Users Instructions and

Customer Care Guide

R 25 & 30 HE combi Condensing boiler

R 28 HE system Condensing boiler

ZWB 7-25 R 25 HE GC-Number: 47 311 77

ZWB 7-30 R 30 HE GC-Number: 47 311 78

ZB 7-28 R 28 HE system GC-Number: 47 311 62

6 720 610 577 GB (03.11) TD

6720 610 577-01.10

Supplied By www.heating spares.co Tel. 0161 620 6677

Contents

6 720 610 577 GB (03.11)

Contents

Excellence comes as standard 3

Safety precautions 4

1General notes 5

2Controls 9

3Operating the Appliance 10

3.1 Preparation 10

3.2 Switching the Appliance On/Off 12

3.3 Switching on the Central Heating 13

3.4 Controlling Central Heating 13

3.5R25 & 30 Boilers: Setting the Hot Water Temperature 13

3.6 Summer Mode, Hot Water Only

(R 25 & 30 Appliances) 15

3.7 Frost protection (R 25 & 30 Appliances) 16

3.8 Fault Condition 16

4Tipsonsaving energy 17

5General Information 19

6Maintaining your appliance 19

7Service 20

8Faultorbreakdown 21

9Yourguarantee 22

10 Guarantee registration 23

11 Operating Instructions Quick Reference 24

Supplied By www.heating spares.co Tel. 0161 620 6677

Excellence comes as standard

6 720 610 577 GB (03.11)

Excellence comes as standard

Thank you for purchasing an R 25 & 30/R 28 condensing appli-

ance.

The R 25 & 30/R 28 Series has been developed by the Bosch

Group and the strictest quality control standards are demanded

throughout every stage of production.

Indeed, the Bosch Group have led the field in innovative appliance

design and performance for many years.

The result is that your new R 25 & 30/R 28 appliance offers you

the very best of everything – quality, efficiency, economical run-

ning costs, proven reliability and value for money.

What’s more, you also have the assurance of our no nonsense

2yearparts and labour guarantee.

And it’s backed up by Worcester Heat Systems Ltd. - Offering a

complete maintenance scheme to keep your boiler operating at

peak condition and efficiency.

No wonder that more and more people are agreeing that when it

is gas, it has to be a Worcester Heat Systems Ltd. Condensing

appliance.

Benchmark

The “Benchmark” initiative is the new code of practice to encour-

age the correct installation, commissioning and servicing of

domestic central heating boilers and system equipment.

The “log-book” is a vital document that must be completed by the

installer at the time of installation. It confirms that the boiler has

been installed and commissioned according to the manufactur-

ers’ instructions.

Without the completion of the “log-book”, manufacturers may

refuse to respond to a call–out from a householder, who will be

advised that he or she must call back the installer, who has not ful-

filled his obligations to record the information required by the ini-

tiative.

Supplied By www.heating spares.co Tel. 0161 620 6677

Safety precautions

6 720 610 577 GB (03.11)

Safety precautions

Gas Safety (Installation and Use) Regulations 1998

It is the law that all gas appliances are installed by a competent

person in accordance with the above regulations. Failure to install

appliances correctly could lead to prosecution. It is in your inter-

est, and that of safety, to ensure compliance with the law.

If you smell gas:

BTurn off gas service cock at the meter.

BOpen all doors and windows.

BDo not operate any electrical switches.

BDo not smoke.

BExtinguish any naked flames.

BCall your gas company.

If you smell fumes from the appliance:

BSwitch off appliance.

BOpen windows and doors.

BInform your heating engineer.

Fitting and modifications

BFitting of the appliance or any modifications to the appliance

may only be carried out by a competent person.

BFlue systems must not be modified in any way.

Maintenance

BWe recommend that you take out a maintenance contract

with a competent installer and have the appliance serviced at

regular intervals.

BEnsure that your Service Engineer uses only genuine spare

parts!

Supplied By www.heating spares.co Tel. 0161 620 6677

General notes

6 720 610 577 GB (03.11)

Combustible materials

BDo not store or use any combustible materials (paper, thin-

ners, paints etc.) in the vicinity of the appliance.

Health and safety

BThis appliance contains no asbestos products.

BThere is no potential hazard due to the appliance being electri-

cally unsafe.

BThere are no substances used in the construction that are a

potential hazard in relation to the COSHH Regulations (Con-

trol of Substances Hazardous to Health Regulations 1988).

Combustion Air/Ambient Air

BKeep combustion air/ambient air free of corrosive substances

(e.g. halogenated hydrocarbons which contain chlorine or flu-

orine compounds). In this way corrosion can be prevented.

1General notes

To get the best from your appliance please read these instructions

carefully.

Sealed heating systems

The appliance is fitted to a sealed heating system which is pre-

pressurised. Your installer will tell you of the minimum and maxi-

mum pressure which must be indicated on the pressure gauge.

Check regularly that the pressure is maintained and contact your

installer or maintenance engineer if there is a permanent signifi-

cant drop in the pressure. If the system loses pressure it should

be repressurised and the cause of the fall investigated.

Central heating systems

During the first few hours of operation of the central heating sys-

tem, check that all radiators are being heated at an even rate. If the

top of a radiator is at a lower temperature than the bottom then it

should be vented by releasing air through the venting screw at the

top of the radiator. Ask your installer to show you how this is done.

Supplied By www.heating spares.co Tel. 0161 620 6677

General notes

6 720 610 577 GB (03.11)

Repeated venting will reduce the quantity of water in the system

and this must be replenished for safe and satisfactory operation

of the appliance.

Should water leaks be found in the system or excessive venting is

required then a service engineer must be contacted to inspect the

installation and rectify any fault.

Only additives that are compatible with aluminium may be used in

the system. Any incompatible additive used will invalidate the

guarantee.

Condensate drain

This is a condensing appliance and the terminal will, at times, give

out a plume of water vapour. This is quite normal.

The appliance produces quantities of condensate which is dis-

charged regularly through the siphon.

Clearances

Your installer will have provided adequate space around the appli-

ance for safety and servicing access. Do not restrict this space

with the addition of cupboards, shelves etc. next to the appliance.

Room thermostat

A room thermostat may be fitted to control the central heating.

Refer to the instructions supplied with the thermostat for informa-

tion on siting and setting. A programmable thermostat may also be

used with this appliance to provide additional timed control of the

central heating.

Left-hand side 5 mm

Right-hand side 5 mm

In Front 600 mm

Above Casing (Vert. Flue) 200 mm

Above Flue Turret 30 mm

Below 200 mm

Table 1

Supplied By www.heating spares.co Tel. 0161 620 6677

General notes

6 720 610 577 GB (03.11)

Thermostatic radiator valves

It is recommended that this type of valve is fitted to all the radiators

except one, usually a radiator where the room thermostat is fitted.

They should conform to the requirements of BS2767:10.

Showers, bidets, taps and mixing valves – R 25 & 30

Boilers

Standard hot and cold taps and mixing valves must be suitable for

operating at mains pressure. Thermostatically controlled or pres-

sure equalising shower valves will guard against the flow of water

at too high a temperature.

Hot and cold mains fed water can be supplied directly to an over-

rim flushing bidet subject to local water company requirements.

With all mains fed systems the flow of water from individual taps

will vary with the number of outlets operated simultaneously and

the cold water mains supply pressure to the property.

Flow balancing using “ball-o-fix” type valves is recommended to

avoid an excessive reduction in flow to individual outlets.

For further information contact Worcester Heat Systems Ltd.

Technical Services Department.

Hot and cold flow – R 25 & 30 Boilers

The flow of water demanded from both hot and cold service out-

lets is dependent upon the mains supply. It may not be possible in

some installations to operate all outlets simultaneously.

Water mains failure – R 25 & 30 Boilers

If there is a failure of the mains water supply then no water will be

available at a tap or shower until the mains supply is restored. The

appliance will still operate in the central heating mode.

Use in hard water areas – R 25 & 30 Boilers

In exceptionally hard water areas a device to prevent scale forma-

tion may be fitted. Installation of a scale inhibitor assembly should

be in accordance with the requirements of the local water com-

pany. An isolating valve should be fitted to allow for servicing.

Supplied By www.heating spares.co Tel. 0161 620 6677

General notes

6 720 610 577 GB (03.11)

Alternatively the maximum temperature of the domestic hot water

may be reset to about 45 °C which will reduce the risk of scale

formation in these hard water areas.

Ventilation

This is a room sealed appliance and does not require any air for

combustion from inside the house. If the appliance is fitted into a

cupboard or a compartment is built around the appliance after

installation then the compartment must be separated from the

boiler space by a perforated non-combustible partition as

described in BS6798.

Notwithstanding the requirements of BS6798, there is no need

for ventilation openings to be provided in the compartment

because of the low heat loss from the casing.

Do not allow the flue terminal fitted on the outside wall to become

obstructed or damaged.

Pump

The pump will have been set by the manufacturer and must not be

manually re-adjusted.

Supplied By www.heating spares.co Tel. 0161 620 6677

Controls

6 720 610 577 GB (03.11)

2Controls

8.1 System Pressure gauge

61 Reset button

135 Master switch

136 Central heating temperature control

170 Service valves in CH flow and return

171 Hot water

172 Gas isolation valve (open)

173 Cold water inlet

295 Identification sticker

310 Hot water temperature control (R 25 & 30)

317 Display

363 Indicator lamp for “burner on”

364 Indicator lamp for “off/on”

365 “Chimney sweep” button

366 Service button

367 “ECO” button

422 Optional timer

365 61 317 366 367

ECO

310 422

364

135

295

136

170

363

172 170

173

6 720 610 600-01.1O

8.1

171

Supplied By www.heating spares.co Tel. 0161 620 6677

Operating the Appliance

6 720 610 577 GB (03.11)

3Operating the Appliance

3.1 Preparation

Turn on the gas cock (172).

BPress in the handle and turn it anti-clockwise as far as the stop

(when handle is in line with direction of flow, the cock is open).

Central heating system valves (170)

BUsing a spanner, turn square nut until groove is in line with

direction of flow (see detail).

Groove at right angles to direction of flow = off.

Cold water inlet valve (173)

BTurn handle so that it is in line with direction of flow.

When handle is at right angles to direction of flow, the valve is

closed.

170

172 173

6 720 610 577-02.1O

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Caldera de Benchmark

Benchmark

Benchmark Alpha CD18S Guía del usuario

Benchmark

Benchmark mCHP BoilerMate Guía del usuario

Benchmark

Benchmark Metropolis DGT 25 BF Guía del usuario

Benchmark

Benchmark Procombi A Series Nota de publicación

Benchmark

Benchmark i-mini 30 Manual de usuario

Benchmark

Benchmark BoilerMate BMA 125 OV Guía del usuario

Benchmark

Benchmark GulfStream A-CLASS Manual de usuario

Benchmark

Benchmark Planet Dewy 90A Guía del usuario

Benchmark

Benchmark Buderus 600-28C Manual de usuario

Benchmark

Benchmark Ideal Boilers Vogue S15IE Manual de usuario

Benchmark

Benchmark RKA 100 Manual

Benchmark

Benchmark ZSBR 7-30 RD 430i Guía del usuario

Benchmark

Benchmark Alpha InTec 24X Guía del usuario

Benchmark

Benchmark Europa 24 Manual de usuario

Benchmark

Benchmark RD109 Manual de usuario

Benchmark

Benchmark Alpha E-Tec 20NXS Manual de usuario

Benchmark

Benchmark i-mini 30 Manual de usuario

Benchmark

Benchmark CS1 Guía del usuario

Benchmark

Benchmark Alpha E-Tec Plus 28 Guía del usuario

Benchmark

Benchmark ACCOLADE 2000 Guía del usuario

Benchmark

Benchmark VOKERA Mynute 12 VHE Manual de usuario

Benchmark

Benchmark Calydra green 24 Nat Manual de usuario

Benchmark

Benchmark GB10 Guía del usuario

Benchmark

Benchmark ZWB 7-29 CC1 Manual de usuario

Manuales populares de Caldera de otras marcas

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manual de usuario

Radijator

Radijator BIO max 23.1 Manual de usuario

Brunner

Brunner BSV 20 Manual de usuario

Buderus

Buderus Logamax GB062-24 KDE H V2 Manual de usuario

Potterton

Potterton 50e Hoja de datos

UTICA BOILERS

UTICA BOILERS TriFire Manual de usuario

Joannes

Joannes LADY Series Manual

ECR International

ECR International UB90-125 Manual de instrucciones

Froling

Froling FHG Turbo 3000 Manual de usuario

Froling

Froling P4 Pellet 8 - 105 Manual de usuario

U.S. Boiler Company

U.S. Boiler Company K2 Manual de usuario

Henrad

Henrad C95 FF Manual de usuario

NeOvo

NeOvo EcoNox EF 36 Manual de usuario

Potterton

Potterton PROMAX SL 12 Manual de usuario

Eco Hometec

Eco Hometec EC 25 COMPACT Manual de usuario

Viessmann

Viessmann VITODENS 200 Guía

Baxi

Baxi Prime 1.24 Manual de usuario

REXNOVA

REXNOVA ISA 20 BITHERMAL Manual de usuario
