Belkin F5U513 Manual de usuario

FireWire

Notebook Adapter

Connect your iPod™, camcorder, FireWire®, and

Sony® i.LINK® devices to your PC

User Manual

F5U513ea

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 1

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 2

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . .3

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Windows 98 SE Driver Installation . . . . . . . . . . . . . . . . . . . . . .5

Windows ME Driver Installation . . . . . . . . . . . . . . . . . . . . . . . .6

Windows 2000/XP Driver Installation . . . . . . . . . . . . . . . . . . . .7

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 3

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 4

INTRODUCTION

Thank you for purchasing the Belkin FireWire Notebook

Adapter (the Adapter).

Now you can add three 400Mbps FireWire ports to your Windows 98 SE,

Me, 2000, or XP operating system and enjoy the ultrafast speed and

Plug-and-Play ease of next-generation FireWire devices.

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 1

OVERVIEW

Specifications

• 3 external 6-pin IEEE 1394 ports

• OHCI 1.0-compliant

• IEEE 1394a 2.0-compliant

• Texas Instruments TSB12LV23 OHCI-Lynx 1394 Link Layer Host

Controller

• Texas Instruments TSB41LV02 Digital to Analog transceiver

• Supports 100/200/400Mbps data rates

• PC 98 & PCI Power Management v1.0-compliant

• 3.3V operation for CardBus to IEEE 1394 interface

• Optional AC adapter requirements:

Voltage: 12V DC

Current: 1.6 Amps

Plug Size: 3.8mm

Plug Polarity: Center positive

Note: Optional AC adapter is usually only required for devices that do not

provide their own power source such as web cameras, certain

scanners, and certain pocket hard-disk drives.

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 2

OVERVIEW

Minimum System Requirements

• 266MHz Pentium® II (700MHz PIII recommended for video editing)

• 32MB RAM (128MB recommended for video editing)

• Windows® 98 SE, Me, 2000, XP

• 32-bit Type II CardBus slot (Check your laptop owner’s manual for

CardBus slot specifications)

Package Contents

• Belkin FireWire Notebook Adapter

• User Manual

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 3

HARDWARE INSTALLATION

1. Examine your laptop computer and locate the CardBus slot(s).

2. Insert the Adapter into a free 32-bit Type II CardBus slot.

3. Apply power to the laptop and let Windows start normally.

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 4

WINDOWS 98 SE

DRIVER INSTALLATION

1. When Windows has finished loading, the “New Hardware Wizard” will

launch and display a window that identifies the Adapter as a “Texas

Instruments OHCI Compliant IEEE 1394 Host Controller”. Click “Next”.

2. Select “Search for the Best Driver for Your Device (Recommended)”.

Click “Next”.

3. Leave all boxes unchecked. Click “Next”.

4. The “New Hardware Wizard” will now prompt you to select the driver

you wish to install. Select “The Updated Driver (Recommended)”. Click

“Next”.

5. The “New Hardware Wizard” will now locate and install the proper

driver. Click “Next”.

6. You may be prompted to insert your Windows 98 installation CD.

7. Hardware installation is now complete. Click “Finish”.

8. To confirm that the Adapter has been properly installed, open the

Windows “System Properties” window and click the “Device Manager”

tab. In the list of installed devices, click the “+” sign next to the

entry for “IEEE 1394 Bus Controller”. You should find an entry for

“Texas Instruments OHCI Compliant IEEE 1394 Host Controller”.

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 5

WINDOWS ME

DRIVER INSTALLATION

1. When Windows has finished loading, the “New Hardware Wizard” will

launch and display a window that identifies the Adapter as a “Texas

Instruments OHCI Compliant IEEE 1394 Host Controller”.

2. Select “Automatic search for a better driver”. Click “Next”.

3. Windows will search its driver database and automatically install the

correct driver. Click “Finish”. You will be prompted to restart your

computer. Click “Yes”. Installation is now complete.

4. To confirm that the Adapter has been properly installed, open the

Windows “System Properties” window and click the “Device Manager”

tab. In the list of installed devices, click the “+” sign next to the

entry for “IEEE 1394 Bus Controller”. You should find an entry for

“Texas Instruments OHCI Compliant IEEE 1394 Host Controller”.

P74414ea_F5U513ea_manual_uk 11-08-2003 12:09 Page 6
