Baumatic BFW1400 Manual de usuario

BFW1400W

BFW1400SL

Washing machine

Please note- this Instruction Manual contains important safety information. Please

make sure that you read it before using your Washing Machine for the first time. It also

contains valuable Troubleshooting tips so that you can solve faults without having to call

for a service engineer.

Instruction Manual for your Baumatic

BFW1400W/ BFW1400SL

FULLY ELECTRONIC

WASHING MACHINE

Please note: for fast access to using your

Washing Machine, please look at the bold-font

items listed on the Contents page (page 3).

DD MOD 20/12/06

CONTENTS

Important Safety Information……..…………………………………….….4

Your Washing Machine’s Control Panel…………….….……………..5

Start / Pause Button……………………………………………….………………5

Function Buttons………………………………………………………………….…6

Adjusting wash water temperature……...…………………………………...7

Adjusting the spin speed.....……………….…………………………………….….8

Selecting an Additional Function….……………………………………………..…9

Changing an Additional Function………………………………………………….…9

To Change / Cancel a Program…….…………….……….………………………….…10

Setting a Program to Begin at a Certain Time………………………………..11

Child Lock…………………………………………………………………………………………...11

When the Program Finishes………………………………………………….……………….12

Washing your Laundry………………………………………………………………………..…13

Washing Labels and their Meanings……………………………………………………..…14

Loading your Washing Machine………………………………………………………………...…..15

Filling your Washing Machine’s Dispenser Drawer with Detergent……...15-16

Running Your Washing Machine……………………………………………………………..……..17

Using the Program Knob………………………………………………………………………..…...…17

Washing Tables……….………………………………………………………………………………….…..18-19

How your Washing Machine’s Program Cycles Work………………………………..………….20

…And which Options are Compatible with each Other…………………………..………..…20

Maintenance & Cleaning ..………………………………………………………………………..….21-24

Water Inlet Filters / Pump Filter ….……………………………………………………..….....21-22

Cleaning the Detergent Drawer & Siphon Plug….………………………………..…….……...23

Cleaning the Cabinet & Drum.……………………………………………………………..…….……...24

Notes on Stains and how to Remove them from your Clothes.………….….……..25-26

Troubleshooting……………………………………………………..………………………….……….…27-29

Error Codes………………………………………………………….…………………………….…….…...30-31

Installation Instructions…………………………………………………………………….…..………32-34

ENVIRONMENTAL NOTE...............…………………………………………………..…………….35

Conditions of Guarantee…………………...……………………………………………..…............37

Contact Details…………………………………………………………………………………..……………..…38

IMPORTANT SAFETY INFORMATION:

WARNING: THIS IS IMPORTANT SAFETY INFORMATION. PLEASE

READ THIS BEFORE USING YOUR WASHING MACHINE.

:DO NOT USE AN EXTENSION CORD OR PLUG INTO A MULTIPLE

SOCKET.

:DO NOT INSERT A PLUG WITH A DAMAGED CORD OR THAT IS

BROKEN INTO THE SOCKET.

:IF THE CORD IS DAMAGED IT SHOULD BE REPLACED BY THE

MANUFACTURER OR APPOINTED SERVICE AGENT IN ORDER TO

AVOID A HAZARD.

:NEVER REMOVE THE PLUG FROM THE SOCKET BY PULLING FROM

THE CORD SECTION. HOLD THE PLUG AS YOU PULL IT OUT.

:DO NOT PLUG INTO THE POWER SUPPLY IF YOUR HANDS ARE WET.

:DO NOT TOUCH THE MACHINE WITH WET HANDS OR FEET.

:DO NOT OPEN THE DETERGENT DRAWER WHILE THE DEVICE IS

RUNNING.

:DO NOT FORCE OPEN THE DOOR OF THE MACHINE WHILE THE

MACHINE IS RUNNING.

:DO NOT TOUCH THE DRAIN HOSE AND WATER DURING DRAINING –

THE WASHING MACHINE CAN REACH HIGH TEMPERATURES DURING

DRAINING.

:DO NOT ATTEMPT TO REPAIR. PLEASE APPLY TO THE NEAREST

AUTHORISED SERVICER.

:DO NOT FORGET THAT THE PACKING MATERIAL OF YOUR MACHINE

MAY BE HAZARDOUS FOR CHILDREN.

:NEVER LET YOUR CHILDREN PLAY WITH YOUR WASHING MACHINE.

:KEEP PETS AWAY FROM YOUR MACHINE.

:ONLY USE YOUR WASHING MACHINE IN THE HOME. THE WARRANTY

WILL BE INVALID SHOULD YOU USE IT FOR COMMERCIAL

PURPOSES.

Your Washing Machine’s Control Panel

•This key is used for starting a program or for pausing a

program that is running.

•Once a selected program has been started, the symbol

lights up on the display. When it is paused, the

symbol lights up on the display.

The Program Knob must be turned to the ‘0’ position (closed)

before selecting the program or changing to a new one.

•You can select from your washing machine’s various functions

with the MODE KEY. Each time you press it, the symbol of a

function will show on the display.

•You can select a function you want to use in a washing cycle

by using the SELECT KEY when the symbol of the function

you’d like to use shows on the display (from when you’d

pressed the MODE KEY).

•You also use this key to select from the different wring cycles

and washing temperatures, as well as whatever ADDITIONAL

FUNCTIONS you might like to include in your washing

program.

FUNCTION BUTTONS

Rinse Hold

9This function is recommended for use when you can’t take your

clothes out of your washing machine immediately after the

program has finished. This function prevents wrinkles from

forming. Pressing this button will keep the last rinsing water

from draining. To reactivate the program so the cycle can

complete, repress the same button.

Extra Rinse

9You can have one more rinsing done in addition to the rinses

used in whatever washing program your machine is running.

Soak

9Using this function will ensure better cleaning by leaving your

clothes in water with detergent for a certain period of time

before your machine starts washing. You should use this

function for very dirty clothes.

Easy Ironing

9By using this function, you can ensure your clothes come out

less wrinkled after the washing program has finished.

Plus Water

9By using this function, you let your washing machine use

more water than it would usually do. This will reduce the

friction that normally occurs between your clothes. You

should use this function for delicate clothes and for any

clothes that you want rinsed really well.

Stain Remove

9You can ensure a more intensive wash with this function. You

should only use this for very dirty or stained laundry.

Adjusting wash water temperature

9You can Adjust the Wash Water temperature according to the

program you have selected using this function.

*NOTE: You cannnot set the wash water temperature to one

higher than the temperature of the program you have selected.

To adjust the temperature:

Use the Mode Key to move

the symbol as displayed

on the display panel.

NOTE: The maximum washing temperature of the program you

have selected will be shown on the display.

•You can reduce this temperature down to the washing

temperature you want by using the SELECT key. These levels

will appear on the display.

•If you want to cancel the temperature, press on the SELECT

key until the ‘COLD’ signal is shown on the display. When the

‘COLD’ signal appears, the symbol will show on the

display, like this:

•If you have skipped the temperature level that you wanted,

you can get back to it by pressing the SELECT key repeatedly.

•If you have selected a different temperature from the

maximum temperature, the symbol will remain displayed

until the program completes.

Please note: The temperature levels you can wash with are

shown on Table-2 (page 20). If you do not adjust the temperature

at all, the washing process will automatically run at the maximum

temperature allowed for the cycle you selected.

Adjusting the spin speed

9You can adjust the spin speed for a wash cycle. Always

be sure to select a lower spin speed for your delicate garments

To adjust the spin speed:

Use the MODE KEY to move to the

symbol on the display.

9The maximum spin speed of the wash program that

you have selected will now be shown on the display.

You can reduce the spin speed by using the

SELECT key. The following levels will appear on the display.

If you want to cancel the spin cycle, press SELECT

press on the SELECT key until the ‘NO SPIN’ signal is displayed. It looks

like this:

ÂIf you go past spin speed that you want to use, continue

to press the SELECT key until the spin speed that you require

appears in the display.

NOTE: If you have selected a different spin speed from the

maximum spin speed, the symbol on the display will remain lit

until the program has finished.

Spin cycles are shown on Table-2 (page 20) as ‘SPIN SPEED

ADJUSTMENT’. If you don’t make any adjustments to the spin speed

the spin cycle will complete at the maximum spin speed that the

machine will allow for a particular wash program.

Selecting an Additional Function

You can use the ADDITIONAL FUNCTIONSspecified in Table-1

(pages 18-19), depending on the type of program that you’re using

for your laundry.

To activate the ADDITIONAL FUNCTIONS:

Press the MODE KEY until the ADDITIONAL

FUNCTION you want lights up on the display.

When you move onto the ADDITIONAL

FUNCTION you want, the additional function

symbol will blink and the ‘OFF’ signal will

appear on the display. Press the SELECT

button to activate this function for your next

washing cycle.

9The ‘ON’ signal will show on the display.

9The ADDITIONAL FUNCTION you have selected will remain

turned on until the program has finished.

Note: SEE TABLE-1 (Pages 18-19 ) to see which ADDITIONAL

FUNCTIONS can be selected for each particular wash cycle.

To Change Additional Functions:

If you have selected the wrong ADDITIONAL FUNCTION,

you can change it:

•

•Use the MODE KEY to

SELECT the ADDITIONAL

FUNCTION that you really want.

The ‘ON’ signal will appear

on the display.

•

•Press the SELECT key. The

‘OFF’ signal will show on the

display. You have now

removed the additional

function you did not want

from the washing process.
