Cabletron Systems MMAC-M8FNB Manual de usuario

MMAC-M8FNB™

MULTI-MEDIA ACCESS CENTER

OVERVIEW AND SETUP GUIDE

CABLETRON SYSTEMS, P.O. Box 5005, Rochester, N.H. 03866-5005

NOTICE

Cabletron Systems reserves the right to make changes in

speciﬁcations and other information contained in this document

without prior notice.The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is

subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR

ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL

DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO

LOST PROFITS) ARISING OUT OF OR RELATED TO THIS

MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF

CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH

DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03866-5005

Printed in the United States of America

Order number: 9030535-08 December 1995

SPECTRUM

LANVIEW

, and

Multi Media Access Center

are

registered trademarks and

MMAC-M8FNB, MIM,

M8PSM

M8PSM-E

, and

M8PSM-EDC

are trademarks of Cabletron Systems,

Inc.

Ethernet

is a trademark of Xerox Corporation.

IBM

is a registered trademark of International Business Machines

Corporation

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Note

:This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

rules.These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment.This equipment uses, generates, and can

radiate radio frequency energy and if not installed in accordance with

the operator’s manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause interference, in which case the user will be required to

correct the interference at his own expense.

WARNING:

Changes or modifications made to this device which are

not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

DOC NOTICE

This digital apparatus does not exceed the Class A limits for radio

noise emissions from digital apparatus set out in the Radio

Interference Regulations of the Canadian Department of

Communications.

Le Présent appareil numérique n’émet pas de bruits radioélectriques

dépassant les limites applicables aux appareils numériques de la class

A prescrites dans le Règlement sur le brouillage radioélectrique édicté

par le ministère de Communications du Canada.

BABT NOTICE

This device is approved under BABT General Approval No.

NS/G/1234/J/100003 for indirect connection to public

telecommunications systems in the United Kingdom.

iii

VCCI NOTICE

This equipment is in the 1st Class Category (information equipment

to be used in commercial and/or industrial areas) and conforms to the

standards set by the Voluntary Control Council for Interference by

Information Technology Equipment (VCCI) aimed at preventing radio

interference in commercial and/or industrial areas.

Consequently, when used in a residential area or in an adjacent area

thereto, radio interference may be caused to radios and TV receivers,

etc.

Read the instructions for correct handling.

CONTENTS

CHAPTER 1 INTRODUCTION

1.1 USING THIS MANUAL............................................................1-1

1.1.1 Symbols..........................................................................1-2

1.2 USING THE MMAC-M8FNB MANUAL SET..........................1-2

1.3 GETTING HELP........................................................................1-3

1.4 THE MMAC-M8FNB MULTI MEDIA ACCESS CENTER.....1-4

1.5 MMAC-M8FNB FEATURES.....................................................1-5

CHAPTER 2 INSTALLATION REQUIREMENTS AND

SPECIFICATIONS

2.1 SITE GUIDELINES...................................................................2-1

2.2 MMAC-M8FNB CONFIGURATION GUIDELINES...............2-2

2.3 OPERATING SPECIFICATIONS.............................................2-3

2.3.1 Physical Specifications..................................................2-3

2.3.2 Power Supply Requirements........................................2-4

2.3.3 Test Points.....................................................................2-7

2.4 LEDs...........................................................................................2-8

2.5 SAFETY....................................................................................2-12

CHAPTER 3 MMAC-M8FNB SETUP

3.1 UNPACKING THE MMAC-M8FNB.........................................3-1

3.2 SETTING UP THE MMAC-M8FNB.........................................3-2

3.2.1 Rack Mounting the MMAC-M8FNB Chassis..............3-2

3.2.2 Rack Mounting the Cable Tie Tray..............................3-4

3.2.3 Inserting the Fan Tray .................................................3-5

3.2.4 Installing the Power Supply Module............................3-6

3.2.5 Installing the Security Bars.........................................3-9

3.2.6 Powering Up the MMAC-M8FNB..............................3-10

CONTENTS

Page 1-1

CHAPTER 1

INTRODUCTION

The

MMAC-M8FNB™ Multi Media Access Center

offers

maximum ﬂexibility and convenience in the design and operation of

your network.The enclosure provides space for one

Repeater/Management Module and up to seven Media Interface

Modules (MIM™), allowing up to 171 network connections depending

on the Repeater/Management module and the MIMs that have been

installed.

This manual is an installation and reference guide. It lists the

features and options of the MMAC-M8FNB and explains how to

install the fan tray and power supply(ies).You should read through

this manual prior to using the MMAC-M8FNB to gain a full

understanding of the MMAC-M8FNB and its capabilities.

1.1 USING THIS MANUAL

Chapter 1,

Introduction

, discusses the features and capabilities of

the MMAC-M8FNB.

Chapter 2,

Installation Requirements and Speciﬁcations

, lists

the location requirements that must be met before you install the

MMAC-M8FNB on your network.This chapter also includes some

MIM conﬁguration guidelines, environmental guidelines, and

operating speciﬁcations for the MMAC-M8FNB and related Power

Supply Modules (M8PSM™, M8PSM-E™, or M8PSM-EDC™).

Only qualiﬁed personnel should install or service this

unit and its modules!

INTRODUCTION

Page 1-2

Chapter 3,

MMAC-M8FNB Setup

, contains instructions for rack

mounting your MMAC-M8FNB, inserting the fan tray, installing the

power supply(ies), installing the security bars, and powering up the

MMAC-M8FNB.

1.1.1 Symbols

Throughout this manual you will see two symbols which will be used

to call your attention to important safety-related information:

You will also see a third symbol, which will be used to call your

attention to additional information not related to safety:

1.2 USING THE MMAC-M8FNB MANUAL SET

Other manuals have been developed for the Repeater/Management

modules and for each MIM that can be installed in your

MMAC-M8FNB. These manuals explain how to install the individual

CAUTION: when you see this symbol, you will be

provided with special precautionary information th

can help you guard against improper use of your

equipment.

WARNING: when you see this symbol, note that failure

to follow the instructions provided can result in an

electrical safety hazard.

NOTE: the information that follows could help you to

better use and understand your equipment.

NOTE
