INTRODUCTION

This user guide book is designed to help you through each step of owning your new product.

Please read it carefully before you start using your appliance, as we have endeavored to answer as

many questions as possible, and provide you with as much support as we can.

General information, spares and service information is available from our website.



in this user guide, please contact us (see contact information inside the front cover).

European Directives

As a producer and a supplier of cooking appliances we are committed to the protection of the

environment and are in the compliance with the WEEE directive. All our electric products are

labelled accordingly with the crossed out wheeled bin symbol. This indicates, for disposal

purposes at end of life, that these products must be taken to a recognized collection points,

such as local authority sites/local recycling centres.

This appliance Complies with European Community Directives (CE) for household and similar

electrical appliances and Gas appliances where applicable.

This appliance conforms to European Directive regarding Eco design requirements for energy-

related products. Our policy is one of constant development and improvement, therefore we cannot



made subsequent to publishing.

Disposal of Packaging Material

The packaging materials used with this appliance can be recycled. Please dispose of the packaging

materials in the appropriate container at your local waste disposal facilities.

UK ONLY GAS WARNING:

If you smell gas, Do not try to light any appliance. Do not touch any electrical switch.

Call the Gas Emergency Help line at 0800 111999

SAFETY

WARNING

 󰀨

appliance to avoid the possibility of electric shock and call for a

service engineer’s visit.

• During use the appliance becomes hot. Care should be taken to

avoid touching heating elements.

• Children less than 8 years of age shall be kept away unless

continuously supervised. This appliance can be used by children

aged from 8 years and above and persons with reduced physical

sensory or mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction concerning the

use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision.

• Do not use harsh abrasive cleaners or sharp metal scrapers to

clean the oven door glass or the hob, since they can scratch the

surface, which may result in shattering of the glass.

• Do not use a steam cleaner on any cooking range, hob or oven

appliance.

• Metallic objects such as knives, forks, spoons and lids should not

be placed on the hob surface since they can get hot.

 󰀨

on the pan detector.

• The appliance is not intended to be operated by means of an

external timer or separate control system.

• Unattended cooking on a hob with fat or oil can be dangerous



           󰀨 



 

• Only use hob guards designed by the manufacturer of the cooking

appliance or indicated by the manufacturer of the appliance in

the instructions for use as suitable or hob guards incorporated in

the appliance. The use of inappropriate hob guards can cause

accidents.

• This induction hob complies with the applicable EMC and EMF

standards. Therefore it should not interfere with other electronic

         

implant should clarify with their doctor or the producer of the

implant, whether there implant is adequate and fail-safe. Please

place pans centrally on the cooking zones. The British Heart

Foundation provide additional advice regarding using induction



• During use the appliance becomes hot. Care should be taken to

avoid touching heating elements.

• Do not modify this appliance.

• Do not place articles on or against the appliance.

• Servicing should be carried out only by authorised personnel.

 󰀨

you clean any part of it.

• Although every care has been taken to ensure this appliance has

no sharp edges. We recommend that you wear protective gloves

when installing and moving this appliance. This will prevent injury.

           

disconnection with a minimum contact separation of 3mm.

 

minimum temperature rating of 70°C.

CAUTION

• The cooking process has to be supervised. A short term cook-

ing process has to be supervised continuously.

• This appliance must not be installed behind a decorative door in

order to avoid overheating.

• Fire Safety Advice

 

Brigade.

If you have an electrical re in the kitchen:

 󰀨

 

 

• Other Safety Advice

󰀨

•This appliance must be earthed.

󰀨

the safety and performance, particularly in relation to surface temperatures becoming hot and gas operated

󰀩

•GAS WARNING! -

Contact your local gas supplier immediately.

Report No.: GZES180801368431

Information for domestic electric hobs P

SymbolValueUnit

Model identification —

Type of hob —Built-in induction hob

Number of cooking zones and/or

areas —4 zones

1 area

Heating technology (induction

cooking zones and cooking

areas, radiant cooking zones,

solid plates)

—Induction cooking zones

For circular cooking zones or

area: diameter of useful surface

area per electric heated cooking

zone, rounded to the nearest 5

Zone1: 18,0

Zone2: 18,0

Zone3: 21,0

Zone4: 16,0

Middle area: 38,0 * 19,0

For non-circular cooking zones

or areas: length and width of

useful surface area per electric

heated cooking zone or area,

rounded to the nearest 5 mm

L, W N/A cm

Energy consumption per cooking

zone or area calculated per kg

ECelectric cooking

Zone1: 207,6

Zone2: 184,7

Zone3: 176,1

Zone4: 195,7

Middle area: 185,0

Wh/kg

Energy consumption for the hob

calculated per kg ECelectric hob 189,8 Wh/kg

BEL IHL773 BLK

1. max. 1800/2300 W zone

2. max. 1800/2300 W zone

3. max. 3000/3600 W zone

4. max. 2200/2600 W zone

USING YOUR APPLIANCE

Getting to know your product

Note:󰀨

Control Panel

Hob functions

Heating zone selection / Power slider touch control

Boost /󰀨

Flexible area bridge key Keylock control

Timer control

5. max. 1200/1500 W zone

6. Control panel

7. Glass plate

Before using the Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

 

Touch controls



pressure. The touch control keys take approximately 1 second to respond to your touch. Always

ensure the touch control area is clean, dry and free from any objects (e.g. utensils, tea towels and

󰀩

Choosing the right Cookware

• Only use cookware with a base suitable for induction cooking. Look for the induction symbol on

the packaging or on the bottom of the pan.

• You can check whether your cookware is suitable by carrying out a magnet test. Move a magnet

towards the base of the pan. If it is attracted, the pan is suitable for induction. The base of the

pan must be magnetic across the whole diameter of the base.

 

 

copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

1. Put some water in the pan you want to check.

2. If 

Start cooking

After switching the hob on, the buzzer will beep once. All the

indicator lights light up for a second and go out, to indicate that the

induction hob is now in standby mode.

1 /󰀨

once and the displays show ‘-’ or ‘--’ to indicate that the hob is

in standby mode.

2. Place a suitable pan on the cooking zone that you wish to use.

•Make sure the bottom of the pan and the bottom of the cooking

zone are clean and dry.

3. Touch the relevant heating zone slider control for the zone you

wish to use, until the power level indicator next to it starts to





least as large as the circle printed on the glass. Using a pan which is slightly wider than the glass

󰀩

zone.

󰀨

        

slider control to adjust the heat settting.

• If you don’t select a power level within 1 minute, the

󰀨

to start again from step 1.

• You can modify the heat setting at any time. Adjusting

0󰀨

Finish cooking

1. Touch the relevant heating zone selection control key for the

   󰀨    



2

to turn the power level down to 0.

3󰀨/󰀨

Beware of hot surfaces

H will show which cooking zone is hot to touch. It will disappear

when the surface has cooled down to a safe temperature.

This can also be used to save energy if you wish to heat other

pans, use the hotplate that is still hot.



• You have not placed a pan on the correct cooking zone or;

• The pan you’re using is not suitable for induction cooking or;

• The pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone. The display will

󰀨2

power up

power down

If the display ashes alternately with the heat setting

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Quemador de Belling

Belling

Belling Hob Actualización de firmware

Belling

Belling GHU60GE W Actualización de firmware

Belling

Belling PBI60R Instrucciones de funcionamiento

Belling

Belling GTG60 Manual de usuario

Belling

Belling SCGHU60GC Manual de usuario

Belling

Belling Gas hobs Actualización de firmware

Belling

Belling 60cm Manual de usuario

Belling

Belling IH60 UK Actualización de firmware

Belling

Belling PBi60 AU Actualización de firmware

Belling

Belling IH60 UK Actualización de firmware

Belling

Belling GTG 60 LPG Series Manual de usuario

Belling

Belling Hob Actualización de firmware

Belling

Belling IH60XL Actualización de firmware

Belling

Belling 60T Series Instrucciones de funcionamiento

Belling

Belling shu60 Guía

Belling

Belling FSE 60 DO Actualización de firmware

Belling

Belling CH302TX Manual de usuario

Belling

Belling IH613 Manual de instrucciones

Belling

Belling GHU60-70 AU Manual de usuario

Belling

Belling 77cm Hob Touch Actualización de firmware

Belling

Belling GHU573 Guía

Belling

Belling CH772TX Manual de usuario

Belling

Belling GTG60 Manual de usuario

Belling

Belling CH60TX Manual de usuario

Manuales populares de Quemador de otras marcas

Siemens

Siemens EX875KYV1E Hoja de especificaciones

AEG

AEG CERAMIC HOB 6010 K Manual de usuario

VALERA

VALERA CT 70A Manual de usuario

Zanussi

Zanussi ZGF 6420 Manual de usuario

Gaggenau

Gaggenau CI 273 Manual de usuario

G3 Ferrari

G3 Ferrari Energy Manual de usuario

Pkm

Pkm IN4B Manual de usuario

Award

Award H903BG Manual de usuario

Zanussi

Zanussi VCH 5005 RZ Manual de usuario

Miele

Miele KM 523 Manual de usuario

Hotpoint

Hotpoint IS67V8CCXT/E Manual de usuario

AEG

AEG HK854870XB Manual de usuario

Cookology

Cookology SEP600BK Manual de usuario

Bauknecht

Bauknecht Hob Manual de usuario

Zanussi

Zanussi ZGM 782 Manual de usuario

dipo INDUCTION

dipo INDUCTION DIBK218S Manual de usuario

Miele

Miele KM 5987 Manual de usuario

Miele

Miele KM 360 G Manual de usuario
