Black Box Veri-NAC LVN5600A Manual de usuario

724-746-5500 | blackbox.com

About Black Box

Black Box Network Services is your source for more than 118,000 networking and infrastructure products. You’ll find everything

from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by

free, live 24/7 Tech support available in 20 seconds or less.

BLACK BOX®

Black Box Tech Support: FREE! Live. 24/7.

Tech support the

way it should be.

Great tech support is just 20 seconds away at 724-746-5500 or blackbox.com.

BL A C K B OX®

Veri-NAC™—the fastest to deploy, easiest to use

Network Access Control (NAC) appliance for

Intrusion Prevention, vulnerability management,

and regulatory compliance.

Veri-NAC Quick Start Guide

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) •

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 •

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 •

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

September 2009

LVN5200A LVN5600A

LVN5250A LVN5800A

LVN5400A

724-746-5500 | blackbox.com

Page 2

Veri-NAC Quick Start Guide

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks, and Veri-NAC is a trademark, of BB Technologies, Inc.

Microsoft and Internet Explorer are registered trademarks of Microsoft Corporation.

Mozilla and Firefox are registered trademarks of Mozilla Foundation Corporation.

Opera is a trademark of Opera Software ASA Corporation Norway.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

724-746-5500 | blackbox.com

Page 3

FCC and IC RFI Statements

Federal Communications Commission and Industry Canada Radio Frequency Interference

Statements

This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict

accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to

comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,

which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own

expense will be required to take whatever measures may be necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio

Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de

la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.

724-746-5500 | blackbox.com

Page 4

Veri-NAC Quick Start Guide

Instrucciones de Seguridad

(Normas Oficiales Mexicanas Electrical Safety Statement)

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca

de una alberca, etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.

Todo otro servicio deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico

sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes

que impidan el flujo de aire por los orificios de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros

aparatos (incluyendo amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como

se indique en el aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados

sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com

Page 5

We‘re here to help! If you have any questions about your application

or our products, contact Black Box Tech Support at 724-746-5500

or go to blackbox.com and click on “Talk to Black Box.”

You’ll be live with one of our technical experts in less than 20 seconds.

Table of Contents

1. Setting Up the Veri-NAC Appliance ......................................................................................................................................................... 6

1.1 What’s Included .................................................................................................................................................................................. 6

1.2 LVN5200A/LVN5250A and LVN5400A/LVN5600A/LVN5800A Appliances .......................................................................................... 6

2. Configuring the Browser ........................................................................................................................................................................12

2.1 Internet Explorer—Cache Issues .........................................................................................................................................................12

2.2 Internet Explorer—Security Issues.......................................................................................................................................................13

2.3 Mozilla Firefox—Security Issues ..........................................................................................................................................................15

3. Troubleshooting .....................................................................................................................................................................................17

724-746-5500 | blackbox.com

Page 6

Veri-NAC Quick Start Guide

1. Setting Up the Veri-NAC Appliance

The Veri-NAC Appliance can help provide better Network Access Control and help prevent intrusions on your network.

There are five Veri-NAC models: LVN5200A, LVN5250A, LVN5400A, LVN5600A, and LVN5800A rackmountable 1U appliances.

1.1 What’s Included

Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support at

724-746-5500.

LVN5200A, LVN5250A:

• Veri-NAC appliance

• (2) EVNSL81-0010 cables

• This printed Quick Start Guide, a Default Password Sheet, and a License Agreement

• This QSG, full manual, readme file, and FAQ on CD-ROM

• Printed read.me document

LVN5400A, LVN5600A, LVN5800A:

• Veri-NAC appliance

• EVNSL81-0010 cables ([4] for LVN5400A, [6] for LVN5600A, [8] for LVN5800A)

• This printed Quick Start Guide, a Default Password Sheet, and License Agreement

• Printed full manual

• This QSG, full manual, readme file, and FAQ on CD-ROM

• Printed read.me document

1.2 LVN5200A/LVN5250A and LVN5400A/LVN5600A/LVN5800A Applicances

To set up the Veri-NAC appliance on your network, connect it to the first switch or hub inside your firewall. Then follow these

steps:

Step One: Connect to Your Network

1. A power cable is included with each Veri-NAC. Connect the power cable to the power jack on the rear side, on the far left end

of the appliance and to a 3-prong grounded 120-VAC, 60-Hz outlet.

NOTE: We strongly recommend that you plug your Veri-NAC appliance into a surge protector to ensure that your appliance is

protected from voltage spikes.

2. Connect your local area network to the Ethernet 0 port (labeled Eth0) on the rear of the Veri-NAC appliance (see Figure 1-2 or

1-4).

Figure 1-1 shows the LVN5200A/LVN5250A front panel. Table 1-1 describes its components.

1 2 345 6 7

8 9

Figure 1-1. LVN5200A/LVN5250A front panel.

724-746-5500 | blackbox.com

Page 7

Chapter 1: Setting Up the Veri-NAC Appliances

Table 1-1. LVN5200A/LVN5250A front panel components.

Number Component Description

1 System overheat LED Lights when the system overheats

2, 3 Network activity LEDs Lights during activity on the network

4 Hard drive activity LED Lights during activity on the hard drive

5 Power LED Lights when the unit is powered on

6 System reset button Press this button to reset the system

7 Power ON/OFF button Press this button to turn power ON/OFF

8, 9 Vent holes for airflow Allows for system cooling

Figure 1-2 shows the LVN5200A/LVN5250A back panel. Table 1-2 describes its components.

1 2 3 4 5

6 7 8 9 10 11 12

Figure 1-2. LVN5200A/LVN5250A back panel.

Table 1-2. LVN5200A/LVN5250A back panel components.

Number Component Description

1 IEC 320 power connector Connects to power

2 PS/2 mouse connector Links to PS/2 mouse

3, 12 Air holes Allow cooling

4 Not used —

5 Expansion slot cover Covers expansion slots

6 PS/2 keyboard connector Links to PS/2 keyboard

7 (2) USB Type A ports Links to USB peripherals

8 DB9 serial Links to serial connector

9 HD15 VGA Links to monitor

10 Eth 0 Connects to LAN 1

11 Eth 1 Connects to LAN 2

724-746-5500 | blackbox.com

Page 8

Veri-NAC Quick Start Guide

Figure 1-3 shows the LVN5400A/LVN5600A/LVN5800A models’ front panel. Table 1-3 lists its components.

1 2 345 6 7

8 9

Figure 1-3. LVN5400A/LVN5600A/LVN5800A front panel.

Table 1-3. LVN5400A/LVN5600A/LVN5800A components.

Number Component Description

1 System overheat LED Lights when the system overheats

2, 3 Network activity LEDs Lights during activity on the network

4 Hard drive activity LED Lights during activity on the hard drive

5 Power LED Lights when the unit is powered on

6 System reset button Press this button to reset the system

7 Power ON/OFF button Press this button to turn power ON/OFF

8, 9 Vent holes for airflow Allows for system cooling

Figures 1-4 through 1-6 show the LVN5400A/LVN5600A/LVN5800A models’ back panels. Table 1-4 lists their components.

Figure 1-4. LVN5400A back panel.

Figure 1-5. LVN5600A back panel.

1 2 3 4 11 12

5 6 7 8 9 10

1 2 3 4 11 12 13 14

5 6 7 8 9 10

724-746-5500 | blackbox.com

Page 9

Chapter 1: Setting Up the Veri-NAC Applicance

Figure 1-6. LVN5800A back panel.

Table 1-4. LVN5400A/LVN5600A/LVN5800A components.

Number Component Description

1 IEC 320 power connector Connects to power

2 PS/2 mouse connector Links to PS/2 mouse

3 Air holes Allow cooling

4 Not used —

5 PS/2 keyboard connector Links to PS/2 keyboard

6 (2) USB Type A ports Links to USB peripherals

7 DB9 serial Links to serial connector

8 HD15 VGA Links to monitor

9 Eth 0 (LVN5400A, LVN5600A, LVN5800A) Connects to LAN 0

10 Eth 1 (LVN5400A, LVN5600A, LVN5800A) Connects to LAN 1

11 Eth 2 (LVN5400A, LVN5600A, LVN5800A) Connects to LAN 2

12 Eth 3 (LVN5400A, LVN5600A, LVN5800A) Connects to LAN 3

13 Eth 4 (LVN5600A) Connects to LAN 4

14 Eth 5 (LVN5600A) Connects to LAN 5

15 Eth 4 (LVN5800A) Connects to LAN 4

16 Eth 5 (LVN5800A) Connects to LAN 5

17 Eth 6 (LVN5800A) Connects to LAN 6

18 Eth 7 (LVN5800A) Connects to LAN 7

NOTE: The network cable must be CAT5 cable or higher with RJ-45 connectors.

1 2 3 4 16 15 12 11 10 9

5 6 7 8 17 18

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de Black Box

Black Box

Black Box TS580A-R4 Manual de usuario

Black Box

Black Box EncrypTight ET0010A Manual de usuario

Black Box

Black Box LB0010A-A24-R2 Manual de usuario

Black Box

Black Box JPM083A Manual de usuario

Black Box

Black Box IC457A-F Manual de usuario

Black Box

Black Box ServSwitch KV1081A Manual de usuario

Black Box

Black Box ACR2004A Manual de usuario

Black Box

Black Box Time-Division Multiplexor Manual de usuario

Black Box

Black Box RF200A Manual de usuario

Black Box

Black Box Secure Site Manager 8 Manual de usuario

Black Box

Black Box MC144A Manual de usuario

Black Box

Black Box ServSelect KV119A Instrucciones de instalación y mantenimiento

Black Box

Black Box LWS100AE Manual de usuario

Black Box

Black Box Veri-NAC Manual

Black Box

Black Box ServSwitch KV754A Manual de usuario

Black Box

Black Box IT Pro LNA1000A Manual de usuario

Black Box

Black Box Palm-Sized Ethernet Switch Express 8-Port... Manual de usuario

Black Box

Black Box IC448A Manual de usuario

Black Box

Black Box Balun G.703 Manual de usuario

Black Box

Black Box MT1050A Manual de usuario

Black Box

Black Box JPM806A-HD Manual de usuario

Black Box

Black Box LB410A Manual de usuario

Black Box

Black Box Lineshare Pro AC FX150A Manual de usuario

Black Box

Black Box ETHERLINK IV Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
