Model S100

Electronic Bench Scale

User Manual

WARNINGS

Safe installation

Safety

THE EQUIPMENT CONTAINS NO USER SERVICEABLE COMPONENTS.

Installation and maintenance of the equipment must only be carried out by trained and

authorised personnel.

Electrical installation

The mains lead must be connected to a supply outlet with a protective earth contact. The

electrical supply at the socket outlet must provide over current protection of an appropriate

rating.

For your protection all mains (110V or 230V) equipment used out of doors or in wet or damp

conditions should be supplied from a correctly fused source and protected by an approved

ground fault protection device (RCD, GFCI etc.)

IF IN DOUBT SEEK ADVICE FROM A QUALIFIED ELECTRICIAN.

Routine maintenance

To avoid the possibility of electric shock or damage to the machine, always switch off the

machine and isolate from the power supply before carrying out any routine maintenance.

To avoid the risk of the machine falling, where applicable, ensure that it is placed securely on a

flat and level surface.

Safe use

Caution – Cleaning the indicator/weigh head

Harsh abrasives, solvents, scouring cleaners and alkaline cleaning solutions, such as washing

soda, should not be used especially on the display windows. Under no circumstances should

you attempt to wipe the inside of the machine.

The outside of standard products may be wiped down with a clean cloth, moistened with water

containing a small amount of washing up liquid.

The outside of products waterproofed to IP65, IP66 and IP67 may be washed down with water

containing a small amount of proprietary detergent.

Training

Do not attempt to carry out any procedure on a machine unless you have received the

appropriate training or read the Instruction Manual.

EMC compliance

The following may be applicable to your machine.

WARNING:

This is a class A product. In a domestic environment this product may cause radio interference

in which case the user may be required to take adequate measures.

Product Contents

Indicator

Base

Steel Pipe

Pipe Bracket

Screws x 4

Nuts x4

Platform

Allan keys

Indicator Assembly

1. Feed the loadcell wire

through the base and the

pipe.

2. Insert the pipe into the

base

3. Tighten the nuts with

the provided.allen key

4. Feed the loadcell

wire through the

bracket.

5. Insert the pipe into

pipe bracket.

6. Tighten the screw

7. Set the indicator on the

bracket and use the four

nuts (provided) to fix the

indicator in place.

8. The indicator stand is now

fully assembled.

Platform Assembly

Remove the four packaging pads from the base of the

platform before use

Securely fix the indicator stand onto the side of the

platform using the two nuts. The scale is now

ready for use.

Setting the Scale Up for Use

Display and Keypad

ON/OFF TAREZERO UNITS

I0Tkg/lb

kg lb Zero Low Batt CH Net

0-+

SBI 100

Max 300kg

d = 0.05kg

ON/OFF

Function Keys Annunicators

Tare

ZERO

Illuminated when the weight is zero

On/Off

Depends on active unit of measure

(Flashing LED means that the weight

reading is not stable.)

Units

NET

Illuminated when adapter is plugged

in.

Zero

Illuminated when the battery is

charging.

Manual symbols

Short key press Long key pressMultiple key press

Scale Operation

Turning On and Zeroing the Scale

ZERO

Turning off the scale

Selecting Unit of Measure

kg lb

Using the Tare

NET



oz lb

Removing the Tare

ZERO

Setting up the Auto-Off Function

Scale must be switched on.

2. 0-9 minutes (0 switches the function off).

ZERO

Calibration

Only to be performed by trained personnel.

0N/OFF

300/150/60kg

600/300/120lb



Unit 0 lb Unit 1

6kg/15kg

12lb/30lb

ZERO

Error Messages

Error Message Definition Required

Solution/Troubleshooting

0¯ ¯ ¯ ¯: Weight above range for calibrated

zero point. Remove load before zeroing

Recalibrate the scale.

0_____:

Weight below range for calibrated

zero point. Remove load before zeroing

Recalibrate the scale.

_____: Indicates an under range condition Remove all loads and zero the

scale.

¯ ¯ ¯ ¯: Capacity exceeded Remove the load and try again. If

the load is great than 6 kg a scale

with a larger capacity is required.

CAL-Er: Calibration error Restart calibration

Lo.bAt: Low Battery Recharge the battery.
