Precision Engineered Opto-Electronics™
EX40
Hi-Impact Dome Camera
INSTALLATION INSTRUCTIONS
MAN-40-00
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep this instruction.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with manufacturer instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong is provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the power where they exit
from the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in a way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
IMPORTANT
For best results, please read this Instruction Booklet prior
to installing the EX40 camera.
WARNING !
CSA Certified / UL Listed CLASS 2 power adaptors must be used
in order to comply with electrical safety standards.
This Product Has Been Certified By CSA International To
Include the Health Care Facility Requirements Of UL 2044
Bosch Security Systems, Inc. will not be responsible for injuries
or damages resulting from the improper installation or use of any
product sold by Bosch Security Systems, Inc their agents,
distributors or dealers.
EU Directives covered by this declaration:
72/9/EC Low Voltage Directives
89/336/EEC Electromagnetic Compatibility Directive
NOTE: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to
part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. As part of its’
normal operation this device can generate radio
frequency energy and if not installed and used in
accordance with the installation manual may cause
interference to radio communications. However, there
is no guarantee that interference will not occur on a
particular installation. If the device does cause
interference to radio or television reception the user is
encouraged to try to correct the interference by one or
more of the following measures:
1) Fit Ferrite beads on all cable to and from the power
supply box, within the box walls.
2) Route the composite cable between the camera and
the power supply in steel conduit piping over the entire
run of the cable up to and including connection to a
deep conduit base fitted under the camera and a conduit
fitting adaptor in the wall of the PSU box.
3) Contact BOSCH Service Center for further advice.
INDEX – EX40
Page
Description...................................................1
Unpacking....................................................2
Parts List......................................................2
Items Required for Installation.....................2
Initial Preparations.......................................3
Guidelines....................................................3
Section 1. Dome Removal...........................4
Section 2. Input Power Connections ...........6
Section 3. Mounting - Camera Base..........11
Section 4. Directional Adjustment..............16
Section 5. Camera Re-Assembly ..............22
Section 6. Troubleshooting Guide.............24
Section 7. Mounting Holes Diagram..........26
Section 8. General Specifications..............27
1
DESCRIPTION
The EX40 Hi-Impact Dome Camera has been
engineered for surveillance in hostile
environments. Compact and good looking, the
camera features armour-tough construction for
protection against vandalism or against
accidental damage.
An aluminum housing, CNC-machined from a
billet, with an impact resistant polycarbonate
dome and locking retaining ring, make it
extremely rugged and weather-tight.
For viewing adjustment, the CCD Camera/Lens
Assembly can be fully rotated using a unique
“Pan-Tilt-Twist” (PTT) mounting bracket.
A voltage regulator circuit allows for 12V dc or
24V ac operation, and a range in between, also
providing protection from voltage surge,
transient spikes, and reverse voltage.
2
UNPACKING
Care should be taken when unpacking the shipped
unit. Check the parts list and confirm all items have
been located. Inspect the equipment thoroughly to
ensure nothing was damaged in transit.
Contact BOSCH Service Center if a problem is
noted, see rear page of this booklet for contact
numbers.
PARTS LIST (items supplied with unit)
- EX40 Camera Assembly
- Installation Instructions booklet
- Plastic bag containing an Allen key and one ½
NPT plug wrapped with Teflon tape
ITEMS REQUIRED FOR INSTALLATION
(not supplied with unit)
- Philips screwdriver
- Small slotted screwdriver
- Silicone sealant and Teflon sealing tape.
- Mounting screws, etc.
3
INITIAL PREPARATIONS
Determine the operating voltage at the installation
site. The camera’s Voltage Regulator Board
accepts either 12V dc or 24V ac input.
See Section 2, Input Power Connections.
Determine the optimum location for the camera.
Section 3, Mounting-Camera Base.
All cameras have been tested prior to shipment.
After the wiring has been reconnected, it is
advisable to check the camera’s operation before
installation.
ESD protection – Cameras and circuit boards are
sensitive electronic components. It is
recommended to wear a ground strap to ground
any static charge. (Alternative: touch a grounded
metal plate for at least a minute before proceeding
with any disassembly)
GUIDELINES
The installation of the EX40 camera is explained in
Sections 1 to 5 listed below. It is important that
these steps are followed in sequence:
1. Dome Removal
2. Input Power Connections
3. Mounting - Camera Base
4. Directional Adjustment
5. Camera Re-Assembly
4
1. DOME REMOVAL
The camera’s dome and its retaining ring must
be removed prior to mounting the camera or
performing any wiring disconnections and re-
connections. The setscrews in the retaining ring
are not tightened in the factory and protrude by
1/8" (3mm) in order for the ring to be rotated.
Refer to Figure 1 - 1 on page 5.
Step 1.1 - Place the camera on a flat surface.
Step 1.2 - Press firmly on the dome with one
hand and rotate the retaining ring in
a counter-clockwise direction with
the other hand. Push against the
protruding setscrews with a finger to
rotate the ring. Do not use a
screwdriver or other metal device.
Step 1.3 - Remove the dome and the retaining
ring. Set them aside.
