bem wireless Eclipse Manual de usuario
eclipse
®
Page 3
Page 18
Page 34.
English
Canadian Françis
Español
Contents
3
Light / Multi-Function Button
Press down on light to Snooze
/ Play / Pause / Answer
LCD Screen
Thank you for choosing the Eclipse Speaker. Take a moment
to familiarize yourself with its controls and its many functions,
featuring a push down light that lets you snooze, play / pause
music and answer the phone.
Meet the Eclipse Speaker
Sun Icon
Light on / off button changes
light and LCD display
brightness
Double Bell Icon
Choose one or two alarms
Bell Icon
Alarm and light mode settings
Musical Note Icon
Switch between Bluetooth and
Aux play modes
Minus / Plus Icons
Adjust volume, alarm and time
settings
4
If any of these were missing or damaged, please
visit bemwireless.com to obtain a replacement.
USB Port
For charging your smart-
phone, tablet or MP3 player
Aux Input
Use the included Aux Cable
to play audio from any device
with a headphone output
Bluetooth Indicator
Clock Setting
Choose between AM / PM,
and set hours and minutes
DC Input
Connect the Power Adapter
here
Power Adapter x 1
Aux Cable x 1
5
Product Interface: LCD Screen
AM/PM
Buzzer
Audio ModesAlarm 1/2
Sun Icon
6
Getting Started
Step 1: Power Up
Connect your Eclipse to an outlet using the included power
adapter. The light will come on and the LCD screen will light up.
(The light defaults to HIGH.)
Press to change the light brightness and cycle between:
HIGH – MEDIUM – LOW – OFF
You can also change the brightness of the LCD display. (The LCD
brightness defaults to HIGH.)
Press and hold and cycle between:
MEDIUM – LOW – OFF – HIGH
Step 2: Audio Modes
Press to select an audio mode, Bluetooth or Aux. (Bluetooth is
the default play mode when the speaker is turned on for the rst
time.)
7
AUX Mode: The Eclipse can be connected
to any device that has a standard 3.5mm headphone
jack by using the included aux cable. Use the controls
on the attached device to play / pause.
Bluetooth Mode: Play audio wirelessly from a
connected Bluetooth device. When the Bluetooth
mode is selected, the word Bluetooth displays on
the LCD screen. Go to the Bluetooth settings on
your mobile phone, tablet or computer and select
the device named “Eclipse”. A tone sounds to conrm
the device has paired successfully. From now on, this
device will connect automatically with the Eclipse
Speaker.
Step 3: Set the Clock
1. Press and hold on the back of the speaker to shift between
12 hour and 24 hour time. (When in 12 hour mode, PM displays
on the LCD screen during PM hours. When in 24 hour mode,
nothing displays during the AM or PM hours.)
2. Press and the hours will blink on the LCD screen,
press + / - to adjust the hour.
Getting Started (cont.)
8
3. Press again and minutes will blink on the LCD screen, press
+ / - to adjust the minutes.
4. Press and hold for 3 seconds to set and conrm the time
setting.
Step 4: Set the Alarm
The Eclipse Speaker features dual alarms that can be set for two
different times. Once you decide which alarm you wish to activate
(1 or 2), go to Step 2 to set the alarm time.
Step 1: Choose 1 or 2 alarms
1. Press once to select and display the Alarm 1 icon on the
LCD screen. Once Alarm 1 displays, you can set the alarm
time (go to Step 2).
2. Press twice to select and display the Alarm 2 icon on
the LCD screen. Once Alarm 2 displays, you can set the
alarm time (go to Step 2).
3. After the alarm times are set, press three times to
select and display BOTH Alarm 1 and 2 icons on the LCD
screen.
4. Press a fourth time to turn BOTH alarms and the icons
off.
9
Step 2: Set alarm time and sound mode
Set the alarm time and the sound mode of the activated
alarm (1 or 2). (You cannot set the alarm if Alarm 1 and 2 are
both activated or both off.)
1. Press to begin setting your alarm. The hours blink on
the LCD screen, press + / - to adjust the hour.
2. Press a 2nd time, the minutes blink on the LCD screen,
press + / - to adjust the minutes.
3. Press a 3rd time, ashes on the LCD screen, press
+ / - to shift between turning the light on or off when the
alarm sounds. (A blinking indicates the light will slowly
become bright when the alarm goes off.
4. Press and hold for 3 seconds to conrm the alarm
settings.
The alarm lasts for 3 minutes. Press any button on the front of the
speaker to silence it. Note that the light stays on.
Using the Snooze Function
When the alarm sounds, press down on the light to activate the
snooze function, which postpones the alarm for 9 minutes. (The
snooze function only works once the alarm starts.)
Getting Started (cont.)
10
Push Down Multi-Function Light
Pushing down on the multi-function light lets you snooze, play /
pause music and answer the phone.
Snooze
When the alarm sounds, push down on the light to activate the
snooze function. The alarm will start again in 9 minutes.
Play / Pause Music
After pairing your mobile phone to the Eclipse Speaker via Blue-
tooth, the speaker phone function is activated.
•Make a Call: Calls you make will automatically transfer to the
speakerphone. If not, push down on the light.
•Answer a Call: Push down on the light to answer an incoming
call.
•End a Call: During a call, push down on the light to end it.
•Reject a Call: Push down on the light and hold to reject an
incoming call.
•Redial the Last Number: Push down on the light twice to call
the last number dialed.
Operation Details
