Breville Bar Italia ESP4 Manual de usuario

Model ESP4

C NTENTS

Page

Introduction 3

Breville Recommends Safety First 4

Special Safety Directions 5

Know your Breville Espresso/Cappuccino Maker 6

Operating your Breville Espresso/Cappuccino Maker 7

Before using your Espresso/Cappuccino Maker 7

How to make an Espresso 7

How to froth milk for a cappuccino or latte 10

How to release the steam pressure 11

Coffee Making Tips 12

Drinks to Try 12

Care and Cleaning 13

Trouble Shooting Chart 15

Bar Italia

Congratulations

Congratulations on the purchase of your new

Breville Espresso/Cappuccino Maker

•Do not immerse cord, plug or

Espresso/Cappuccino Maker body in

water or any other liquid.

•Always use the appliance on a dry, level

surface.

•Before use fully unwind the power cord.

•Do not let the cord hang over the edge of

a table or counter, touch hot surfaces, or

become knotted.

•Do not place this appliance on or near a

hot gas or electric burner, or where it

could touch a heated oven.

•Always turn the Selector Control to

‘STA DBY’, switch the power off at the

power outlet and then remove the plug

when the appliance is not being used and

before cleaning.

•The appliance is not intended for use by

young children or infirm persons without

supervision.

•Do not leave the appliance unattended

when in use. Young children should be

supervised to ensure that they do not play

with the appliance.

•This appliance is for household use only.

•Do not use this appliance for anything

other than its intended use. Do not use

outdoors.

•Do not touch hot surfaces. Use handles.

•Regularly inspect the supply cord, plug

and actual appliance for any damage. If

found damaged in anyway, immediately

cease use and return the entire appliance

to the nearest authorised Breville Service

Centre for examination, replacement or

repair.

•Any maintenance other than cleaning

should be performed at an authorised

Breville Service Centre.

•The installation of a residual current

device (safety switch) is recommended to

provide additional safety protection when

using electrical appliances. It is advisable

that a safety switch with a rated residual

operating current not exceeding 30mA be

installed in the electrical circuit supplying

the appliance. See your electrician for

professional advice.

BREVILLE REC MMENDS SAFETY FIRST

Congratulations on your purchase of your new Breville Espresso/Cappuccino Maker. We at

Breville are very safety conscious. We design and manufacture consumer products with the

safety of you, our valued customer, foremost in mind.

In addition, we ask that you exercise a degree of care when using any electrical appliance and

adhere to the following precautions:

IMP RTANT SAFEGUARDS

SPECIAL SAFETY INSTRUCTI NS

T AV ID P SSIBLE BURNS FR M H T STEAM AND WATER, NEVER PEN

THE WATER TANK CAP WHILE THERE IS PRESSURE IN THE WATER TANK.

REM VE ALL PRESSURE FIRST.

SPECIAL SAFETY

INSTRUCTI NS

•The cup-warming plate will always be

heating when the appliance is switched on

at the power outlet. Please switch off and

unplug when not in use.

•Only use cold water in the water tank. Do

not use any other liquid.

•ever use the appliance without water in it.

•Ensure the water tank cap and filter

holder are firmly secured when using

the appliance.

•Always ensure the water tank cap is clean

around the seal and the centre valve area

(never use if the seal is damaged or faulty).

•As part of regular maintenance, it is

recommended that this appliance be

taken to the nearest authorised Breville

Service Centre for checking of the

‘Pressure Indicator Button’ once every

two years.

•Before removing the Water Tank Cap

ensure the Pressure Indicator Button has

dropped down and is flush with the top of

the cap.

•To avoid possible burns from hot steam

and water, never remove the water tank

cap or filter holder while there is steam

pressure in the water tank. Remove all

steam pressure first.

•Refer to Page 11 for instructions on how

to release the steam pressure.

3 position brew/steam selector control

Water tank cap with pressure

indicator button

Cup warming plate

Power ‘on’ and ‘heating’ lights

Steam tube and nozzle with removable

cappuccino froth enhancer

Filter holder and 2 stainless steel

filters (1-2 cup filter and 2-4 cup filter)

Removable drip tray

Bonus espresso cup set (not shown)

Cleaning tool (not shown)

Water tank with hinged cover Stainless steel frothing jug Coffee measuring spoon

KN W Y UR BREVILLE ESPRESS /CAPPUCCIN MAKER

PERATING Y UR BREVILLE ESPRESS /CAPPUCCIN MAKER

Do not use warm or hot

water to fill the water tank.

fig 1

D N T P UR WATER INT THE WATER TANK WHILE THE SELECT R

C NTR L IS IN THE BREW R STEAM P SITI N.

BEF RE USING Y UR

ESPRESS /CAPPUCCIN

MAKER

Wash the filter holder, stainless filters

and frothing jug in mild detergent and water.

Rinse and dry thoroughly.

It is recommended to carry out a

complete brewing operation with cold water

but without any coffee before making your

first espresso or cappuccino (see Brewing

Coffee). By doing so, any residual dust left

inside the Espresso/Cappuccino Maker will

be removed.

PRE-WARMING CUPS

For optimal coffee temperature, use the cup

warming plate on top of the appliance to

pre-warm the cups. The cup-warming plate

will be heating whenever the appliance is

switched on at power outlet.

H W T MAKE AN ESPRESS

Filling the water tank

•Switch the power off at the power outlet

and remove the plug.

•Ensure the Brew/Steam selector control

is in the ‘STA DBY’ position.

•Ensure the Pressure Indicator Button on

the Water Tank Cap has dropped down

and is flush with the top of the cap.

•

•Unscrew the water tank cap and pour cold

water into the tank. Fill to 5mm below the

visible water pipes (Fig 1). Do not fill to

the top of the tank or there will not be

enough area to generate steam.

•Screw the water tank cap back on top of

the water tank, making sure it is secured

firmly before operating the appliance.

THE METAL PARTS F THE FILTER H LDER MIGHT STILL BE VERY H T.

C L D WN THESE PARTS BY RUNNING UNDER C LD WATER.

T AV ID P SSIBLE BURNS FR M H T STEAM AND WATER, NEVER PEN

THE WATER TANK CAP WHILE THERE IS PRESSURE IN THE WATER TANK.

REM VE ALL PRESSURE FIRST.

NEVER LET C FFEE R WATER LEVEL IN A CUP REACH THE P URING

N ZZLE F THE FILTER H LDER.

fig 3 fig 4

correct

(level)

Incorrect

(Heaped)

PREPARING THE C FFEE

•Remove the filter holder by rotating 45

degrees to the left (Fig 2 ).

•Place the 2 or 4 cup filter into the filter

holder and use the measuring spoon to

fill the filter with ground espresso coffee

to the required cup level marking inside

the filter (use the smaller filter for 1 or 2

cups and the larger filter for 2 or 4 cups).

Do not fill above the 2 or 4 cup mark.

•Distribute the ground coffee evenly and

press it lightly with the measuring spoon

(Fig 3 and 4). Too much coffee can block

the flow of water.

•Clean any excess ground coffee from the

rim of the filter holder to ensure a proper

fit under the brew head.

•Place the filter retainer clip in the release

position by pulling the clip back towards

your hand.

•Place the filter holder underneath the

brew head so that the handle is

positioned to the left of centre. Lift the

filter holder until it contacts the brew

head and rotate to the right.

PERATING Y UR BREVILLE ESPRESS /CAPPUCCIN MAKER

fig 2

The steam pressure in the

machine must be released

each time BEF RE re-filling

with fresh cold water.

BREWING THE C FFEE

The twin nozzle filter holder allows you to

make either one or two espresso coffees

at a time.

•Make sure the drip tray is in place. Place

empty coffee cups on the drip tray under

the filter holder.

•Make sure the Brew/Steam Selector

Control is in the ‘STA DBY’ position.

•Plug the power cord into a 230/240v

power outlet and switch on.

•The red power ‘On’ light will illuminate

when the appliance has been switched on

at the power outlet and the cup warming

plate will start heating.

•Rotate the Selector Control to the ‘BREW’

position . The orange heating light will

illuminate to let you know the water is

heating. Coffee will begin to flow into the

cups in approximately five minutes.

•The Pressure Indicator Button on the

Water Tank Cap will rise when sufficient

steam pressure is achieved.

•When sufficient coffee has flowed into the

cups, turn the Selector Control back to

the ‘STA DBY’ position. This will stop the

flow of coffee.

•If you are not continuing to using the

steam function, switch off at the power

outlet, unplug the power cord, remove all

pressure and allow the appliance to cool.

•Do not remove the water tank cap or filter

holder until the steam pressure in the

appliance has been released. The

Pressure Indicator Button should drop

down and be flush with the top of the

water tank cap.

PERATING Y UR BREVILLE ESPRESS /CAPPUCCIN MAKER

T AV ID SPLATTERING F H T MILK, D N T LIFT THE STEAMING

N ZZLE AB VE THE SURFACE F THE MILK WHILE FR THING.

ENSURE THE SELECT R C NTR L IS IN THE ‘STANDBY’ P SITI N

BEF RE REM VING THE FR THING JUG.

H W T FR TH MILK F R A

CAPPUCCIN R LATTÉ

A cappuccino is an espresso topped with

steamed and frothed milk (1⁄3espresso,

1⁄3steamed milk, 1⁄3frothed milk), traditionally

served luke warm in a cup.

A latte is an espresso topped with

steamed and frothed milk (1⁄3espresso,

topped with steamed milk and about 10cm of

frothed milk), traditionally served in a glass

wrapped with a serviette.

•The first step in making a cappuccino/latte

is to make a short espresso (Follow steps

in ‘How to make an Espresso’).

•Fill the frothing jug 1/3 full with cold milk

(skim milk is the easiest to froth).

•Hold the frothing jug below the froth

enhancer. Immerse the froth enhancer

10mm into the milk and rotate the

Selector Control to the ‘STEAM’

position . Gently move the frothing

jug in a circular motion around the

froth enhancer.

•When the milk begins to increase in

volume, immerse the froth enhancer

deeper into the milk to further heat the

milk. Do not allow the milk to boil.

•Turn the Selector Control to the

‘STA DBY’ position to stop the steaming

function before removing the jug.

•Add the steamed milk to each cup of

freshly brewed espresso coffee and spoon

on the frothed milk.

•Switch the power off at the power outlet,

unplug the power cord, remove all steam

pressure and allow the appliance to cool.

•Do not remove the water tank cap or the

filter holder until the steam pressure in

the appliance has been released. The

Pressure Indicator Button should drop

down and be flush with the top of the

water tank cap.

PERATING Y UR BREVILLE ESPRESS /CAPPUCCIN MAKER

Otros manuales para Bar Italia ESP4

Tabla de contenidos

Otros manuales de Cafetera de Breville

Breville

Breville the Oracle BES980XL Manual de usuario

Breville

Breville the Duo-Temp BES800XL Manual de usuario

Breville

Breville Barista Max+ Manual de usuario

Breville

Breville Grind Control BDC650BSS Manual de usuario

Breville

Breville Cafe Roma ESP8B Manual de usuario

Breville

Breville Cafe Venezia BES250XL Manual de usuario

Breville

Breville BES820XL Manual de usuario

Breville

Breville Duo-Temp Pro Manual de usuario

Breville

Breville Aroma Fresh BCM120 Manual de usuario

Breville

Breville Bambino Manual de usuario

Breville

Breville VCF152X Manual de usuario

Breville

Breville CAFE ROMA Manual de usuario

Breville

Breville Cafe Roma ESP8XL Manual de usuario

Breville

Breville the Oracle Touch BES990DBL1BUS1 Manual de usuario

Breville

Breville Aroma Style Electronic LCM700 Manual de usuario

Breville

Breville ESPRESSO MACHINE Manual de usuario

Breville

Breville Barista Express Manual de usuario

Breville

Breville BKC600XL Manual de usuario

Breville

Breville BES900 Manual de usuario

Breville

Breville VCF126X Manual de usuario

Breville

Breville the Barista Express BES870 Manual de usuario

Breville

Breville the Oracle BES980 Manual de usuario

Breville

Breville Grind Control Manual de usuario

Breville

Breville vcf011 Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
