Bticino LIVING NOW K4001C Manual de usuario

Cat. No(s): K4001C

Technical data sheet: IDP000271_01-EN Updated: Created: 18/10/2019

1/2

Viale Borri, 231 - 21100 VARESE - Italy

www.bticino.com

Connected 1 way switch

4. CONNECTION

Terminal type: screw

Terminal capacity: 1 x 2.5 mm2- 2 x 1.5 mm2

Stripping length: 7 mm

Screwdriver: 3 mm at

6.1 Mechanical characteristics

Protection against impacts: IK 04

Protection against solid bodies/liquids: IP20D considering complete

installation

6.2 Material characteristics

Mechanism casing: PC

Halogen-free

UV resistant

Self-extinguishing:

+ 850°C/30 s for insulating parts holding live parts in place.

+ 650°C/30 s for the other insulating components.

 6.3 Electrical characteristics

Voltage: 100/240 V~

Current: 2 A max bulb

Current: 0,4 A max LED

Current: 1 A max CFL

Frequency: 50/60 Hz

Standby consumption: 1 mA

Zigbee technology 2.4 GHz to 2.4835 GHz

Power level: REC 70-03: < 20 dBm

Range: 200 m of unobstructed space

10 m between products

 6.4 Climate characteristics

Storage temperature: 0°C to +45°C

Usage temperature: +5°C to +45°C

1. USE

The connected switch allows to control lights locally or remotely. The

connected switch has the same installation and usability of a traditional

switch and it is compatible with all loads with max power 250W. It is

equiped with a blue LED light used always on for localization modality or

on, when the ight in on for the load status modality. It can be associated

with "wireless light switches".

Caution: must be connected to the neutral.

Power supply 100/240Vac - 1 module.

Colours code:

White

Sand

Black

A B C D

45 22 35 7

Designation Cat. No(s) Related

Cover code

Connected switch for lighting.

Equipped with an LED indicator.

Hidden reset button used to return

to factory settings.

K4001C

KW01/KW01M2

KM01/KM01M2

KG01/ KG01M2

2. RANGE

3. DIMENSIONS (mm)

6. TECHNICAL CHARACTERISTICS

5. OPERATION

B C D

LED indicator: useful during installation

Control Pushbutton

RESET pushbutton: used to return to factory settings

2/2

Cat. No(s): K4001C

Technical data sheet: IDP000271_01-EN Updated: Created: 18/10/2019

Connected 1 way switch

Clean the surface with a cloth.

Do not use acetone, tar-removing cleaning agents or trichloroethylene.

Resistant to the following products: Hexane (EN 60669-1), methylated

spirit, soapy water, diluted ammonia, bleach diluted to 10%, window-

cleaning products, pre-impregnated wipes.

8. STANDARDS AND APPROVALS

Compliant with installation and manufacturing standards.

See e-catalogue.

The undersigned, BTICINO, declares that the radio-electric equipment

type (K4003C) complies with directive 2014/53/EU.

The full text of the EU declaration of conformity is available on the

following website: www.bticino.it/red

7. CARE

Caution: Always test before using special cleaning products.
