Baumatic BWF1106SS Manual de usuario
BWF1106SS
Washing machine
USER MANUAL FOR YOUR BAUMATIC
BWF1106SS
Washing machine
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 05/02/08
2
3
Contents
Environmental note 4
Important safety information 5 – 6
Specifications 7
Description of the appliance 8
Controlpanel 9
Programoptions 9
LCDdisplay 10
Wash program selection knob 10
Spin speed selection knob 10
Detergentdrawer 11
Preparing the wash cycle 12
Preparing your garments for washing 12
A selection of wash care symbols 13
Detergentsandconditioners 14
Wash program guidance 15
Wash program table 16 - 17
Selecting a wash program 18 - 19
Cancelling or pausing a wash program 19
Spin speed selection knob 20
Setting a program option 21
Settingadelaystart 22
Maintenance and cleaning 23
Indailyuse 23
Control panel and washer dryer cabinet 23
Detergentdrawer 23–24
The washing machine drum 24
Door 24
Error code failure system 25 – 26
Generaltroubleshooting 27
Poor wash results 28
Cleaning the drain pump filter 28 – 29
Installation 29
Unpacking the machine and removing the transit bolts 29 – 30
Positioning and levelling the appliance 31
Connecting to the mains water supply 32
Wateroutlet 33
Powersupply 34
Before first use maintenance wash 35
Contactdetails 36
ENVIRONMENTAL NOTE
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
4
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Technical
Department.
General Safety
oRepairs to your appliance must only be carried out by a
Baumatic engineer or one of its authorised service agents. Any
attempt by an inexperienced person to repair the appliance,
could result in injury or damage to your washing machine.
oIf you notice that the mains cable is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
oThe appliance should be turned off and isolated from the mains
supply, before either cleaning or maintenance work is attempted.
oThe mains cable must not be used to pull the plug out of the
electrical socket.
oThe machine should not be sprayed with water.
oThe glass of the porthole door may become hot during the higher
temperature wash programs.
oThe machine should be allowed to cool before carrying out an
emergency drain or cleaning the drain filter.
oIt is possible for small animals to chew either mains cables or
water hoses, which could cause an electric shock hazard.
Installation
oThe installation instructions contained within this user manual
should be followed.
oIt is obligatory for the completed installation to comply with all
relevant building regulations and local water authority
requirements.
5
6
oBefore the first use of the appliance, we advise that a 90
degree cotton wash is completed. No garments should be
placed inside the machine; however a small amount of
detergent must be used.
During Use
oIt is recommended that the appliance is unplugged and the
water supply is turned off after the machine is used.
oThis appliance is only designed to wash normal domestic
washloads. If you use your washing machine in any other way or
it is incorrectly used, then Baumatic accepts no liability for any
damage that might be caused and any guarantee will be void.
oNo attempt should be made to alter or modify the specifications
of this appliance.
oThe detergents that you place in this appliance should be
suitable for automatic washing machines. With regards to dosage
levels, the detergent manufacturer’s recommendations should be
followed.
oYou should not wash garments that have been in contact with
flammable materials.
oYour washing machine should not be used for dry cleaning.
oIf you use either dyes or bleaching agents inside this machine,
then you should consult with the manufacturer of these products
to make sure they are suitable for use in your washing machine.
Baumatic cannot be held responsible for any damage that may
result.
Child Safety
oYour washing machine should only be used by adults. You should
not allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
oIt could be possible for a child or pet to gain access to the
washing machine through the porthole door. Therefore please
check the drum before using the appliance.
oAny packaging that is removed from the machine should be kept
away from children.
oAll detergents should be kept out of children’s reach in a safe
place.
7
Specifications
915 wash programs
96kg wash load
91100 rpm maximum spin speed
9LCD display
9Electronic control
9Spin speed regulation via a control knob
9Remain time indicator
93 Option buttons: Easy iron
Extrarinse
Intensivewash
9Unbalance control system
9Suspend the clothes in water option
9Door safety lock
9Stainless steel drum
9Adjustable feet
9Error code failure system
Appliance dimensions
Height: 850 mm
Width: 590 mm
Depth: 550 mm
Energy efficiency
Energy rating (washing) A+
Washperformance A
Water extraction performance C
Description of the appliance
8
Control panel
Wash program selection knob
This control knob allows you to select the wash program of your
choice.
Start/pause button
Once a wash program has been selected, this button should be
pressed to start the wash cycle. It can also be used to pause a wash
program once it’s in progress.
Program option button
This button needs to be pressed after a wash program has been
selected, but before the wash program has been started. If you
select a different wash cycle after pressing a program option, it
will need to be reselected.
Intensive wash: This function should be selected if you are washing
heavily soiled, stained clothes. It achieves a better level of wash
performance by extending the wash program that you have selected.
Easy iron: This function helps to prevent garments from creasing by
carrying out a program where the rotation of the drum will fluff out the
garments, after the spin cycle has completed. This should make the
garments easier to iron.
Extra rinse: This function increases the level of the final rinse for the
selected wash program. This should be selected if large loads are being
washed or the garments belong to somebody who has sensitive skin.
This option will increase the amount of water the appliance uses.
9
LCD display
Wash program selection knob
Spin speed selection knob
