BWMI1206

BWMI1407

Fully integrated

washing machine

USER MANUAL FOR YOUR BAUMATIC

BWMI1206

BWMI1407

Fully integrated

washing machine

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference.

GS 06/01/11

Contents

Environmental note 4

Important safety information 5 - 6

Specifications 7–8

Product and aperture dimensions 7

Product specifications 7 – 8

Baumatic consumables 8

Control panel 9 - 13

Detergent drawer 12 - 13

Preparing the wash cycle 13 - 19

Preparing your garments for washing 13 - 14

A selection of wash care symbols 14

Detergents and conditioners 15

Programtable 16

Program description 17 – 18

Wash program guidance 19

Selecting a wash program 19 - 23

Cancelling or pausing a wash program 20

Delay start feature 20 – 21

Saving energy when using your washing machine 21

Automatic consumption reduction 21

Removingstains 22

Stain removal rules 22

Stain removal guide 22 - 23

Maintenance and cleaning 24 - 26

Indailyuse 24

Control panel and washing machine cabinet 24

Detergent drawer 24 - 25

The washing machine drum 25

Door 25

90 degree maintenance wash 25

Long periods of not in use 26

General troubleshooting 26 - 27

Poorwashresults 28

Installation 29 - 36

Unpacking and removing the transit bolts 29 - 30

Positioning and levelling the appliance 30 – 31

Fitting the décor door 31 - 33

Connecting to the mains water supply 33

Wateroutlet 34

Powersupply 35

Before first use maintenance wash 35 – 36

Contactdetails 37

Environmental note

Note

: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Advice Line.

General Safety

oRepairs to your appliance must only be carried out by a

Baumatic engineer or one of its authorised service agents. Any

attempt by an inexperienced person to repair the appliance,

could result in injury or damage to your washing machine.

oIf you notice that the mains cable is damaged. The appliance

must not be used. The same applies if you notice that the

worktop, control panel or base area is damaged. As this could

allow access to the internal components of the machine.

oThe appliance should be switched off and isolated from the

mains supply, before either cleaning or maintenance work is

attempted.

oThe mains cable must not be used to pull the plug out of the

electrical socket.

oThe machine should not be sprayed with water.

oThe glass of the porthole door may become hot during the higher

temperature wash programs.

oThe machine should be allowed to cool before carrying out an

emergency drain or cleaning the drain filter.

oIt is possible for small animals to chew either mains cables or

water hoses, which could cause an electric shock hazard.

Installation

oThe installation instructions contained within this user manual

should be followed.

oIt is obligatory for the completed installation to comply with all

relevant building regulations and local water authority

requirements.

oBefore the first use of the appliance, we advise that a

90°C cotton wash is completed. No garments should be

placed inside the machine; however a small amount of

detergent must be used.

During Use

oIt is recommended that the appliance is unplugged and the

water supply is switched off after the machine is used.

oThis appliance is only designed to wash normal domestic

washloads. If you use your washing machine in any other way or

it is incorrectly used, then Baumatic accepts no liability for any

damage that might be caused and any guarantee will be void.

oNo attempt should be made to alter or modify the specifications

of this appliance.

oThe detergents that you place in this appliance should be

suitable for automatic washing machines. With regards to dosage

levels, the detergent manufacturer’s recommendations should be

followed.

oYou should not wash garments that have been in contact with

flammable materials.

oYour washing machine should not be used for dry cleaning.

oIf you use either dyes or bleaching agents inside this machine,

then you should consult with the manufacturer of these products

to make sure they are suitable for use in your washing machine.

Baumatic cannot be held responsible for any damage that may

result.

Child Safety

oYour washing machine should only be used by adults. You should

not allow children in the area of the machine unsupervised. You

should not let them touch the controls or play with the appliance.

oIt could be possible for a child or pet to gain access to the

washing machine through the porthole door. Therefore please

check the drum before using the appliance.

oAny packaging that is removed from the machine should be kept

away from children.

oAll detergents should be kept out of children’s reach in a safe

place.

Specifications

Product dimensions: Aperture dimensions:

Height: 820 mm 825 mm

Width: 596 mm 600 mm

Depth: 541 mm 570 mm

Product specifications

BWMI1206 BWMI1407

oLoad capacity: 6 kg 7 kg

oMaximum spin speed: 1200 rpm 1400 rpm

oDrum size: 46 litres 56 litres

o15 wash programs

o3 option buttons: Pre-wash, Extra Rinse and Anti-Crease

oVariable spin speed with no spin option

oPorthole diameter: 30 mm

o180° door opening

oLED display

oDigital countdown indicator

oDelay start

oSeparate temperature control option

oAutomatic consumption reduction

oSelf-adjusting water level to load

oImbalance control system

oOverflow protection

oFoam protection

oSafety lock

oFuzzy logic

oAdjustable feet

Energy efficiency:

Energyrating A+

Washperformance A

Water extraction performance class B (BWMI1206)

A (BWMI1407)

Baumatic Consumables

oBC002 Washing Machine and Dishwasher Descaler (200g)

oBC006 Washing Bag (40 x 60 cm)

To order a Baumatic consumable product please call 0123 5437 244

and quote the product code. You can also order online from

eshop.baumatic.co.uk

Control panel

A) Detergent drawer

B) Cycle progress indicator

C) Start / pause button

D) Delay start button

E) Pre-wash button

F) Extra rinse button

G) Anti-crease button

H) Spin speed control knob

I) Wash temperature control knob

J) Door open button

K) Program selection knob

Cycle progress indicator

This display shows the time remaining for a set wash program. The

icons indicate the following remaining times:

Start light: Remaining time above 60 minutes

60 light: Remaining time less than 60 minutes

30 light: Remaining time less than 30 minutes

15 light: Remaining time less than 15 minutes

Stop light: End of the program.

The display also shows the set delayed start time of 3, 6 or 9 hours.

The stop light will flash while a program is being set until the

program has started or the program selection knob is returned to

the “OFF” position.

Start / pause button

This button should be used to start the chosen wash

program. When the button is pressed, the appliance will begin the

cycle within a few seconds. You can also press this button to pause

a wash cycle in progress and continue after. When a program is

selected, wait for the STOP light to flash before pressing the

Start / Pause button.

Delay start button

This button can be used to program a delay start of 3, 6 or 9

hours. See the section “Delay start feature” for instructions.

Pre-wash button

This option is useful for heavily soiled loads and can be

used only on some programs.

Extra rinse button

This button will program the machine to add an additional

rinse to the cycle. This function is ideal for people with sensitive

skin as it removes more of the detergent from washing. It is

advisable to use this function for very dirty loads where extra

detergent has been used. This option can be used only on some

programs.

Anti-crease button

Use this button to select the anti-crease function. This will

minimise creases in mixed fabrics, delicate fabrics and woollens and

silk. It works in the following ways:

Fabric

(according to

program

selected)

Process

Mixed fabrics The water is gradually cooled throughout the final

2 rinses with no spinning and then a delicate spin

assures the maximum relaxation of the fabrics.

Delicate fabrics The final 2 rinses are carried out with no spinning

and then the fabrics are left in water until it is

time to unload. When you are ready to unload,

press the anti-crease button (G) to drain.

Woollens / silk After the final rinse the fabrics are left in water

until it is time to unload. When you are ready to

unload, press the anti-crease button (G) to drain

and spin.
