BMW Multi Tool User Manual

Table of Contents

1. Safety Precautions and Warnings................................................................................3

2. General Information......................................................................................................4

3. Hardware Overview......................................................................................................5

3.1. Tool Description.................................................................................................5

3.2. Specifications.....................................................................................................6

3.3. System Requirements.......................................................................................7

4. Software Overview .......................................................................................................8

4.1. Overview............................................................................................................8

4.2. Function...........................................................................................................11

5. Troubleshooting..........................................................................................................30

5.1. “Device not connected”Error ...........................................................................30

6. Warranty and Service.................................................................................................31

6.1. Limited One Year Warranty .............................................................................31

6.2. Service Procedures.........................................................................................35

BMW Multi Tool User Manual

1.Safety Precautions and Warnings

To prevent personal injury or damage to vehicles and/or the tool, read

this instruction manual first and observe the following safety

precautions at a minimum whenever working on a vehicle:

Always perform automotive testing in a safe environment.

Wear safety eye protection that meets ANSI standards.

Keep clothing, hair, hands, tools, test equipment, etc. away from all moving

or hot engine parts.

Operate the vehicle in a well ventilated work area: Exhaust gases are

poisonous.

Put blocks in front of the drive wheels and never leave the vehicle

unattended while running tests.

Use extreme caution when working around the ignition coil, distributor cap,

ignition wires and spark plugs. These components create hazardous

voltages when the engine is running.

Put the transmission in PARK (for automatic transmission) or NEUTRAL

(for manual transmission) and make sure the parking brake is engaged.

Keep a fire extinguisher suitable for gasoline/chemical/electrical fires

nearby.

Don’t connect or disconnect any test equipment while the ignition is on or

the engine is running.

Keep the tool dry, clean, free from oil/water or grease. Use a mild

detergent on a clean cloth to clean the outside of the scan tool, when

necessary.

BMW Multi Tool User Manual

2.General Information

Thank you for choosing BMW Multi Tool.

This manual includes the use of equipment notes, please read this manual

carefully before use so that you can correctly use it.

system, or transmitted, in any form, or by any means, mechanical, electronic,

photocopying, recording, or otherwise, without the prior written permission.

All copyright and trademarks acknowledged.

No patent liability is assumed with respect to the use of the information contained

herein. Moreover, because we is constantly striving to improve its high-quality products,

the information contained in this manual is subject to change without notice. Every

precaution has been taken in the preparation of this manual. Nevertheless, we

assumes no responsibility for errors or omissions. Neither is any liability assumed for

damages resulting from the use of the information contained in this publication.

BMW Multi Tool User Manual

3.Hardware Overview

3.1.Tool Description

ITEM

Description

❶

OBD II CONNECTOR

Connects the tool to the vehicle’s Data Link connector (DLC).

❷

Dongle

USB dongle.

❸

USB CONNECTOR

Connects the tool to the PC/Laptop through USB Cable.

❹

Programmer

Program keys.

❺

Programmer Female Pin

Connects programmer to device.

❻

Programmer Male Pin

Connects programmer to device.

BMW Multi Tool User Manual

3.2.Specifications

ITEM

Description

Operating Temperature

-20 to 70 °C ( -4 to 158 °F )

Storage Temperature

-40 to 85 °C ( -40 to 185 °F )

Diagnostic Interface

16 PIN

USB Interface

USB 2.0

Power

DC 5 V - 12 V

Consumption

1 W

Dimensions

Length

95 mm(3.74″)

Width

49 mm(1.93″)

Height

28 mm(1.10″)

Net Weight

85 g

Gross Weight

223 g

BMW Multi Tool User Manual

3.3.System Requirements

PC/Laptop Minimum Specification

Minimum Specification

Recommended Specification

CPU

Pentium 3/1GHz or above

Pentium 4/1.6GHz or above

Memory(RAM)

512M or above

1G or above

HDD

40G or above

60G or above

Display

800 x 600 or above

1024 x 768 or above

Win98/2000/XP/Vista

WinXP

Port

USB

BMW Multi Tool User Manual

4.Software Overview

4.1.Overview

BMW Multi Tool includes forth parts, hardware device, dongle, programmer,

software. Before running software you must connect dongle and hardware

device to computer.

1. OBD II: BMW Multi Tool connects to car directly.

2. CAS PLUG: Connect CAN line manually, support 12V. Detail method followed in next

page.

3. Support EEPROM dump: get EEPROM dump with programmer.

BMW Multi Tool User Manual

1. 7 Series CAS1/CAS2 pin method:

2. CAS2(While Box)/CAS3/CAS3+ pin method:

BMW Multi Tool User Manual

3. Device pin method:
