Basic User’s Guide

MFC-J650DW

MFC-J870DW

MFC-J875DW

Version A

USA/CAN

172

General D

NOTE

This chapter provides a summary of the machines’ specifications. For additional specifications

visit http://www.brother.com/.

1Measured diagonally.

2Measured when the machine is connected to the USB interface. Power consumption varies slightly depending on the

usage environment or part wear.

3When using ADF, single-sided printing, resolution: standard / document: ISO/IEC 24712 printed pattern.

4Measured according to IEC 62301 Edition 2.0.

5Even when the machine is turned off, it will automatically turn itself on periodically for print head maintenance, and

then turn itself off.

Specifications D

Printer Type Inkjet

Print Head Black:

Color:

Piezo with 210 nozzles  1

Piezo with 210 nozzles  3

Memory Capacity 128 MB

LCD (Liquid Crystal

Display) 2.7 in. (67.5 mm) TFT Color Touchscreen LCD 1 and

Touchpanel

Power Source AC 100 to 120 V 50/60 Hz

Power Consumption 2(MFC-J650DW)

Copying Mode: Approx. 19 W 3

Ready Mode: Approx. 4 W 4

Sleep Mode: Approx. 1.1 W 4

Off: Approx. 0.2 W 45

(MFC-J870DW and MFC-J875DW)

Copying Mode: Approx. 19 W 3

Ready Mode: Approx. 4 W 4

Sleep Mode: Approx. 1.2 W 4

Off: Approx. 0.2 W 45

Specifications

173

1Noise depends on printing conditions.

Dimension

Weight (MFC-J650DW) 20.1 lb (9.1 kg)

(MFC-J870DW and MFC-J875DW) 20.7 lb (9.4 kg)

Noise Level Sound Pressure

Operating: 50 dB(A) (Maximum) 1

Temperature Operating:

Best Print Quality:

50 to 95 F (10 to 35 C)

68 to 91 F (20 to 33 C)

Humidity Operating:

Best Print Quality:

20 to 80% (without condensation)

ADF (automatic

document feeder)

Up to 20 pages

Paper: 20 lb (80 g/m2) Letter or A4 size

Document Size ADF Width: 5.8 in. to 8.5 in. (148 mm to 215.9 mm)

ADF Length: 5.8 in. to 14.0 in. (148 mm to 355.6 mm)

Scanner Glass Width: Max. 8.5 in. (215.9 mm)

Scanner Glass Length: Max. 11.7 in. (297 mm)

7.1 in.

(180 mm)

16.1 in.

(410 mm)

14.7 in.

(374 mm)

20.4 in.

(519 mm)

174

Print media D

1For glossy paper or transparencies, remove printed pages from the output paper tray immediately after they exit the

machine to avoid smudging.

2Use only transparencies recommended for inkjet printing.

3See Paper type and size for each operation on page 28.

Paper Input Paper Tray D

Paper Type:

Plain Paper, Inkjet Paper (coated paper),

Glossy Paper 1 and Transparency 12

Paper Size 3:

Letter, Legal, Executive, A4, A5, A6, Envelopes (Com-10, DL, C5,

Monarch), Photo (4" 6")/(10 15 cm), Photo 2L

(5" 7")/(13 18 cm) and Index Card (5" 8")/(127 203 mm)

Width: 3.86 in. - 8.5 in. (98 mm - 215.9 mm)

Length: 5.8 in. - 14 in. (148 mm - 355.6 mm)

For more details, see Paper weight, thickness and capacity

on page 29.

Maximum paper tray capacity:

Up to 100 sheets of 20 lb (80 g/m2) plain paper

Photo Bypass Tray (USA)

Photo Paper Tray (Canada)

Paper type:

Plain Paper, Inkjet Paper (coated paper) and Glossy Paper 1

Paper size:

Photo (4" 6")/(10 15 cm) and Photo L (3.5" 5")/(89 127 mm)

Width: 3.5 in. - 4.0 in. (89 mm - 102 mm)

Length: 5.0 in. - 6.0 in. (127 mm - 152 mm)

Maximum paper tray capacity:

Up to 20 sheets

Paper Output Up to 50 sheets of 20 lb (80 g/m2) plain paper (face up print delivery to the

output paper tray) 1

Specifications

175

Fax D

1“Pages” refers to the “ITU-T Test Chart #1” (a typical business letter, Standard resolution, MMR code). Specifications

and printed materials are subject to change without prior notice.

Compatibility ITU-T Group 3

Modem Speed Automatic Fallback

14,400 bps

Scanning Width 8.19 in. (208 mm) (Letter)

Printing Width 8.26 in. (210 mm) (Letter)

Gray Scale B&W: 8 bit (256 levels)

Color: 24 bit (8 bit per color/ 256 levels)

Resolution Standard

203  98 dpi (Black)

203  196 dpi (Color)

Fine

203  196 dpi (Black/Color)

Superfine

203  392 dpi (Black)


203  196 dpi (Black)

Address Book 100 names  2 numbers

Groups Up to 6

Broadcasting 250 (200 Address Book/50 Manual Dial)

Automatic Redial 1time after 5minutes

Memory Transmission Up to 200 1 pages

Out of Paper Reception Up to 200 1 pages

176

Copy D

1When copying on Letter size paper.

Color/Black Yes/Yes

Copy Width 8.26 in. (210 mm) 1

Multiple Copies Stacks/Sorts up to 99 pages

Enlarge/Reduce 25% to 400% (in increments of 1%)

Resolution Prints up to 1200 2400 dpi

2-sided Yes

Paper Type:

Plain paper

Paper Size:

Letter, A4, A5, Executive

Specifications

177

PhotoCapture Center™ D

1Memory cards, adapters and USB Flash drive are not included.

2USB 2.0 Standard

USB Mass Storage standard up to 64 GB

Support format: FAT12/FAT16/FAT32/exFAT

3Progressive JPEG format is not supported.

4Motion JPEG only

5See Paper type and size for each operation on page 28.

Compatible Media 1Memory Stick Duo™ (16 MB - 128 MB)

Memory Stick PRO Duo™ (256 MB - 32 GB)

(Not available for music data with MagicGate™)

Memory Stick Micro™ (M2™) with Adapter (256 MB - 32 GB)

MultiMedia Card (32 MB - 2 GB)

MultiMedia Card plus (128 MB - 4 GB)

MultiMedia Card mobile with Adapter (64 MB - 1 GB)

SD Memory Card (16 MB - 2 GB)

miniSD with Adapter (16 MB - 2 GB)

microSD with Adapter (16 MB - 2 GB)

SDHC Memory Card (4 GB - 32 GB)

miniSDHC with Adapter (4 GB - 32 GB)

microSDHC with Adapter (4 GB - 32 GB)

SDXC Memory Card (48 GB - 128 GB)

USB Flash drive 2

Resolution Up to 1200  6000 dpi

File Extension

(Media Format) DPOF (ver. 1.0, ver. 1.1), Exif DCF (up to ver. 2.1)

(Image Format) Photo Print: JPEG 3, AVI 4, MOV 4

Scan to Media: JPEG, PDF (Color)

TIFF, PDF (Black & White)

Color Enhancement Yes

Photo Enhance

(MFC-J870DW and

MFC-J875DW)

Auto Correct, Enhance Skin, Enhance Scenery, Cropping,

Remove Red-eye, Night Scene, Fill Light, Whiteboard,

Monochrome and Sepia

Number of Files Up to 999 files

(The folder inside memory cards or USB Flash drive is also

counted.)

Folder File must be stored in the 4th folder level of the memory card or

USB Flash drive.

Borderless Letter, A4, Photo (4" 6")/(10 15 cm), Photo 2L

(5" 7")/(13 18 cm) 5

178

PictBridge D

Compatibility Supports the Camera & Imaging Products Association

PictBridge standard CIPA DC-001.

Visit http://www.cipa.jp/pictbridge/ for more information.

Interface USB direct interface

Specifications

179

Scanner D

1Windows® XP in this User’s Guide includes Windows® XP Home Edition, Windows® XP Professional, and Windows®

XP Professional x64 Edition.

2Maximum 1200  1200 dpi scanning when using the WIA Driver for Windows®XP, Windows Vista®, Windows®7 and

Windows®8 (resolution up to 19200  19200 dpi can be selected by using the Brother scanner utility).

Color/Black Yes/Yes

TWAIN Compliant Yes

(Windows®XP 1/Windows Vista®/Windows®7/Windows®8)

(Mac OS X v10.6.8, 10.7.x, 10.8.x)

WIA Compliant Yes

(Windows®XP 1/Windows Vista®/Windows®7/Windows®8)

ICA Compliant Yes (Mac OS X v10.6.8, 10.7.x, 10.8.x)

Color Depth 30 bit color Processing (Input)

24 bit color Processing (Output) / 256 levels per color

Gray Scale 10 bit color Processing (Input)

8 bit color Processing (Output) / 256 levels per color

Resolution Up to 19200  19200 dpi (interpolated) 2

Up to 1200  2400 dpi (optical) (Scanner Glass)

Up to 1200  600 dpi (optical) (ADF)

Scanning Width and Length (Scanner Glass)

Width: Up to 8.42 in. (213.9 mm)

Length: Up to 11.61 in. (295 mm)

(ADF)

Width: Up to 8.42 in. (213.9 mm)

Length: Up to 13.92 in. (353.6 mm)

180

Printer D

1When the Borderless feature is set to On.

2See Paper type and size for each operation on page 28.

3When printing on Letter size paper.

4For detailed specifications visit http://www.brother.com/.

Resolution Up to 1200  6000 dpi

Printing Width 38.26 in. [8.5 in. (borderless) 1]

Borderless 2Letter, A4, A6, Photo (4" 6")/(10 15 cm), Photo L

(3.5" 5")/(89 127 mm), Index Card

(5" 8")/(127 203 mm), Photo 2L

(5" 7")/(13 18 cm)

2-sided Paper Type:

Plain paper

Paper Size:

Letter, A4, A5, Executive

Print Speed 4
