Belkin F8E839ukBNDL Manual de usuario
Wireless Keyboard and
Optical Mouse Bundle
Enjoy web surfing and total media control
with 19 smart hot keys
User Manual
F8E839ukBNDL
P74598uk_F8E839ukBNDL_man.indd 1 15/10/04 5:47:17 pm
P74598uk_F8E839ukBNDL_man.indd 2 15/10/04 5:47:17 pm
Introduction 1
Compatible Equipment 2
Operating Systems 2
Package Contents 2
Quick Installation Guide for PS/2 Connection 3
Software Installation for Windows 98, Me, 2000, and XP 4
Troubleshooting 5
Uninstallation process for Windows 98, Me, 2000, and XP 7
Information 8
TABLE OF CONTENTS
P74598uk_F8E839ukBNDL_man.indd 3 15/10/04 5:47:17 pm
P74598uk_F8E839ukBNDL_man.indd 4 15/10/04 5:47:17 pm
1
Congratulations and thank you for purchasing the Wireless Keyboard
and Optical Mouse bundle from Belkin. We appreciate your business
and are sure you will enjoy years of reliable use with these high-
quality, input devices. Please review this entire User Manual
so you can be sure to get the most reliable performance from your
new equipment.
INTRODUCTION
P74598uk_F8E839ukBNDL_man.indd 1 15/10/04 5:47:17 pm
2
Compatible Equipment
Works with all PCs that are compatible with IBM® and equipped with
PS/2 interface
NOTE: Use of these products on a desk made of iron, or other
metal, will negatively impact the operation of your Wireless
Keyboard and Mouse.
Operating Systems
Windows XP, Me, 2000, 98 SE, 95
Package Contents
Wireless Keyboard
Wireless Optical Mouse
Receiver
4 AA batteries
User Manual
Driver CD
Please read the instructions for installing, operating, and using
the wireless desktop.
INTRODUCTION
P74598uk_F8E839ukBNDL_man.indd 2 15/10/04 5:47:17 pm
3
1. Be sure that your computer is powered off.
2. Connect the receiver to your computer’s PS/2 port. The receiver
has a 2-head connector for the Keyboard and Mouse connections
(purple is for the Keyboard and the USB connection; the green is
for the Mouse). There is also an illustration on the top connector
to identify them. If your computer does not use the same color
scheme, match the plug with the illustration next to the port.
3. Install the batteries into your Keyboard and Mouse. Please make
sure you follow the indication on the inside compartment for
correct positioning of the batteries.
4. Power on your computer.
5. To set up the wireless mouse and keyboard links, press the
connection button on the receiver. Then press the connection
button on the mouse that is located on the bottom and hold for
several seconds. Press the connection button on the keyboard
(located under the foot of the keyboard) and hold for several
seconds. The indicator light on the receiver will flash until the
channel has been selected. When the indicator light stops flashing,
your keyboard and mouse will be operational.
QUICK INSTALLATION GUIDE FOR
PS/2 CONNECTION
P74598uk_F8E839ukBNDL_man.indd 3 15/10/04 5:47:17 pm
4
Note: The Keyboard and Mouse should now be functioning.
If they are not, repeat the setup instructions and refer to the
“Troubleshooting” section for help. When the Mouse and
Keyboard are operational, the software can be installed.
Warning: It is recommended that you uninstall any previously installed
keyboard and mouse software prior to installing your
new Belkin software.
1. Be sure your computer is powered on.
2. Insert the CD into your computer’s CD-ROM drive.
3. If you have not previously installed Keyboard and Mouse software,
click “OK” and the installation will begin. Follow the on-screen
instructions.
4. Upon completion of installation, you will be prompted to restart
your computer. You must restart at this time in order for the
software to function.
5. The setting icons of the keyboard and mouse will appear on
the taskbar of windows - Double click the icons to set the
programmable mouse button and the keyboard hot key functions.
SOFTWARE INSTALLATION FOR
WINDOWS 98, ME, 2000, AND XP
P74598uk_F8E839ukBNDL_man.indd 4 15/10/04 5:47:17 pm
5
The Keyboard and/or Mouse is/are not detected or do not
work after installation.
• Make sure the receiver cables are plugged into the computer’s PS/2
port.
• For optimal performance, place the receiver at least eight inches
(20cm) away from the computer monitor, the computer, any external
storage devices, or other electrical devices.
• Make sure you have properly installed the batteries. Test the
batteries to make sure they are not dead (you can do this by
installing them into another device).
• You may have other system devices that are conflicting with the
Mouse and/or the Keyboard. Check the IRQ/address setting of
these devices for conflicts and change the settings as required.
Please refer to your computer documentation or the manufacturer’s
technical support for assistance in making these changes.
• Make sure you have properly established communication/
synchronization between the receiver and the Mouse and Keyboard.
TROUBLESHOOTING
P74598uk_F8E839ukBNDL_man.indd 5 15/10/04 5:47:17 pm
6
• If your Mouse pointer becomes choppy on-screen or the Keyboard
does not register keystrokes, replace batteries swith a fresh set.
• When multiple wireless keyboard and mouse sets are used in a
close proximity, interference might occur. You can solve this by
changing the communication channel of your keyboard and mouse.
• To change the channel of the wireless keyboard and mouse, press
the connection button on the receiver. Then press the connection
button on the mouse that is located on the bottom and hold for
several seconds. Press the connection button on the keyboard
(located under the foot of the keyboard) and hold for several
seconds. The indicator light on the receiver will flash until the new
channel has been selected.
TROUBLESHOOTING
P74598uk_F8E839ukBNDL_man.indd 6 15/10/04 5:47:17 pm
