2.Safety

This user manual is for informational purposes only, it contains information for start-up and

operation of this product. Note: the contents and the product described are subject to change

without notice. To avoid injuries and damage observe the safety instructions of the user

manual.

Understanding and observing the instructions in this user manual are prerequisites for

hazard-free use and safety during operation. This user manual cannot cover all conceivable

applications. If you would like additional information or if problems arise that are not

sufficiently addressed in this manual please ask your distributor or contact us directly using the

means preferred which are located on the back cover of this manual.

Personal Injury and Damage to the product

lObserve the safety instructions in this user manual

2.1.Signal word panel

Depending on the probability of serious consequences, potential dangers are identified with a

signal word, the corresponding safety colour, and if appropriate, the safety alert symbol.

Indicates a potentially hazardous situation which, if not avoided, may result in moderate or

minor (reversible) injury.

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the

product and/ or its functions or of a property in its proximity.

ModIT-Boss Page 4 of 15

2.2.Safety alert symbol

Use of the safety alert symbol indicates a risk of injury.

Observe all measures that are marked with the safety alert symbol in order to

avoid injury

2.3.Pictograms

Warning Signs

Electrical hazard Fire Hazard

Mandatory action signs

Read operating instructions Mandatory regulation

2.4.Product modification

Cambrionix products are designed and manufactured to meet the requirements of UK and

International safety regulations. Modifications to the product could affect safety and render the

product non-compliant to relevant safety standards, which could result in injury or damage to

the product.

Electric shock or personal injury may occur

lDo not modify the product in any way

lDo not dismantle the product

ModIT-Boss Page 5 of 15

Fire or personal injury may occur

lDo not obstruct air vents on the product

lDo not cover the product in combustible material

Damage to your product may occur

lDo not bend or compress any part of the product

2.5.Power supply

This section describes safety precautions you must follow when using the power supply.

Electric shock or personal injury may occur

lDo not use a damaged power cord or plug, or a loose power socket

lDo not touch the power plug with wet hands

lDo not allow liquids to come into contact with the unit or power supply

Damage to your product may occur

lDo not short circuit the Power Supply Unit (PSU) supplied with your

product

lDo not disconnect the power cord while the product is being used

lDo not bend or pull the power cord with excessive force

ModIT-Boss Page 6 of 15

2.6.Storage and Installation

This section describes safety precautions you must follow when installing and storing your

ModIT-Boss.

Electric shock or personal injury may occur

lDo not place the power cord near heat sources

lConnect the plug to an earthed socket

Damage to your Cambrionix product may occur

lOperate the product only in an environment where the ambient

temperature is inside the operating temperature range

lOperate the product only in an environment where the relative humidity is

inside the operating range

lBe careful not to leave the power cord underneath a heavy object

Overheated power sockets may cause a fire

lDo not overload the power socket that your hub is connected to

lInsert the power plug all the way into the socket so that it is not loose

ModIT-Boss Page 7 of 15

3.Getting Started

3.1.What's Included

l2m Mains power cable (Country specified on order)

lModIT-Boss Unit

3.2.Connecting to the mains

Making sure you adhere to local safety regulations, connect the power cable to the socket and

switch the power supply on.

3.3.Registration

You may register your product at www.cambrionix.com to download LiveViewer and our API.

ModIT-Boss Page 8 of 15

3.4.Cleaning your ModIT-Boss

Cleaning the product is generally not required, although in some instances it may be necessary

if excess dirt/ dust/ hair has accumulated, or if minor liquid spillages have occurred on the

module during operation or storage.

Electric shock or personal injury may occur

lIf there is a dirt/ spillage over a ventilation slot, external data/ power

connector or product aperture, please remove power from the unit without

touching the liquid and contact Cambrionix immediately

lEnsure that the product is switched off and the power cord is removed from the product.

Hold the power cable by the plug and do not touch either the plug or the power cord

with wet or damp hands as an electrical shock may result

lWipe the product with a clean, dry and soft cloth. Do not use detergents which contain

alcohol, solvent or surface-active agents. Do not spray water or detergent directly onto

the product

lWet a soft and dry cloth in water and wring thoroughly to clean the product as required

lDry the product thoroughly once the cleaning has finished

lReconnect the power cord and use your product as advised once cleaning and drying is

complete

ModIT-Boss Page 9 of 15

4. Installing Host System

One of the features of the Boss Module is the ability to install a Mac mini inside. This provides

different levels of sophistication to the ability of your device.

There are 8 screws on the underside of the case and 7 on the rear that need to be removed

there are also two pins on each side of the boss unit that will need to be removed.

Remove these using a screwdriver and slide the top of the Boss Module 4 inches, as

demonstrated in the in the graphic below.

The graphic below demonstrates how the product should look at this stage. Notice the

highlighted yellow screws, which should all have been removed at this point

ModIT-Boss Page 10 of 15

With a spanner, undo the highlighted nut below. Once removed, it will allow you to slide the

lid off fully.

Once the lid is completely removed, it will reveal the inside of the product. Next, remove

the screws (highlighted in yellow) in order to remove the Mac mini chassis.

Once you have removed the Mac mini chassis place your Mac mini on the circular mat

(outsides highlighted below). You can then attach the mini Mac to the three wires on the

left.
