Burkert 6027 Manual de usuario

Driftsinstruktion

Manuel d‘utilisation

Operating Instructions

Typ 6027

2/2-way solenoid valve

2/2-vägs magnetventil

Électrovanne 2/2 voies

1 OPERATING INSTRUCTIONS

The operating instructions contain important information.

▶Read the operating instructions carefully and follow the safety instruc-

tions in particular, and also observe the operating conditions.

▶Operating instructions must be available to each user.

▶The liability and warranty for the device are void if the operating instruc-

tions are not followed.

1.1 Symbols

▶Designates an instruction to prevent risks.

→designates a procedure which you must carry out.

Warning of injuries:

DANGER!

Imminent danger. Serious or fatal injuries.

WARNING!

Potential danger. Serious or fatal injuries.

CAUTION!

Danger. Minor or moderately severe injuries.

Warns of damage to property:

NOTE!

2 INTENDED USE

Incorrect use of the solenoid valve Type 6027 can be dangerous

to people, nearby equipment and the environment.

▶The device is designed to control, shut off and meter neutral media up

to a viscosity of 21 mm2/s.

▶Provided the cable plug is connected and installed correctly, e.g. Bürk-

ert Type 2508, the device satisfies protection class IP65 in accordance

with DIN EN 60529 / IEC 60529.

▶Use according to the permitted data, operating conditions and con-

ditions of use specified in the contract documents and operating

instructions.

▶Correct transportation, correct storage and installation and careful use

and maintenance are essential for reliable and problem-free operation.

▶Use the device only as intended.

2.1 Definition of term

In these operating instructions, the term “device” always refers to the

Type 6027.

english

Risk of injury due to malfunction of valves with alternating

current (AC).

Sticking core causes coil to overheat, resulting in a malfunction.

▶Monitor process to ensure function is in perfect working order.

Risk of short-circuit/escape of media through leaking screw joints.

▶Ensure seals are seated correctly.

▶Carefully screw valve and connection lines together.

General hazardous situations.

To prevent injury, ensure that:

▶Do not make any internal or external changes. Ensure that the system

cannot be activated unintentionally.

▶Installation and repair work may be carried out by authorized techni-

cians only and with the appropriate tools.

▶After an interruption in the power supply or pneumatic supply, ensure

that the process is restarted in a defined or controlled manner.

3 BASIC SAFETY INSTRUCTIONS

These safety instructions do not make allowance for any contingencies

and events which may arise during installation, operation and maintenance.

Danger – high pressure.

▶Before loosening the lines and valves, turn off the pressure and

vent the lines.

Risk of electric shock.

▶Before reaching into the system, switch off the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

Risk of burns/Risk of fire if used continuously through hot device

surface.

▶Keep the device away from highly flammable substances and media

and do not touch with bare hands.

english

▶Do not put any loads on the body.

▶For models with ATEX or UL approval follow the safety instructions

in the ATEX manual or on the respective supplementary sheet.

▶The general rules of technology apply to application planning and

operation of the device.

3.1 Warranty

The warranty is only valid if the device is used as intended in accordance

with the specified application conditions.

3.2 Information on the internet

The operating instructions and data sheets for type 6027 can be found

on the internet at:

www.burkert.com Type 6027

4 TECHNICAL DATA

4.1 Operating conditions

The following values are indicated on the type label:

• Voltage (Tolerance ± 10 %) / Current type

• Coil power consumption (active power in W - at operating temp.)

• Pressure range

• Body material: Brass (MS), Stainless steel (VA)

• Sealing material: EPDM, PTFE, FKM, PEEK, NBR

• Port connection

Circuit function 2/2-way valve:

A (NC) B (NO)

Protection class: IP65 in accordance with DIN EN 60529 / IEC

60529 with cable plug, e.g. Bürkert Type 2508

english

4.2 Application conditions

Ambient temperature: max. +55 °C

Permitted medium temperature depending on coil material and sealing

material:

Circuit

function

Coil

material

Frequency Sealing

material

Medium

temperature

Control

function A

(NC)

Polyamide

(AC10)

AC/DC/UC

FKM (FF) -10...+100 °C

Epoxide

FKM (FF) -10...+140 °C

EPDM (AA) -30...+120 °C

NBR (BB) -10...+80 °C

PTFE + PEEK (EP) -40...+180 °C

Control

function B

(NO)

FKM (FF) -10...+100 °C

EPDM (AA) -30...+100 °C

PTFE + PEEK (EP) -40...+100 °C

DC/UC

PTFE + FKM (EF) -10...+140 °C

PTFE + PEEK (EP) -40...+180 °C

EPDM (AA) -30...+120 °C

FKM (FF) -10...+140 °C

CF A (NC) /

CF B (NO) AC/DC/UC PEEK + FKM (TF) -10...+80 °C

Permitted medium temperature and ambient temperature depending on

sealing material:

Temperatures for valves with UL/UR approval

Sealing material

Ambient temperature

EPDM (AA)

PTFE + EPDM (EA)

PTFE + FKM (EF)

PTFE + PEEK (EP)

FKM (FF)

-10...+55 °C

Medium temperature

EPDM (AA) -30...+120 °C

PTFE + EPDM (EA)

PTFE + FKM (EF) -10...+140 °C

PTFE + PEEK (EP) -40...+140 °C

FKM (FF) -10...+140 °C

Operating duration: Unless otherwise indicated on the type label,

the solenoid system is suitable for continuous

operation

english

Important information for functional reliability during continuous

operation: If standstill for a long period at least 1-2 activations

per day are recommended.

Medium: neutral gases and liquids which do not attack the

body material, the inner parts of the valves or the

sealing material. Check resistance in individual

cases (www.burkert.com)

4.3 Conformity

In accordance with the EC Declaration of conformity, Type 6027 is com-

pliant with the EC Directives.

4.4 Standards

The applied standards, which verify conformity with the EC Directives,

can be found on the EC-Type Examination Certificate and / or the EC

Declaration of Conformity.

4.5 Type label

Example:

Type

Circuit function

Orifice

Sealing material

Body material

Id.-Number

Voltage, Frequency,

Power consumption

Port connection,

Operating pressure

english

5 INSTALLATION

5.1 Safety instructions

DANGER!

Risk of injury from high pressure in the equipment.

▶Before loosening the pipes and valves, turn off the pressure and

vent the lines.

Risk of injury due to electrical shock.

▶Before reaching into the device or the equipment, switch off the

power supply and secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

WARNING!

Risk of injury from improper installation.

▶Installation may be carried out by authorized technicians only and

with the appropriate tools.

Risk of injury from unintentional activation of the system and an

uncontrolled restart.

▶Secure system from unintentional activation.

▶Following assembly, ensure a controlled restart.

5.2 Before installation

Installation position: any, actuator preferably upwards.

Procedure:

→Check pipelines for dirt and clean.

→Install a dirt filter before the valve inlet (≤ 0.3 mm).

WARNING!

Medium leaking through damaged connections.

▶Do not damage sealing surfaces of the body connections during

installation.

Danger due to unsuitable screw connections.

▶At high pressures and temperatures ensure that the thread

length (load-bearing thread turns) is adequate for each pairing of

materials.

NOTE!

Caution risk of breakage.

• Do not use the coil as a lever arm.

english

5.3 Installation – body design

Procedure:

→Hold the device with a open-end wrench on the body and screw

into the pipeline.

Valve body must not be installed under tension.

Sealing material must not get into the device.

→Observe direction of flow: from 1 → 2 (from P → A),

or CF B from P → B.

5.4 Installation – flange design

Procedure:

→Loosen nut and remove coil.

→Insert seal into body.

→Screw body onto connection plate.

→Install coil (see chapter „5.6“).

→Observe direction of flow:

from 1 → 2 (from P → A),

or CF B from P → B.

5.5 Electrical connection of the cable plug

WARNING!

Risk of injury due to electrical shock.

▶Before reaching into the system, switch off the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

If the protective conductor is not connected, there is a risk of electric

shock.

▶Always connect protective conductor and check electrical continuity.

Procedure:

→Tighten cable plug (for permitted types see data sheet), observing

max. torque 1 Nm.

→Check that seal is fitted correctly.

→Connect protective conductor and check electrical continuity.

english

Authorized cable plug

e.g. Type 2508

Seal

max. 1 Nm

5.6 Installation of coil

WARNING!

Risk of escape of media.

When a sticking nut is loosened, medium may escape.

▶Do not tighten sticking nut any further.

Risk of injury due to electrical shock.

If the protective conductor contact between the coil and body is

missing, there is danger of electrical shock.

▶During installation insert the plastic ring into the body journal. The

plastic ring must not project over the octagonal nipple.

▶Check protective conductor contact after installing the coil.

Overheating, risk of fire.

If the coil is connected without a pre-installed valve, the coil will overheat

and be destroyed.

▶Connect the coil with a pre-installed valve only.

english

Installation of coil:

Plastic ring

Nut

O-ring

max. 15 Nm

4 x 90°

6 MAINTENANCE, TROUBLESHOOTING

6.1 Safety instructions

WARNING!

Risk of injury from improper maintenance.

▶Maintenance may be carried out by authorized technicians only and

with the appropriate tools.

Risk of injury from unintentional activation of the system and an

uncontrolled restart.

▶Secure system from unintentional activation.

▶Following maintenance, ensure a controlled restart.

6.2 Malfunctions

If malfunctions occur, check whether:

• the device has been installed according to the instructions,

• the electrical and fluid connections are correct,

• the device is not damaged,

• all screws have been tightened,

• the voltage and pressure have been switched on,

• the pipelines are clean.

english

Otros manuales para 6027

Tabla de contenidos

Idiomas:

Otros manuales de Unidad de control de Burkert

Burkert

Burkert 2300 Series Manual de usuario

Burkert

Burkert AirLINE 8652 Manual de usuario

Burkert

Burkert 2006 Manual de usuario

Burkert

Burkert PTB 03 ATEX 1030 X Manual de usuario

Burkert

Burkert 0301 Manual de usuario

Burkert

Burkert 2300 Series Manual de usuario

Burkert

Burkert 6213 Manual de usuario

Burkert

Burkert 2301 Series Manual de usuario

Burkert

Burkert 3281 Manual de usuario

Burkert

Burkert PTB 00 ATEX 2202 X Manual de usuario

Burkert

Burkert 8695 Manual de usuario

Burkert

Burkert 3320 Manual de usuario

Burkert

Burkert 6126 Manual de usuario

Burkert

Burkert 2065 Manual de usuario

Burkert

Burkert 0262 Manual de usuario

Burkert

Burkert 6213 EV Manual de usuario

Burkert

Burkert 2657 Manual de usuario

Burkert

Burkert 0641 Manual de usuario

Burkert

Burkert 5406 Manual de usuario

Burkert

Burkert 2006 Manual de usuario

Burkert

Burkert 6213 Manual de usuario

Burkert

Burkert 2031 Manual de usuario

Burkert

Burkert 6430 Manual de usuario

Burkert

Burkert 3320 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
