Brother MFC 4550 Manual de usuario

These machines are made for use in the USA or CANADA only. We

can not recommend using them overseas because it may violate the

Telecommunications Regulations of that country and the power

requirements of your fax machine may not be compatible with the

poweravailableinforeigncountries.UsingUSAorCANADAmodels

overseas is at your own risk and will void your warranty.

UF72440013

Printed in Japan

*Manufactured by Brother Industries Ltd. whose quality system

is registered by BSI and JQA.

BSI Certificate of registration No. FM27391

JQA Certificate of registration No. JQA-0340

Brother International Corporation

200 Cottontail Lane,

Somerset, NJ 08875-6714, U.S.A.

Brother International Corporation (Canada) Ltd.

1 rue Hôtel de Ville,

Dollard-des-Ormeaux, QC, CANADA H9B 3H6

MFC 4550/6550MC/7550MC

OP-US-5.0

MFC 4550

MFC 6550MC

MFC 7550MC

OPERATIONS

MANUAL

for Fax, Printer, Copier

CONTENTS

Chapter 1: THE CONTROL PANEL KEYS

Chapter 2: HOW TO USE ON-SCREEN PROGRAMMING

(OSP)AND HELP KEY

Chapter 3: TELEPHONE FUNCTION SETTINGS

Chapter 4: USING THE UNIT AS A TELEPHONE

Chapter 5: SENDING FAXES

Chapter 6: RECEIVING FAXES AND OTHER CALLS

Chapter 7: POLLING

Chapter 8:

REMOTE FAX OPTIONS (Only for MFC 4550)

Chapter 9: MESSAGE CENTER MODE SETTINGS

(Only for MFC 6550MC/7550MC)

Chapter 10: USING THE MFC AS A PRINTER

Chapter 11: PRINTING REPORTS AND LISTS

Chapter 12: HOW TO USE THE COPY FUNCTION

Chapter 13: REPLACING TONER CARTRIDGE AND DRUM UNIT

Chapter 14: REGULAR MAINTENANCE

Chapter 15: OPTIONAL ACCESSORIES

Chapter 16: TROUBLESHOOTING PROCEDURES

Chapter 17: SPECIFICATIONS

Chapter 18: IMPORTANT INFORMATION

Chapter 19: INDEX

MFC 4550/6550MC/7550MC

OP-US-5.0

1. Remove the drum unit.

Shipment of the Multi-Function Center (MFC)

If for any reason you must ship your MFC, carefully package the MFC

to avoid any damage during transit. It is recommended that you save

and use the original packaging. The MFC should be adequately insured

with the carrier.

Warning

When shipping the MFC, the DRUM UNIT assembly including the TONER

CARTRIDGE must be removed from the machine (MFC) and placed in

the zip lock bag. Failure to remove it and place it in the zip lock bag

during shipping, will cause severe damage to the machine and will

VOID THE WARRANTY.

2. Place the drum unit in the zip lock

bag.

3. Repack the Machine (MFC).

MFC 4550/6550MC/7550MC

OP-US-5.0

Introduction to the Operations Manual

forFax,Printer,Copier

Have you set up your MFC and prepared your computer for

the printer mode by following the instructions in the Setup

Manual? The Setup Manual will help you prepare your MFC

touseitasafax,printerandcopier.

Your Multi-Function Center 6550MC/7550MC has 6

performance modes in one machine. It is a Fax, Printer,

Copier, Scanner, PC Fax and Message Center.

And your MFC 4550 has 5 performance modes. It is a Fax,

Printer, Copier, Scanner and PC Fax.

After you complete setting up the MFC, see the “Operations

ManualforFax, Printer, Copier,”formoreinformationabout

your MFC, such as functions of the machine and the control

panel. Information about maintenance, troubleshooting and

technicalspecificationsarealsoavailableinthismanual.

Please keep this manual beside your MFC, so you can access

important information whenever necessary.

See the Multi-Function Link Pro Owner's Manual for

information on how to set up your MFC and Personal Computer

and how to use the Scanner and PC Fax.

MFC 4550/6550MC/7550MC

OP-US-5.0
