BEMIS BioBidet A1 Manual de usuario

User Manual

A1 Bidet Sprayer

TABLE OF

CONTENTS

PRODUCT INFORMATION

Product Installation..................................................4

Parts.................................................................................5

PRODUCT INSTALLATION

Pre-Installation...........................................................6

Installation....................................................................7

PRODUCT OPERATION

Operation......................................................................12

WARRANTY

Warranty.......................................................................14

4 5

FEATURES PARTS

•High quality ceramic valve

•Dual Sprayer

•6” Comfortable handle body

•Easy D.I.Y. installation

•Ambient temperature bidet wash

•Adjustable water pressure

•58” Metal spiral hose

•No electricity or batteries required

•One year warranty

6 7

PRE-INSTALLATION INSTALLATION

CAUTION:

Do not over tighten any connections. Over tightening connections

can cause damage to the parts and cause leaking.

NOTICE:

Observe all local plumbing, electrical, and building codes.

When installing this unit, be sure that the water supply valve

is fully turned off. Failure to do so can result in flooding and

water damage.

1. Shut off the water

supply to the toilet.

•Flush the toilet to drain

all water inside the tank.

•Attach the 7/8” T-valve

shutoff to the threaded

fill valve on your toilet.

Be sure the 7/8” flat

washer is in the T-valve

before installing. Position

the T-valve so that the

shuttoff handle is facing

the front of the toilet.

2. Disconnect the supply

line from the toilet

fill valve.

8 9

INSTALLATION (CONT.)

3. Reattach your existing

toilet supply line.

•Reattach your

existing toilet supply

line to the bottom of

the T-valve. Be sure

all connections are

secure, and no leaking

or water is present.

4. Remove protective

plastic covers.

•Remove protective

plastic covers on

threaded caps from the

ends of the 48” stainless

steel supply hose. Attach

the hex-head end of the

hose to the T-valve.

NOTICE

This device is designed for connection to a cold water source

with a pressure of 20-80 psi.

5. Attach the Handheld Bidet to the

other end of the supply hose.

6. Mounting Spray

Option 1: Toilet Mount

Option 2: Wall mount

•As a precaution, slide the level

on the handheld bidet sprayer

to “off,” which is away from the

sprayer head.

•Carefully remove toilet lid and

place holder in desired location.

•Using a Philips screwdriver,

remove the plastic toilet clip.

Find desired location on the

wall near your toilet. Use the

included screw to attach the

holster to the wall.

•Make sure to use an

expanding nut if you are

attaching to dry wall.

10 11

7. Turn on the water supply valve.

•Turn on the water supply valve on the back wall and check

for any leaks. Use common plumbers tape if necessary on any

leaking threads, reattach and test again. Carefully remove

toilet lid and place holder in desired location.

INSTALLATION (CONT.)

12 13

Short Term Non-Use

It is highly recommended that the water supply

valve is turned off when not in use.

NOTE:

If any leaks occur, check all rubber washers and make sure

all connections are tight and secure. If leaking persists,

discontinue use of the unit, turn off the water source and

contact [email protected]om.

OPERATION

How To Use

•Open the T-valve to allow water to flow to the

Handheld Bidet Sprayer.

•Direct the Handheld Bidet to the appropriate area and

slide the lever to the “on” position.

•When finished, slide the lever to the “off” position and

close the T-valve.

NOTE: THE T-VALVE MUST BE SHUT OFF

AFTER EACH USE.

Failure to turn off after each use may cause flooding and water

damage. BBC Innovation LLC is not responsible for damage that is

caused by failure to follow this instruction.

Cleaning the A1

Your A1 is made with a higher grade fire-retardant ABS resin. Using

harsh cleaning chemicals can weaken the material causing it to

damage and develop cracks.

•Clean the A1 by wiping the surface area with a damp

cloth regularly.

•Do not use harsh detergents or any cleaning tools with bristles

on your bidet.

•Steam cleaning is the preferred cleaning method for your

bidet. For a deep chemical free clean, consider the Bio Mist

Bidet Cleaner.

14 15

No implied warranty, including any implied warranty of

merchantability or fitness or a particular purpose, applies

to BBC Innovation LLC bidet after the applicable period of the

express limited warranty stated above, and no other express

warranty or guaranty, except as mentioned above, given by

any person or entity with respect to Bio Bidet shall bind Bio

Bidet, (some states and provinces do not allow limitations on

how long an implied warranty, so the above limitation may

not apply to you). BBC Innovation LLC shall not be liable for

revenues or profits, inconvenience, expense for substitute

equipment or service, or any other special, incidental or

consequential damages caused by the use or misuse of, or

inability to use, Bio Bidet regardless of the possibility and

foresee-ability of such damages. In no event shall recovery of any

kind against BBC Innovation LLC be greater in amount than the

purchase price of the product and causing the alleged damage.

Without limiting the foregoing, you assume all risk and liability

for loss, damage, or injury to you and your property and to others

and their property arising out of use or misuse of, or inability

to use, the Bio Bidet not caused directly by the negligence or

BBC Innovation LLC. This limited warranty shall not extend to

anyone other than the original purchaser of the Bio Bidet.

WARRANTY

Your Bio Bidet is warranted against defects in materials

or workmanship for one (1) year from the date of original

purchase. Defective parts or a defective product returned to

Bio Bidet will be repaired with new or comparable rebuilt

parts or exchanged for a Refurbished Bio Bidet as determined

by Bio Bidet in their sole discretion.

This Iimited warranty given by Bio Bidet covers all defects

encountered in normal use of Bio Bidet, and do not apply

in the following cases:

1. Loss of or damage to Bio Bidet due to abuse, misuse,

tampering, mishandling, improper packaging by you,

alteration and failure follow operating instructions.

2. Use of parts or supplies (other than those by Bio Bidet’s

dealers) that cause damage to Bio Bidet.

3. Replacement of discolored or stained parts caused by

chlorine, bleach, ammonia, and other chemicals, cleaning

supplies, oxidation, normal wear and tear.

4. Damage to or malfunction of the unit as a

result of improper and negligent installation.

5. Any and all damages to plumbing, walls, floors, ceiling and

personal properties resulting from water leaks or breakage.

The product must be used at the user’s own risk. Therefore,

the owner hereby releases the manufacturer and distributor

from any and all claims for damages where the above

condition exists.

Thank You

Technical Support/Customer Service

7900 S Route 31 Crystal Lake, IL 60014

T: 847.458.2334

U.S TOLL FREE: 877.339.5214

[email protected]om

www.biobidet.com
