Access Modular Controller 2

ADS‑AMC2‑4WCF | APC‑AMC2‑4WCF

en Installation manual

Access Modular Controller 2 Table of contents | en 3

Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM

Table of contents

1Safety 5

1.1 Unpacking 6

1.2 FCC compliance 6

2Short information 7

3Introduction 8

3.1 Description 8

3.2 Product overview 10

3.2.1 Mainboard 10

3.2.2 Status display 12

3.3 System overview 14

4Installing 15

4.1 Mounting the device on a mounting rail 15

4.2 Unmounting the device from a mounting rail 15

4.3 Opening the case 16

4.4 Closing the case 17

4.5 Cabling 18

4.5.1 Conductor data for powering the controller 18

4.6 Grounding and shielding 19

4.6.1 Grounding for Host Interface 19

4.6.2 Gounding for Extension Interface 20

4.7 Connecting the power supply to the controller 21

4.8 Ethernet host interface 22

4.9 RS-485 host interface 23

4.9.1 RS-485 Two Wire Connection 24

4.9.2 RS-485 Four Wire Connection 24

4.9.3 DIP switch selector 24

4.10 RS-485 for extension modules 26

4.11 Wiegand interface for card readers 27

4.12 Connecting relay outputs 28

4.13 Connecting analog input devices 30

4.14 Tamper protection 32

5Operating 33

5.1 Configuring Ethernet interface 33

6UL requirements 34

6.1 System requirements 35

6.1.1 Computer 35

6.2 UL 294 level descriptions 35

6.3 Installation instructions 35

6.4 Extended technical specification 38

6.4.1 RS-485 extension 38

6.4.2 Power consumption 38

7Troubleshooting 39

7.1 Resetting the software 40

7.2 Resetting the device to factory default 41

8Service and repair 42

9Disposal 43

10 Technical specifications 44

11 Appendices 46

4en | Table of contents Access Modular Controller 2

2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.

11.1 Connecting diagrams 46

Access Modular Controller 2 Safety | en 5

Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM

1 Safety

Read instructions

Read all technical documentation before installing or using this product. Make sure that you

have understood all information described in the technical documentation. Do not ignore

safety messages, as this can cause property or personal damage. Retain instructions for future

reference.

Warning!

Risk of physical injury due to blocked escape routes

This product may block escape routes if not installed correctly. To keep escape routes free:

- Use locks in fail-safe mode, so that doors can be released if power fails.

- Install manual override switches, such as break-glass or lever stations, to unlock doors in an

emergency.

Warning!

Risk of explosion of lithium battery

The battery can explode if replaced incorrectly.

Replace the battery with the same type as recommended by Bosch.

Dispose used batteries according to the instructions of the manufacturer of the batteries.

Caution!

Fire hazard and risk of electric shock due to unauthorized spare parts and accessories

Unauthorized spare parts and accessories might lack grounding wires or other safety

elements. External power supplies must be installed by qualified personnel. The service

technician must use replacement parts or accessories that are specified by the manufacturer.

Notice!

Some features and functions described in this document depend on the firmware loaded into

the device and host software.

Notice!

Device damage due to electrostatic discharge

Protect the hardware from electrostatic discharge, especially when the device is open and

exposed. Always disconnect the controller from the power source before modifying the

installation. This product does not support hot plugging.

Notice!

Unauthorized access

If this product is installed in an unprotected environment, unauthorized people may be able

to enter.

Install the product in a location with restricted access.

Notice!

Device damage due to incorrect mounting

This product may fall and break if it is not mounted on the mounting rails.

Mount this product on the matching mounting rails.

This product is RoHS compliant. See Technical data for the full table of hazardous

components.

6en | Safety Access Modular Controller 2

2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.

1.1 Unpacking

Check the packaging for visible damage. If anything has been damaged during transport,

please inform the transport agency.

Unpack the product carefully. This is an electronic device that must be handled with care to

avoid damage. Do not attempt to put the product into operation if components are damaged.

If any parts are missing, inform your customer service representative or a Bosch Security

Systems salesperson. The shipping carton is the safest transport container for the unit. Store

the shipping carton and the other packaging material for future use. If the product has to be

sent back, use the original packaging.

1.2 FCC compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference, and

2. this device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC rules. The limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate receiving antenna.

2. Increase the separation between the equipment and the receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Access Modular Controller 2 Short information | en 7

Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM

2 Short information

This controller is able to control up to four Wiegand card readers.

It is designed to fully process the access logic at assigned access points. Access points

consist of doors, gates, barriers, turn stiles, revolving doors, mantraps, ID card readers, door

opening elements and sensors.

All the product versions use encrypted connections between the access modular controller

and the host system.

The controller stores all necessary information in a battery-buffered memory and in a compact

flash storage element. Even when the unit is offline, it is able to perform:

– Independent status and authorization checks on access points

– Take access decisions

– Activate and deactivate connected peripheral elements

– Detect and register all relevant events

The Access Modular Controller (AMC) is supported by the Access Professional Edition (APE),

BIS Access Engine (ACE) and the Access Management System (AMS).

For the latest information about our products, visit our online product catalog:

www.boschsecurity.com/xc/en/product-catalog/

Manufacturing dates

For product manufacturing dates, go to www.boschsecurity.com/datecodes/ and refer to the

serial number on the product label.

Remarks

This hardware is part of a security system.

Access should be granted to authorized people only.

Some states do not allow the exclusion or limitation of implied warranties, or limitation of

liability for incidental or consequential damages, hence the above limitation or exclusion might

not apply to you.

If you need further assistance or have any questions, contact:

Bosch Security Systems B.V.

Torenallee 49

5617 BA Eindhoven

Netherlands

www.boschsecurity.com

8en | Introduction Access Modular Controller 2

2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.

3 Introduction

3.1 Description

The controller is equipped with four independent interfaces for Wiegand type readers. It is

able to control two doors with one reader in each direction and up to four doors with a reader

in one direction only.

Figure3.1: Access Modular Controller

All necessary information for access verification is stored in a battery buffered on-board

memory and a Compact Flash (CF) memory card. This guarantees autonomous access

decisions and complete access registrations even if the management host system is offline.

The built in compact flash adapter provides adequate storage capability for cardholders and

events.

The electronics of the controller are completely covered by a plastic housing. The LCD (liquid

crystal display) provides all important status information.

Unsecured Area

Secured Area

Figure3.2: Example

Access Modular Controller 2 Introduction | en 9

Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM

The controller can communicate upstream to the host computer using RS-485 multi-dropped

or Ethernet. It has eight analog input devices and eight relay outputs. With its analog input

devices, the controller verifies, for example, if a lock is closed or open. The relay outputs can

be used, for example, to activate lock mechanisms if access is granted, or activate the burglar

alarm system if an intrusion or system alert is detected. If the eight inputs and eight outputs

on the board are not enough to configure the system, up to three additional extension boards

can be connected. The extensions offer 8 or 16 additional inputs and outputs.

In the Bosch Access Host Systems the setup procedure for a controller is made very simple

and fast by the use of door templates. Once selected, all the inputs and outputs are

predefined. These settings can be changed to choose every free contact of the controller or a

connected extension.

10 en | Introduction Access Modular Controller 2

2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.

3.2 Product overview

3.2.1 Mainboard

3 4 52

10 11

Figure3.3: Upper circuit board with display (front)

1 DIP switch for RS-485 address and protocol selection.

2 Lithium battery for buffering of static RAM and real time clock (RTC). The battery life

is estimated at 10 years, nevertheless an error message is generated if the voltage

sinks below a preset minimum level.

NOTICE: In order to avoid an error message caused by an earlier voltage drop we

suggest to replace the battery every 8 years. Spare part: VARTA CR 2032 PCB.

3 Reset push button - reachable through the casing using a screwdriver

4 Liquid Crystal Display

5 Push button, available on top of the housing, to select different display modes

6 Jumper: Equalization of potential between different systems and earth ground

(shield)

7 Jumper: Interface selector RS-485 host connection, RS-485 two wire or RS-485 four

wire (depends on external wiring)

8 Configurable RS-485 host interface

9 Compact flash memory

10 Project-specific interface

11 Configurable 10/100 Mbit/s Ethernet host interface

Otros manuales para Access Modular Controller 2

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de Bosch

Bosch

Bosch Rexroth IndraControl L40 Manual técnico

Bosch

Bosch AMC2-4W Manual de usuario

Bosch

Bosch LTC 8600 Manual de usuario

Bosch

Bosch APC-AMC2-4R4CF Manual de usuario

Bosch

Bosch rexroth ctrlX CORE Manual de usuario

Bosch

Bosch Rexroth ctrl CORE Manual de usuario

Bosch

Bosch K 30 RF Manual de usuario

Bosch

Bosch Smart Home controller II Manual del operador

Bosch

Bosch ADS-AMC2-4R4CF Manual de usuario

Bosch

Bosch Rexroth VT-VPCD Series Manual de usuario

Bosch

Bosch CLIMATE 5000 VRF RDCI Series Manual de instrucciones

Bosch

Bosch Rexroth SYHNC100-SEK 3 Series Manual de usuario

Bosch

Bosch Rexroth IndraDrive MPH-02 Instrucciones de funcionamiento e instalación

Bosch

Bosch Plena LBB1990/00 Instrucciones de montaje

Bosch

Bosch Lambdatronic LT4 ADV Manual de instrucciones

Bosch

Bosch B443 Manual de usuario

Bosch

Bosch WORCESTER Sense II Manual de usuario

Bosch

Bosch Rexroth CS 440RC Guía del usuario

Bosch

Bosch AMC2 Series Manual de usuario

Bosch

Bosch PXI-CORE Edge controller Manual de usuario

Bosch

Bosch BMS-BAC Manual de usuario

Bosch

Bosch READYKEY PRO LNL-500 Manual de usuario

Bosch

Bosch CR 10H Manual de usuario

Bosch

Bosch CR 20 RF Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
