Black Box KV9632A Manual de usuario

BL A C K B O X®

Combines DVI with USB and audio peripheral

sharing in one unit.

2- and 4-port models are available.

ServSwitch DVI-D USB KVM w/ bidirectional USB and Audio

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax

724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,

PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

KV9632A

KV9634A

Page 2 724-746-5500 | blackbox.com

FCC and IC RFI Statements

FEDERAL COMMUNICATIONS COMMISSION AND

INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy,

and if not installed and used properly, that is, in strict accordance with the

manufacturer’s instructions, may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A computing

device in accordance with the specifications in Subpart B of Part 15 of FCC rules,

which are designed to provide reasonable protection against such interference

when the equipment is operated in a commercial environment. Operation of

this equipment in a residential area is likely to cause interference, in which case

the user at his own expense will be required to take whatever measures may be

necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise

emission from digital apparatus set out in the Radio Interference Regulation

of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la classe A prescrites dans le

Règlement sur le brouillage radioélectrique publié par Industrie Canada.

Normas Oficiales Mexicanas (NOM)

Electrical Safety Statement

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

Page 3

724-746-5500 | blackbox.com

NOM Statement

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,

etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá

lo descrito en las instrucciones de operación. Todo otro servicio deberá ser

referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe

colocar en libreros o gabinetes que impidan el flujo de aire por los orificios

de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el

aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las

lineas de energia.

Page 4 724-746-5500 | blackbox.com

NOM Statement

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

Page 5

724-746-5500 | blackbox.com

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks, and

ServSwitch is a trademark, of BB Technologies, Inc.

Macintosh and Mac are registered trademarks of Apple, Inc.

Windows is a registered trademark of Microsoft Corporation.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

Page 6 724-746-5500 | blackbox.com

Table of Contents

Chapter Page

1. Specifications ............................................................................................7

2. Overview ............................................................................................8

2.1 Introduction ......................................................................................8

2.2 Features ............................................................................................8

2.3 What‘s Included ................................................................................9

2.4 Hardware Description .......................................................................9

2.4.1 KV9632A Front and Back Panels .........................................9

2.4.2 KV9634A Front and Back Panels .......................................10

2.5 System Requirements......................................................................12

2.5.1 Console Side......................................................................12

2.5.2 Computer Side...................................................................12

2.5.3 Cables................................................................................12

3. Installation ..........................................................................................13

3.1 PC BIOS Notice ...............................................................................13

3.2 Console Connection........................................................................13

3.3 Computer Connection ....................................................................14

4. Operation ..........................................................................................16

4.1 Front Panel......................................................................................16

4.1.1 LED Indicators ....................................................................16

4.1.2 Push Buttons......................................................................16

4.1.3 Auto Scan..........................................................................16

4.1.4 Scan Time ..........................................................................16

4.1.5 Adjust the Video (DVI) Signal ............................................17

4.2 Hotkey Commands .........................................................................18

Appendix. Troubleshooting ..............................................................................21

A.1 Problems/Causes/Solutions .............................................................21

A.2 Contacting Black Box ..................................................................... 23

A.3 Shipping and Packaging..................................................................24

Page 7

724-746-5500 | blackbox.com

Chapter 1: Specifications

1. Specifications

Automatic Scan Interval: 3, 8, 15, and 30 seconds

Cable Length (Maximum): 10 ft. (3 m) for USB

DDC2B Support — Yes

Hotkeys: Yes

On-Screen Display (OSD): No

Operation: Hot plug-and-play

Resolution (Maximum): WUXGA: (1920 x 1200), Full HD (1920 x 1080p)

User Controls: KV9632A: (1) front-panel push button;

KV9634A: (4) front-panel push buttons, (1) FUNC button

Connectors: KV9632A: Console interface: (4) USB Type A female ports:

(1) for keyboard, (1) for mouse, (2) for peripheral devices;

(1) DVI-D monitor, (1) set of audio jacks for speaker and microphone;

Computer interface: (2) USB Type B ports, (2) DVI-D for monitors,

(2) sets of audio jacks for speaker and microphone;

KV9634A: Console interface: (4) USB Type A female ports: (1) for keyboard,

(1) for mouse, (2) for peripheral devices; (1) DVI-D monitor, (1) set of

audio jacks for speaker and microphone;

Computer interface: (4) USB Type B ports, (4) DVI-D for monitors,

(4) sets of audio jacks for speaker and microphone

Indicators: KV9632A: (4) LEDs: (2) Computer Online, (2) Computer Selected;

KV9634A: (8) LEDs: (4) Computer Online, (4) Computer Selected

Power: 9 VDC (can accept between 9–12 VDC)

Size: KV9632A: 1.6"H x 6.3"W x 3.9"D (4 x 16 x 10 cm);

KV9634A: 1.6"H x 8.7"W x 3.5"D (4.1 x 22 x 9 cm)

Weight: KV9632A: 1.4 lb. (0.6 kg);

KV9634A: 1.8 lb. (0.8 kg)

Page 8 724-746-5500 | blackbox.com

Chapter 2: Overview

2. Overview

2.1 Introduction

The ServSwitch™DVI-D USB KVM with bidirectional USB and Audio combines USB

KVM, keyboard/video/mouse switching and USB peripheral sharing in one device.

Two models are available: 2-port (KV9632A) and 4-port (KV9634A). You can

easily operate up to four PCs, G3/G4 Macintosh®computers, or Mac®Pros

from a single USB keyboard, USB mouse, and monitor, saving you space, time,

equipment, and money. The peripheral sharing function enables you to share

more USB peripherals among all computers. The units also support bidirectional

audio. Users can switch among up to two or four KVM sources and control the

systems using a USB keyboard and mouse, USB peripherals, and bidirectional

audio, and view them with a DVI-D supported monitor.

Installation is as easy as connecting USB A-B cables between computers and the

ServSwitch DVI-D USB KVM. To select a port, just press the front-panel button(s).

The built-in USB hub ensures smooth switching from one computer to the other.

It reduces redundant cables and encourages a neat and tidy working environment.

The 4-port unit (KV9632A) also includes a FUNC button to adjust video signal

strength.

2.2 Features

• Supports USB keyboards and mice.

• Supports high-resolution video up to UXGA (1600 x 1200)/Full HD (1920 x

1080)/WUXGA (1920 x 1200).

• 2–4 computers can share up to four different USB peripherals (KB + MS + USB

devices).

• A unique multilayered switching system enables the USB (or audio) devices to

operate independently.

• Front-panel push buttons and hotkeys make computer selection easy.

• Supports keyboard and mouse plug-n-play.

• Buzzer sound confirms computer switching.

• Front-panel buttons activate autoscan (KV9634A only).

• Scan time interval is selectable.

• Supports DVI-D quality video.

Page 9

724-746-5500 | blackbox.com

Chapter 2: Overview

• No software is required.

• Supports Windows®and Mac host systems.

• Compatible with most of the popular screen resolutions, such as XGA, SXGA,

UXGA, WSXGA, up to Full HD, WUXGA.

2.3 What’s Included

• (1) 2- or 4-port KVM switch

• (1) external power supply with U.S. power cord

• This user’s manual

• (1) set of rubber feet

2.4 Hardware Description

2.4.1 KV9632A Front and Back Panels

Figures 2-1 and 2-2 illustrate the front and back panels of the KV9632A. Table 2-1

describes its components.

1 2 3

Figure 2-1. KV9632A front panel.

4 5 6 7 9 10 11

8 12 13 14

Figure 2-2. KV9632A back panel.

Page 10 724-746-5500 | blackbox.com

Chapter 2: Overview

Table 2-1. KV9632A front and back panel components.

Number Component Description

1(2) LEDs (1) computer on-line, (1) computer selected for

Port 1

2(2) LEDs (1) computer on-line, (1) computer selected for

Port 2

3Push button Toggles between Computer 1 and Computer 2

4Barrel connector Links to 9–12-VDC power

5Audio connector Links to console headphones/speakers

6Audio connector Links to console microphone

7USB Type A connector Links to keyboard

8USB Type A connector Links to mouse

9(2) USB Type A connectors Links to USB peripherals

10 USB Type B connector Links to CPU 2

11 USB Type B connector Links to CPU 1

12 DVI-D connector LInks to console monitor

13 DVI-D connector Links to CPU 2 video card

14 DVI-D connector Links to CPU 1 video card

2.4.2 KV9634A Front and Back Panels

Figures 2-3 and 2-4 illustrate the front and back panels of the KV9634A. Table 2-2

describes its components.

2 4 5

1 1 1 1 3

Figure 2-3. KV9634A front panel.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Black Box

Black Box

Black Box ServSwitch ACR9000A Manual de usuario

Black Box

Black Box LIE1014A Manual de usuario

Black Box

Black Box VSW-HDMI8X8-B Manual de usuario

Black Box

Black Box VSW-HDMI2-3X1 Manual de usuario

Black Box

Black Box KV7000A Manual de usuario

Black Box

Black Box KV2304A Manual de usuario

Black Box

Black Box ServSwitch DTX5000-R Manual de usuario

Black Box

Black Box INTEL EXPRESS 410T Hoja de especificaciones

Black Box

Black Box ServSwitch DTX5000 Manual de usuario

Black Box

Black Box KV9502A Manual de usuario

Black Box

Black Box IDM-AP-100 Manual de usuario

Black Box

Black Box AVSC-0401H Manual de usuario

Black Box

Black Box ServSensor JR EME102A Manual de usuario

Black Box

Black Box SW590A-R2 Manual de usuario

Black Box

Black Box AC447A Manual de usuario

Black Box

Black Box ACU7017A Manual de usuario

Black Box

Black Box LB8405A-R2 Manual de usuario

Black Box

Black Box ServSwitch Wizard SW652A Manual de usuario

Black Box

Black Box IC1026A Manual de usuario

Black Box

Black Box ServSwitch Plus Series Manual de usuario

Black Box

Black Box ServSwitch Wizard MP KV804A Manual de usuario

Black Box

Black Box KV5300 Series Manual de usuario

Black Box

Black Box MT760A-232/232 Manual de usuario

Black Box

Black Box LB9020A-R2 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
