Beyerdynamic CM 930 Manual de usuario

CM 930 / DM 960

DM 969 / EM 981

RM 510

Mikrofonköpfe

Microphone Capsules

Têtes de microphone

PRODUKTINFORMATION

PRODUCT INFORMATION

INFORMATIONS DE PRODUIT

Réglage de l’atténuation des basses . . . . . . . . . . Page 12

Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 12

Spécifications techniques. . . . . . . . . . . . . . . . . . . Page 14

Evacuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16

INHALT / CONTENTS / SOMMAIRE

PRODUKTINFORMATION

deutsch

Einstellen der Tiefenabsenkung . . . . . . . . . . . . . . Seite 4

Pflege . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Seite 4

Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . Seite 6

Entsorgung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Seite 16

PRODUCT INFORMATION

english

How to set the low-cut filter . . . . . . . . . . . . . . . . Page 8

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 8

Technical Specifications . . . . . . . . . . . . . . . . . . . . Page 10

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16

INFORMATIONS DE PRODUIT

français

PRODUCT INFORMATION

CM 930 / DM 960 / DM 969 / EM 981 /RM 510

There are different microphone capsules available for the S 900,

S 910 and S 600 handheld transmitters of the Opus 900, Opus

910 and Opus 600 wireless microphone systems. If you want to

change the microphone capsule, turn it anti-clockwise to unscrew

it from the transmitter. Put the selected microphone capsule onto

the transmitter and turn it clockwise to tighten.

How to set the low-cut filter

Unscrew microphone head Set low-cut filter

• The CM 930 and EM 981 microphone capsules feature a low-

cut filter to compensate the close-miking effect which ususally

occurs with directional microphones. To set the low-cut filter

unscrew the complete microphone head with the upper shaft

as indicated by the arrows.

• At the bottom of the microphone head you can set the low-

cut filter.

•Standard setting: linear (position Lin)

Maintenance

• Protect the handheld transmitter from humidity, knocks and

shock. Avoid dropping the transmitter at all times.

• For cleaning metal surfaces, use a soft cloth moistened with

methylated spirits or alcohol.

• As soon as your microphone sounds dull, you should clean the

integrated pop shield. Proceed as described in the following.

CM 930 DM 960 DM 969 EM 981 RM 510

english

CM 930 / EM 981

• Unscrew the microphone capsule (turn anti-clockwise).

• Unscrew the wire mesh pop shield (turn anti-clockwise).

• Clean the pop shield under clear running water.

• Allow the pop shield to dry overnight before you replace it.

• The wire mesh pop shield cannot be cleaned in a dishwasher.

DM 960

• Unscrew the upper part of the microphone

basket (turn anti-clockwise).

• Clean it under clear water.

• Let the pop shield dry overnight before you

replace it.

• The upper part of the microphone basket

cannot be cleaned in a dishwasher.

DM 969

• Unscrew the upper part of the microphone

basket (turn anti-clockwise).

• Pull out the foam pop shield and clean it

under clear running water.

• If necessary, use a mild washing-up liquid.

• Dry it afterwards with a hairdryer or allow it

to dry overnight.

• Place the dry pop shield inside the

microphone basket and replace the

microphone basket by screwing it on

clockwise.

CM 930 EM 981

RM 510

• Loosen the screws.

• Unscrew the upper part of the microphone

head (turn anti-clockwise).

• Clean the upper basket under clear running

water.

• Allow the upper basket to dry overnight

before you replace it.

• The upper basket cannot be cleaned in a

dishwasher.

Technical Specifications

CM 930

Polar pattern . . . . . . . . . . . . . . . . . . . Cardioid

Transducer type . . . . . . . . . . . . . . . . . True condenser

Frequency response . . . . . . . . . . . . . . 40 - 20,000 Hz

Nominal impedance . . . . . . . . . . . . . . 180 Ω

Load impedance. . . . . . . . . . . . . . . . . 1 kΩ

Open circuit voltage . . . . . . . . . . . . . . 3 mV/Pa

Max. SPL (w/hout pre-attenuation). . . 146 dB

Signal-to-noise ratio . . . . . . . . . . . . . . 71 dB

A-weighted equivalent SPL. . . . . . . . . 16 dB

Dimensions

Capsule diameter . . . . . . . . . . . . . . . . 48 mm

Shaft diameter . . . . . . . . . . . . . . . . . . 38 mm

Length . . . . . . . . . . . . . . . . . . . . . . . . 105.5 mm

Weight. . . . . . . . . . . . . . . . . . . . . . . . 191 g

DM 960

Polar pattern . . . . . . . . . . . . . . . . . . . Hypercardioid

Transducer type . . . . . . . . . . . . . . . . . Dynamic

Frequency response . . . . . . . . . . . . . . 90 - 16,000 Hz

Nominal impedance . . . . . . . . . . . . . . 280 Ω

Load impedance. . . . . . . . . . . . . . . . . 1 kΩ

Open circuit voltage . . . . . . . . . . . . . . 3 mV/Pa

Magnetic field suppression. . . . . . . . . > 20 dB at 50 Hz

Dimensions

Capsule diameter . . . . . . . . . . . . . . . . 54 mm

Shaft diameter . . . . . . . . . . . . . . . . . . 38 mm

Length . . . . . . . . . . . . . . . . . . . . . . . . 109.5 mm

Weight. . . . . . . . . . . . . . . . . . . . . . . . 191 g

english

DM 969

Polar pattern . . . . . . . . . . . . . . . . . . . Supercardioid

Transducer type . . . . . . . . . . . . . . . . . Dynamic

Frequency response . . . . . . . . . . . . . . 95 - 14,000 Hz

Nominal impedance . . . . . . . . . . . . . . 290 Ω

Load impedance. . . . . . . . . . . . . . . . . 1 kΩ

Open circuit voltage . . . . . . . . . . . . . . 2.5 mV/Pa

Magnetic field suppression. . . . . . . . . > 20 dB at 50 Hz

Dimensions

Capsule diameter . . . . . . . . . . . . . . . . 50 mm

Shaft diameter . . . . . . . . . . . . . . . . . . 38 mm

Length . . . . . . . . . . . . . . . . . . . . . . . . 106.5 mm

Weight. . . . . . . . . . . . . . . . . . . . . . . . 131 g

EM 981

Polar pattern . . . . . . . . . . . . . . . . . . . Cardioid

Transducer type . . . . . . . . . . . . . . . . . Electret condenser

Frequency response . . . . . . . . . . . . . . 50 - 18,000 Hz

Nominal impedance . . . . . . . . . . . . . . 190 Ω

Load impedance. . . . . . . . . . . . . . . . . 1 kΩ

Open circuit voltage . . . . . . . . . . . . . . 3,2 mV/Pa

Max. SPL (w/hout pre-attenuation). . . 146 dB

Signal-to-noise ratio . . . . . . . . . . . . . . 60 dB

A-weighted equivalent SPL. . . . . . . . . 26 dB

Dimensions

Capsule diameter . . . . . . . . . . . . . . . . 48 mm

Shaft diameter . . . . . . . . . . . . . . . . . . 38 mm

Length . . . . . . . . . . . . . . . . . . . . . . . . 105.5 mm

Weight. . . . . . . . . . . . . . . . . . . . . . . . 191 g

RM 510

Polar pattern . . . . . . . . . . . . . . . . . . . Cardioid

Transducer type . . . . . . . . . . . . . . . . . Dynamic (ribbon)

Frequency response . . . . . . . . . . . . . . 90 - 14,000 Hz

Nominal impedance . . . . . . . . . . . . . . 140 Ω

Load impedance. . . . . . . . . . . . . . . . . 1 kΩ

Open circuit voltage . . . . . . . . . . . . . . 2.5 mV/Pa = -52.0 dBV

Max. SPL . . . . . . . . . . . . . . . . . . . . . . 148 dB SPL

Magnetic field suppression. . . . . . . . . > 20 dB bei 50 Hz

Dimensions

Capsule diameter . . . . . . . . . . . . . . . . 56 mm

Shaft diameter . . . . . . . . . . . . . . . . . . 38 mm

Length . . . . . . . . . . . . . . . . . . . . . . . . 96 mm

Weight. . . . . . . . . . . . . . . . . . . . . . . . 165 g

Entsorgung

Dieses Produkt darf am Ende seiner Lebensdauer

nicht über den normalen Haushaltsabfall entsorgt

werden, sondern muss an einem Sammelpunkt für

das Recycling von elektrischen und elektronischen

Geräten abgegeben werden. Das Symbol auf dem

Produkt, der Gebrauchsanweisung oder der

Verpackung weist darauf hin.

Disposal

This symbol on the product, in the instructions or

on the packaging means that your electrical and

electronic equipment should be disposed at the

end of its life separately from your household

waste. There are separate collection systems for

recycling in the EU. For more information, please

contact the local authority or your retailer where

you purchased the product.

Evacuation

Ce symbole sur le produit, l’emballage ou dans le

manuel signifie que votre équipement électrique et

électronique doit être, en fin de vie, jeté sépare-

ment de vos déchets ménages. Il existe en France

des systèmes de collecte différents pour les

déchets recyclables. Pour plus d’information, veuillez

contacter les autorités locales ou le revendeur chez

qui vous avez acheté le produit.

DEF1/PI CM 930/DM960/DM969/EM981/RM510 (11.10)/623.725/Hoh • Änderungen, Irrtümer und Druckfehler vorbehalten • Subject to change without notice • Sous réserve de modifications • Printed in Germany

beyerdynamic GmbH & Co. KG

Theresienstr. 8 | 74072 Heilbronn – Germany

Tel. +49 (0) 7131 / 617 - 0 | Fax +49 (0) 7131 / 617 - 204

[email protected] | www.beyerdynamic.com

Weitere Vertriebspartner weltweit finden Sie unter www.beyerdynamic.com

For further distributors worldwide, please go to www.beyerdynamic.com
