SmartSwitch 9000

9F120-08 / 9F122-12 / 9F125-08

Local Management Appendix

Appendix

9F120-08 / 9F122-12 / 9F125-08

Module Speciﬁc Information

Introduction

This appendix contains local management information that is speciﬁc to the

9F120-08, 9F122-12 and 9F125-08 MicroLAN modules.

Default Interface Codes

The Default Interface ﬁeld on the General Conﬁguration Screen allows you to

enter a number (one through three). Each number represents a default interface

for the selected module. The table below lists the numbers you can enter, each

number’s corresponding interface, and a brief description of that interface. The

default for this ﬁeld is NONE, meaning no default interface selected.

Table 1. 9F12x-xx MicroLAN Module Default Interface Codes

Number Interface Description

1 SMB-1 1 mbps System Management Bus

2 SMB-10 10 mbps System Management Bus

3 FNB Flexible Network Bus (dual attached)

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

FNB Resource Conﬁguration Codes

All of the MicroLAN Modules described in this appendix physically attach to the

FNB-1 and the FNB-2 on the SmartSwitch 9000 backplane. By default, the module

inserts into four rings (the primary and secondary rings of the FNB-1 and the

FNB-2). The FNB Resource Conﬁguration Screen allows you to customize this

conﬁguration to your particular needs.

The FNB Resource Conﬁguration Screen allows you to:

• Select the rings (primary or secondary) of each FNB to which the module will

attach

• Determine whether the module will insert into those rings or bypass them

• Select the ring where the MAC will reside

The terms INSERT and BYPASS refer to relays that are located on the module.

INSERT causes a relay to connect the module’s front panel ports to the selected

ring. BYPASS causes a relay to disconnect the module’s front panel ports from the

selected ring.

INSERT:

BYPASS:

The FNB Resource Conﬁguration Screen lists all possible connections a module

can support on the FNB, displays the current connection, and allows you to

change the connection. Table 2 lists and describes the FDDI Connections from

which you can select.

Front FNB Ring

Relay

Panel

Ports

Front

Panel

Ports

FNB Ring

Relay

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes

Conﬁguration

ID FDDI Connections Description

1 FNB 1 Pri. (MAC) Byp. ,

FNB 2 Pri. (No MAC) Byp.

The module is attached, but not inserted, to

the primary ring on the FNB-1. The module is

attached, but not inserted, to the primary ring

on the FNB-2. The MAC resides on FNB-1.

2 FNB 1 Pri. (MAC) Byp. ,

FNB 2 Pri. (No MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned off. The switch that inserts the module

into the FNB-2 is turned on. The MAC resides

on FNB-1.

3 FNB 1 Pri. (MAC) Ins. ,

FNB 2 Pri. (No MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned on. The switch that inserts the module

into the FNB-2 is turned off. The MAC resides

on FNB-1.

4 FNB 1 Pri. (MAC) Ins. ,

FNB 2 Pri. (No MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned on. The switch that inserts the module

into the FNB-2 is turned on. The MAC resides

on FNB-1.

5 FNB 1 Pri. (No MAC) Byp. ,

FNB 2 Pri. (MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned off. The switch that inserts the module

into the FNB-2 is turned off. The MAC resides

on FNB-2.

6 FNB 1 Pri. (No MAC) Byp. ,

FNB 2 Pri. (MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned off. The switch that inserts the module

into the FNB-2 is turned on. The MAC resides

on FNB-2.

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

7 FNB 1 Pri. (No MAC) Ins. ,

FNB 2 Pri. (MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned on. The switch that inserts the module

into the FNB-2 is turned off. The MAC resides

on FNB-2.

8 FNB 1 Pri. (No MAC) Ins. ,

FNB 2 Pri. (MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 primary ring. The switch

that inserts the module into the FNB-1 is

turned on. The switch that inserts the module

into the FNB-2 is turned on. The MAC resides

on FNB-2.

9 FNB 1 Pri. (MAC) Byp. ,

FNB 2 Sec. (No MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

10 FNB 1 Pri. (MAC) Byp. ,

FNB 2 Sec. (No MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

11 FNB 1 Pri. (MAC) Ins. ,

FNB 2 Sec. (No MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

12 FNB 1 Pri. (MAC) Ins. ,

FNB 2 Sec. (No MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes (Continued)

Conﬁguration

ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

13 FNB 1 Pri. (No MAC) Byp. ,

FNB 2 Sec. (MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

14 FNB 1 Pri. (No MAC) Byp. ,

FNB 2 Sec. (MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

15 FNB 1 Pri. (No MAC) Ins. ,

FNB 2 Sec. (MAC) Byp.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

16 FNB 1 Pri. (No MAC) Ins. ,

FNB 2 Sec. (MAC) Ins.

The module is attached to the FNB-1 primary

ring and the FNB-2 secondary ring. The

switch that inserts the module into the FNB-1

is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

17 FNB 1 Sec. (MAC) Byp. ,

FNB 2 Pri. (No MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

18 FNB 1 Sec. (MAC) Byp. ,

FNB 2 Pri. (No MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes (Continued)

Conﬁguration

ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

19 FNB 1 Sec. (MAC) Ins. ,

FNB 2 Pri. (No MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

20 FNB 1 Sec. (MAC) Ins. ,

FNB 2 Pri. (No MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

21 FNB 1 Sec. (No MAC) Byp. ,

FNB 2 Pri. (MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

22 FNB 1 Sec. (No MAC) Byp. ,

FNB 2 Pri. (MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

23 FNB 1 Sec. (No MAC) Ins. ,

FNB 2 Pri. (MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

24 FNB 1 Sec. (No MAC) Ins. ,

FNB 2 Pri. (MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 primary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes (Continued)

Conﬁguration

ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

25 FNB 1 Sec. (MAC) Byp. ,

FNB 2 Sec. (No MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

26 FNB 1 Sec. (MAC) Byp. ,

FNB 2 Sec. (No MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

27 FNB 1 Sec. (MAC) Ins. ,

FNB 2 Sec. (No MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-1.

28 FNB 1 Sec. (MAC) Ins. ,

FNB 2 Sec. (No MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-1.

29 FNB 1 Sec. (No MAC) Byp. ,

FNB 2 Sec. (MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

30 FNB 1 Sec. (No MAC) Byp. ,

FNB 2 Sec. (MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned off. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes (Continued)

Conﬁguration

ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Speciﬁc Information

31 FNB 1 Sec. (No MAC) Ins. ,

FNB 2 Sec. (MAC) Byp.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned off. The

MAC resides on FNB-2.

32 FNB 1 Sec. (No MAC) Ins. ,

FNB 2 Sec. (MAC) Ins.

The module is attached to the FNB-1

secondary ring and the FNB-2 secondary ring.

The switch that inserts the module into the

FNB-1 is turned on. The switch that inserts the

module into the FNB-2 is turned on. The MAC

resides on FNB-2.

Table 2. 9F12x-xx MicroLAN Module FNB Resource Conﬁguration Codes (Continued)

Conﬁguration

ID FDDI Connections Description

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Cabletron Systems

Cabletron Systems

Cabletron Systems MMAC-Plus 9H531-18 Manual de usuario

Cabletron Systems

Cabletron Systems 2E43-51 Manual de usuario

Cabletron Systems

Cabletron Systems 9F122-12 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 6E122 Manual del propietario

Cabletron Systems

Cabletron Systems SmartSwitch 6500 Manual de usuario

Cabletron Systems

Cabletron Systems 9A656-04 Instrucciones de instalación y funcionamiento

Cabletron Systems

Cabletron Systems SmartSwitch 8000 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 8H02-16 Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9H423-26 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch SBU128 Manual de usuario

Cabletron Systems

Cabletron Systems SEH-22 Manual de usuario

Cabletron Systems

Cabletron Systems SMALL OFFICE CyberSwitch 150 Manual de usuario

Cabletron Systems

Cabletron Systems 9A656-04 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS100-8TXUF2 Manual de usuario

Cabletron Systems

Cabletron Systems 7F06-02 FDDI SmartSwitch Manual de usuario

Cabletron Systems

Cabletron Systems FRM Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9G426-02 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ETHERNET ELS10-27 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK 10 ELS10-26 Manual de usuario

Cabletron Systems

Cabletron Systems 7C03 MMAC SmartSWITCH Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK 100 ELS100-16TX Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELH100 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK 100 ELS100-24TX Instrucciones de instalación y funcionamiento

Cabletron Systems

Cabletron Systems Cabletron CyberSWITCH CSX5500 Manual de instrucciones

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
