional information or if problems arise that are not sufficiently addressed in this manual,

please ask your distributor or contact us directly using the means preferred, which are located on the

back cover of this manual.

CAUTION

Personal Injury and Damage to the product

Always observe the safety instructions in this user manual

3.1. Signal word panel

Depending on the probability of serious consequences, potential dangers are identified with a signal

word, the corresponding safety colour, and if appropriate, the safety alert symbol.

CAUTION

Indicates a potentially hazardous situation that, if not avoided, may result in moderate or

minor (reversible) injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the

product and its functions, or to property in its proximity.

3.2. Safety alert symbol

Use of the safety alert symbol indicates a risk of injury.

Observe all measures that are marked with the safety alert symbol in order to avoid injury

PDSync-C4 Page 5 of 43

3.3. Pictograms

These symbols will be used throughout this documentation to alert to any potential dangers or any

actions that must be taken.

Warning Signs

Electrical hazard Fire Hazard

Mandatory action signs

Read operating instructions Mandatory regulation

3.4. Product modification

Cambrionix products are designed and manufactured to meet the requirements of UK and

international safety regulations. Modifications to the product could affect safety and render the

product non-compliant with relevant safety standards, resulting in injury or damage to the product.

CAUTION

An electric shock or personal injury may occur

Do not modify the product in any way.

Do not dismantle the product.

Do not open the product

CAUTION

Fire, or personal injury may occur

Do not obstruct air vents on the product.

Do not cover the product in or place near combustible material.

PDSync-C4 Page 6 of 43

CAUTION

Damage to your product may occur

Do not bend or compress any part of the product.

3.5. Power supply

This section describes the safety precautions you must follow when using the external power supply.

CAUTION

An electric shock or personal injury may occur

Do not use a damaged power cord or plug, or a loose power socket.

Do not touch the power plug with wet hands.

Do not allow liquids to come into contact with the unit or power supply.

CAUTION

Damage to your product may occur

Do not short circuit the Power Supply Unit (PSU) supplied with your product.

Do not disconnect the power cord while the product is being used.

Do not bend or pull the power cord with excessive force.

Do not use a power supply that exceeds the power supply specifications

within this manual

3.6. Storage and Installation

This section describes safety precautions you must follow when installing and storing your PDSync-

C4.

CAUTION

An electric shock or personal injury may occur

Do not place the power cord near heat sources.

Connect the plug only to an earthed socket.

PDSync-C4 Page 7 of 43

CAUTION

Damage to your Cambrionix product may occur

Operate the product only in an environment where the ambient

temperature is inside the operating temperature range.

Operate the product only in an environment where the relative humidity is

inside the operating range.

Be careful not to leave the power cord underneath a heavy object.

CAUTION

Overheated power sockets may cause a fire

Do not overload the power socket that your hub is connected to.

Insert the power plug all the way into the socket so that it is not loose.

CAUTION

Overloading the brackets may cause failure

The rack brackets for all our products are not designed to be used in a mobile

application, bracket failure could occur if the units are not supported fully e.g

Shock during road transport.

3.7. Cleaning your PDSync-C4

Cleaning the product is generally not required, although in some instances it may be necessary if

excess dirt/ dust/ hair has accumulated, or if minor liquid spillages have occurred on the module

during operation or storage.

CAUTION

Electric shock or personal injury may occur

If there is a dirt/ spillage over a ventilation slot, external data/ power

connector or product aperture, please remove power from the unit without

touching the liquid and seek advise before reapplying power

PDSync-C4 Page 8 of 43

lEnsure that the product is switched off and the power cord is removed from the product. Hold

the power cable by the plug and do not touch either the plug or the power cord with wet or

damp hands as an electrical shock may result

lWipe the product with a clean, dry and soft cloth. Do not use detergents which contain alcohol,

solvent or surface-active agents. Do not spray water or detergent directly onto the product

lMildly dampen a soft and dry cloth in water and wring thoroughly to clean the product as

required

lDry the product thoroughly once the cleaning has finished

lReconnect the power cord and use your product as advised once cleaning is complete

PDSync-C4 Page 9 of 43

4. Getting Started

This manual provides a reference for end-users installing for the first time and using their hub

afterwards. As well as a guide for product safety-related information.

The PDSync-C4 is intended to be used in an indoor static environment in which the environment falls

within the tested specifications to provide charge, sync and management functionality. Please see

the Product Specifications section of this manual for information on the environment specifications.

4.1. Unpacking your product

When you have received your product, please check the packing slip inside the box to ensure all

contents and quantities are correct before opening. This is to avoid retesting and repackaging any

items that are not required.

When opening the packaging, use a suitable method to open the box i.e, do not use a knife. This is to

ensure the product is not damaged.

CAUTION

Personal Injury and Damage to the product

There will be a label on the hub advising you to read the User manual before

use. This will need to be removed before use as it may be covering host ports,

vents etc.

4.2. What's Included

lType-C Cable (to provide communication between the host system and hub)

lPDSync-C4 Hub

l2m Mains power cable (Country specified on order including fuse for the UKplugs)

lPower Supply Unit

4.3. Consumables and Placing Orders

If you require any spare parts, such as the power cable or Type-C cable, these can be ordered by

quoting the product part number listed in the Product Specifications.

These can be ordered from the reseller or solution partner you purchased your PDSync-C4 from, or

from Cambrionix directly.

To find one of our partners local to you please visit www.cambrionix.com/partners where you can

learn about the local vendors and distributors that can assist you and find their contact information.

4.4. Connecting to the mains

Connect the Power Supply Unit (PSU) to the hub using the 4-Pin Mini-DIN plug. Connect the power

cable to the PSU. Making sure you adhere to local safety regulations, connect the power cable to the

Otros manuales para PD-Sync4

Tabla de contenidos

Otros manuales de Cambiar de CAMBRIONIX

CAMBRIONIX

CAMBRIONIX PowerPad15C Manual de usuario

CAMBRIONIX

CAMBRIONIX PDS-C4 Manual de usuario

CAMBRIONIX

CAMBRIONIX SyncPad54 Manual de usuario

CAMBRIONIX

CAMBRIONIX ThunderSync3-16 Manual de usuario

CAMBRIONIX

CAMBRIONIX PowerPad15s Manual de usuario

CAMBRIONIX

CAMBRIONIX SyncPad54 Manual de usuario

CAMBRIONIX

CAMBRIONIX TS3-C10 Manual de usuario

CAMBRIONIX

CAMBRIONIX PowerPad15C Manual de usuario

CAMBRIONIX

CAMBRIONIX ThunderSync2-16 Manual de usuario

CAMBRIONIX

CAMBRIONIX PowerPad15s Manual de usuario

CAMBRIONIX

CAMBRIONIX SyncPad54 Manual de usuario

CAMBRIONIX

CAMBRIONIX PD-Sync4 Manual de usuario

CAMBRIONIX

CAMBRIONIX SuperSync15 Manual de usuario

CAMBRIONIX

CAMBRIONIX TS3-C10 Manual de usuario

CAMBRIONIX

CAMBRIONIX PowerPad15s Manual de usuario

CAMBRIONIX

CAMBRIONIX TS3-16 Manual de usuario

CAMBRIONIX

CAMBRIONIX PowerPad15s Manual de usuario

CAMBRIONIX

CAMBRIONIX 8 Series Manual de usuario

CAMBRIONIX

CAMBRIONIX PD-Sync4 Manual de usuario

CAMBRIONIX

CAMBRIONIX MC14-2,4 A Manual de usuario

CAMBRIONIX

CAMBRIONIX PP8S Manual de usuario

CAMBRIONIX

CAMBRIONIX SuperSync15 Manual de usuario

CAMBRIONIX

CAMBRIONIX ThunderSync3-16 Manual de usuario

CAMBRIONIX

CAMBRIONIX ThunderSync3-C10 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
