Belling

Bi60R Induction Hob

User & Installation Instructions

Contents

Beforeusingyourappliance............................................3

Safety............................................................4

Safetyandinduction .................................................6

Usingtheinductionhob...............................................7

WhatTheSymbolsMean..............................................8

UsingTheInductionHob..............................................9

CookwareforInductionHobs........................................13

CareofPans......................................................14

CookingonInductionHobs............................................15

Cookingtips....................................................16

Care&Cleaning....................................................17

Troubleshooting....................................................19

Installation .......................................................20

ServiceRecord.....................................................26

TechnicalData..................................................27

Before Using Your Hob

Thank you for purchasing a new Belling Induction

Hob. Its stylish and practical design will enhance your

kitchen and make cooking a pleasure. Even if you

have used an induction hob before, it is important that

you read these instructions thoroughly before starting

to cook, paying particular attention to the installation

and safety instructions.

If you have any problems with any aspect of your

Belling hob, please check through these instructions

thoroughly to make sure that you have not missed

anything. If you still need help, then please contact us

using the customer care centre number at the back of

this book.

Before using this appliance please make sure that

you have removed all packaging and wrapping.

Also remove stickers & film from the ceramic glass.

Although every care has been taken to ensure this

appliance has no burrs, or sharp edges, we

recommend that you wear protective gloves when

installing and moving this appliance.

This will prevent any injury.

Our policy is one of constant development and

improvement. Strict accuracy of illustrations and

specifications cannot be guaranteed. Modification

to design and material may be necessary

subsequent to publication.

Always use a registered installer for this appliance.

WARNING! For your own safety, make sure that

these instructions on installation, use and

maintenance are followed.

Environmental protection:

Glen Dimplex Home Appliance brands are

committed to protecting the environment and oper-

ates and Environmental Management System which

complies with BS EN ISO 14001.

All packaging with this appliance is recyclable and

environmentally friendly.

Please recycle whenever possible - contact your

local authority for your nearest recycling centre.

This appliance is for

use in a domestic

kitchen only, it is not

designed, or intend-

ed, for commercial

use.

!!!

lease keep these

instructions in a safe

place.

Should you sell or

pass on the appli-

ance, please give the

new owner this

handbook.

Safety

Keep children away from the vicinity of the hob

when you are cooking.

• Use pans with a flat base which are stable in use,

and avoid using any old misshapen pans or any pan

which is unstable when placed on a flat surface.

• Never leave fat or oil unattended on an active cook

zone. Don’t leave pans on the hob when you are

not around - remove them or turn the cook zones

off (even if only for a moment)

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to ensure that they

do not play with the appliance

• Keep all flammable materials away from the hob.

Ensure electrical leads do not trail over or go near

the hob.

• Do not place aluminium foil or plastic utensils on hot

surfaces.

• Turn pan handles to a safe position, so they are out

of reach of children, not overhanging the appliance

and cannot be caught accidentally.

• Commercial simmering aids should not be used as

they create excessive temperatures that can dam-

age the surface and may cause a hazard.

• Caution: Do not use the hob if the glass is cracked,

as electrical parts are directly beneath. To avoid the

possibility of electric shock, turn off the electricity

supply to the hob at the socket and arrange a

Service call.

WARNING: If you use a griddle plate, ensure that

it is completely cool before attempting to lift it from

the hob as residual heat may cause burns. Always

use oven gloves to protect your hands.

Do not allow yourself to be distracted whilst

cooking.

When you have finished cooking check that all

controls are in the off position.

Safety Advice

Smoke alarm - buy a smoke alarm fitted with a ‘hush

button’ which can silence the alarm instantly should it

activate accidentally & does not necessitate the removal

of the battery (except to change for a new one).

Fire Blanket - consider having a fire blanket in your

kitchen, mounted on the wall where you can get to it

easily & quickly.

Deep-fat Frying - never fill a chip pan (or other deep-

fat fryer) more than one-third full of oil. If you do have

a chip pan fire:

1) call 999 immediately

2) never move the pan

3) turn off the heat but only if it is safe do so

4) never use water on a chip pan fire as this will create

a fireball.

Kitchen Fire - if you have a fire in the kitchen, do not

take risks - get everybody out of the house & call 999.

If a pan catches fire:

1) do not move it - it is likely to be very hot

2) turn off the heat but only if safe to do so & never

lean over a pan to reach the controls

3) if you have a fire blanket, put it over the pan

4) do not use a fire extinguisher on a pan of oil - the

force of the extinguisher can spread the fire

5) if you have managed to extinguish the fire, allow the

pan to cool completely.

Electrical Fire - if you have an electrical fire in the

kitchen, do not take risks - get everybody out of the

house & call 999 :

1) pull the plug out or switch off the power at the fuse

box - this may be enough to extinguish the fire immedi-

ately

2) smother the fire with a fire blanket or use a dry pow-

der or carbon dioxide extinguisher

30 remember: never use water on an electrical fire.

Safety & Induction

Detection of an object or a pan on the heating

zone

A small object - such as a fork, a spoon or even a ring

- placed on a hob cooking zone on its own is not

detected as a pan.

The security system acts in the same way when it

detects a pan which is not suitable for use on an

induction hob.

If you are fitted with a pacemaker or an active

implant

The functions of the hob comply with the applicable

standards on electromagnetic interference

Your induction cooking hob thus complies fully with

the statutory requirements (Directive 89/336/EEC). It

is designed to not interfere with the functioning of

other electrical equipment as long as these also comply

with the same regulations.

Your induction hob generates magnetic fields in its

immediate vicinity.

So that there is no interference between your cooking

hob and a pacemaker, the pacemaker must be

designed in compliance with the appropriate regula-

tions.

In this respect we can only guarantee the compliance

of our own product. You can ask the manufacturer or

your doctor about the compliance or any incompatibili-

ties of your pacemaker.

About the induction hob

The induction hob provides the most

energy efficeint hob technology avail-

able.

The induction system provides superior

heat up and cool down times for pans

- you get fast, precise, repeatable

power control.

As induction only heats up the pan,

there is no lost heat from the cooking

process, which in turn, limits the heat

generated in the kitchen.

Auto Power Tuning

Induction hobs have a unique power

tuning systems that automatically tunes

the power to the size of the pan base

this ensures energy isn’t wasted.

USING THE INDUCTION HOB

Small pan

Large pan

INDUCTION HOB FUNCTIONS

Feature Symbol Description

Eco Power

Rotary Controls

Digital Display

No. of power

levels

Keep Warm/

Low Temperature

Auto Heat Up

(4 Zones)

Power Boost

Pan detection

Overheat pan

detection

Child lock

Residual heat

indicators

Holiday shutdown

Flush fitting or

surface mount

Yes

Induction Power is the most energy efficient means of cook-

ing food on a hob, provides fast heat up and boiling times

Simple knob control with all the benefits of induction tech-

nology

Secret till "lit" hob display

Precise and repeatable control settings

Holds the pan temperature at approximately, ideal

for melting chocolate “mmmm choc-ol-ateee”

Automatically heats up and turns down the power to a

lower setting. Helps to take the worry out of pans boiling

over and burning food

Temporarily boost the power to a cook zone by a massive

60%

Lets you know if the correct pans are being used and

helps to save energy. When a pan is lifted off the zone,

the power is automatically cut.

Helps prevent cookware from overheating providing an

additional level of safety not availabe on other types of hobs

Prevents unintentional operation of the hob

Warns you against hot surfaces but also indicates that

there is residual heat which can be used as a temporary

warm zone

Rest assured this hob will eventually turn it self off if left

Yes

Induction contro s:

Auto Heat Up

Helps to take the worry out of pans boiling over and burning food! No need to

stand over the pan, allows you to do other tasks whilst maintaining control over the

pan.

The Auto Heat Up is activated by rotating he control knob anti-clockwise and hold-

ing for a couple of seconds until the symbol lights up in the display area, then by

rotating the control knob to the required turn down setting.

The Auto Heat Up delivers full power (9) to the zone for a fixed period of time

before automatically turning back down to the desired setting.

The Auto Heat Up has been tuned to provide the best boost period for each setting.

Average Auto Heat up time is 3 minutes.

USING THE INDUCTION HOB

To turn the hob ‘ON’ / ‘OFF’

To turn the hob ‘ON’, turn the control knob for the required cook zone clockwise to

set the cook zone to the desired power setting (1 to 9). The power display will auto-

matically light up.

To turn the hob ‘OFF’ turn the control knob anti-clockwase to the ‘OFF’ position.

Power Setting Suggested food type Auto Heat Up time (mins)

Low temp U ˚C Melting chocolate n/a

1 Milk, Soup Stews, 1

2 Vegetables 2.

4 Rice, Potatoes, Pasta

6 Frying, fish fingers 2

7 Pancakes, Steaks 3

9 Full power n/a

Boost Full power +60% n/a

Power Boost

Rev up your hob with this feature, tem-

porarily boost the power to a cook

zone by a massive 60%.

The power boost is a function that can

be used to temporally boost the nor-

mal maximum power for a cook zone

by borrowing the available power

from a “paired zone”.

The Power Boost is activated by rotat-

ing the control knob clockwise past

power setting 9 and holding for a cou-

ple of seconds until lights up in the

display area. Power Boost is now acti-

vated.

The hob is split into “two paired

areas”.

LH Area (LHF and LHR Cook Zone)

and RH Area (RHF and RHR Cook

Zone).

Only one cook zone per area can be

boosted at anyone time.

Note The Power Boost function will

only operate for a limited time and

is also under thermal control. This

means the power boost will deac-

tivate automatically if the product

is hot, to protect the internal elec-

tronic components of the hob and

to prevent the cookware from over-

heating.

USING THE INDUCTION HOB

Cook Zone Normal Max Power Boosted Power kW Maximum

Permissable setting on

paired zone

LHF 1.40 2.20 9 (LHR)

LHR 1.8 3.00 8 (LHF)

RHF 1.40 2.20 8 (RHR)

RHR 2.30 3.70 6 (RHF)

Otros manuales para PBI60R

Tabla de contenidos

Otros manuales de Quemador de Belling

Belling

Belling SCGHU60GC Manual de usuario

Belling

Belling CH60TX Manual de usuario

Belling

Belling CH302TX Manual de usuario

Belling

Belling FSE 60 DO Actualización de firmware

Belling

Belling SCGHU60GC Actualización de firmware

Belling

Belling shu60 Guía

Belling

Belling IHL773 Manual de usuario

Belling

Belling Gas hobs Actualización de firmware

Belling

Belling IHT603 Manual de usuario

Belling

Belling IH302T Manual de usuario

Belling

Belling 60T Series Instrucciones de funcionamiento

Belling

Belling BCT60CER Manual de lista de piezas

Belling

Belling Gas hobs Actualización de firmware

Belling

Belling IHL603 Manual de usuario

Belling

Belling Hob Rotary UK Actualización de firmware

Belling

Belling 77cm Hob Touch Actualización de firmware

Belling

Belling GTG60 Manual de usuario

Belling

Belling FSE 54 DO Actualización de firmware

Belling

Belling CH60R Actualización de firmware

Belling

Belling IH60 UK Actualización de firmware

Belling

Belling Hob Actualización de firmware

Belling

Belling IH60R Manual de instrucciones

Belling

Belling CRS60 Manual de instrucciones

Belling

Belling GHU60GE W Actualización de firmware

Manuales populares de Quemador de otras marcas

Siemens

Siemens EX875KYV1E Hoja de especificaciones

AEG

AEG CERAMIC HOB 6010 K Manual de usuario

VALERA

VALERA CT 70A Manual de usuario

Zanussi

Zanussi ZGF 6420 Manual de usuario

Gaggenau

Gaggenau CI 273 Manual de usuario

G3 Ferrari

G3 Ferrari Energy Manual de usuario

Pkm

Pkm IN4B Manual de usuario

Award

Award H903BG Manual de usuario

Zanussi

Zanussi VCH 5005 RZ Manual de usuario

Miele

Miele KM 523 Manual de usuario

Hotpoint

Hotpoint IS67V8CCXT/E Manual de usuario

AEG

AEG HK854870XB Manual de usuario

Cookology

Cookology SEP600BK Manual de usuario

Bauknecht

Bauknecht Hob Manual de usuario

Zanussi

Zanussi ZGM 782 Manual de usuario

dipo INDUCTION

dipo INDUCTION DIBK218S Manual de usuario

Miele

Miele KM 5987 Manual de usuario

Miele

Miele KM 360 G Manual de usuario
