Baumatic TITAN1 Manual de usuario

TITAN1 Stainless steel

side by side frost free

fridge/freezer

USER MANUAL FOR YOUR BAUMATIC

TITAN1 Stainless steel side by side

570 litre frost free fridge/freezer

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

DD 10/05/07

Contents

Environmentalnote 4

Important safety information 5 – 6

Specifications of your fridge freezer 7

Dimensions of the appliance 7

Energy efficiency class 7

Cubiccapacities 7

Specifications of your appliance 7

Descriptionoftheappliance 8

Description of the product features 9-10

Using your Baumatic fridge freezer 10

Beforeswitchingon 10

Duringfirstuse 11

Controlpanel 11

Turning on the appliance and setting the thermostat 12

Arranging and storing food in the fridge section 13-14

The freezer compartment 14

Freezing fresh food 14-15

Tipsonfreezing 15

Makingicecubes 15

Important user information 16

Cleaning and maintenance 16-18

Defrosting the freezer compartment 18-19

Replacing the light bulb 19-20

Installation 21

Electricalconnection 21

Positioning 22

Installationpreparation 23

Removing the freezer door 23-24

Removingthefridgedoor 25

Replacing the freezer door 26

Replacing the fridge door 27

Levelling the appliance and adjusting the doors 28

Fitting the front cover 29

Troubleshooting 29-30

Baumatic Ltd. conditions of guarantee 31

Contactdetails 32

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Technical

Department.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing food that needs to

be chilled and refrigerated. If it is used for any

other purpose or it is not used correctly, then

Baumatic Ltd. will accept no liability for any

damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipework

does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ensure that the appliance has been

disconnected from your mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated,

so that there is proper air flow between the

bottom of the unit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

Service

You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious

malfunction. If you require a service call then please

contact the Baumatic Service Department.

Specifications of your fridge freezer

Congratulations on purchasing a Baumatic fridge freezer

Dimensions of your appliance

oHeight: 1790 mm

oWidth: 900 mm

oDepth: 730 mm

Energy efficiency class

oEnergy class: A

Cubic capacities

oGross capacity (fridge): 361 litres

oGross capacity (freezer): 209 litres

oNet capacity (fridge): 339 litres

oNet capacity (freezer): 198 litres

Specifications of the appliance

oFrost free fridge and freezer

oMulti airflow cooling system

oDeodorizer

oAnti-bacterial surface

o4 Safety glass shelves

oMeat drawer

oFolding wine tray

o2 Salad crispers

o2 Egg racks

oButter compartment

o3 General racks

o2 Bottle racks

o4 Freezer shelves

o6 Freezer storage compartments

o2 Removable plastic drawers

oIce cube tray

oDoor storage

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located on the front left edge

of the inside of the fridge section. You will need to open the door of

your appliance to be able to find it. The rating plate will indicate the

ambient temperature range that your appliance will function correctly

within.

Description of the appliance

Freezer section

1) Door storage compartments

2) Freezer shelves (x 4)

3) Dried foods compartment

4) Meat storage compartment

Fridge section

5) Refrigerator shelves (x 4)

6) Movable egg container

7) Salad/vegetable drawer

8) Fruit drawer

9) Dairy compartment

10) Door storage compartments

12) Chiller case

Description of the product features

Shelves

oThe shelves may be placed in any of the guide slots within the

interior of the appliance. They are protected from sliding out.

oTo remove a shelf: Take off all of the items that are stored on

the shelf that you want to remove. Then lift the front of the shelf

and carefully pull it out of the grooves.

Freezer section door storage compartments

oThe top door storage compartment should not have ice cream or

foods that are going to be stored for a long period of time put in

it.

oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE

SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS

THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.

Dried foods compartment

oFor storage of dried foods (such as dried herbs, dried vegetables

etc).

Meat storage compartment

oFor storage of meat and fish (we would recommend that they

are stored in a foil cover or a vinyl wrap).

Fridge section door storage compartments

oThe door liner holds various shelves, which are suitable for

storing eggs, cheese, butter and yogurt. As well as smaller

packages, tubes, cans etc.

oThe lower shelves should be used for storing reasonably sized

bottles.

oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE

SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS

THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.

Movable egg container

oThis case can be placed on any shelf, depending on how the food

in your fridge is arranged.

Salad/vegetable drawer

oFor storing salad and vegetables, the drawer is designed to keep

the contents fresh for as long as possible.

Fruit drawer

oFor storing fruits, the drawer is designed to keep the contents

fresh for as long as possible.

oCare should be taken when storing tropical fruit (bananas and

pineapples etc) and tomatoes. As these types of items can easily

deteriorate in a lower temperature.

Chiller case

oMaximises the storage time of meat and fish by storing it at 0°C

without freezing it.

Using your Baumatic fridge freezer

Before switching on

oMake sure that it has been installed by a suitably qualified

person, as per the information contained in Baumatic’s

installation instructions.

oAfter delivery, wait for eight hours before connecting the

appliance to your mains supply. This means that any refrigerant

gasses that may have been disturbed during the transportation

process are allowed to settle.

oThe outside of the appliance and the removable accessories

contained within it, should be cleaned with a solution of liquid

detergent and water.

oThe interior of the appliance should be cleaned

with a solution of sodium bicarbonate dissolved in

lukewarm water. The interior and accessories

should be thoroughly dried, after the cleaning

process has been completed.

oThere can be an odour when you first switch on the appliance. It

will lessen as the appliance starts to cool.
