Sidewing Table

Assembly Instructions

P1 Support Arm 1 EA

P2 Shelf 1 EA

P3 Wire Stop 1 EA

P4 “U” Bracket 2 EA

Part Drawing Description Qty Part Drawing Description Qty

Sidewing Table

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

Should you require assistance during assembly,

please call our Customer Service Department

Monday - Friday 8 a.m. - 5 p.m.

Central Standard Time 1-800-749-2258

Missing Parts or UPS Damaged Parts

ForYourConvenience youcan

EMAILus at

[email protected]

24HOURS 7 DAYSAWEEK

Hardware List

Allen Wrench 1 EA

Screw-Phillips 2 EA

Knob 1 EA

Screw M6X10mm 6 EA

1.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

IdentifyandSeparateallthe PartsandHardware.

iTeach 2 Sidewing

2.)

66615A,66620_11-29-11

Bottom View

Attachthe Shelf (P2)tothe SupportArm(P1)using twoScrews(A)

asshownin Illustration#1. Insert theWireStop (P3)intothe top

holesinthe SupportArm(P1)andsecure inplacefrom thebottom

usingtwoPhillipsScrews (C). ScrewinKnob(D) into thebottom

holeinthe Support Arm(P1).

Illustration #1

3.) Attachthe assembly from Step2to the backofyour cart using twoUBrackets (P4)and

fourScrews(A)asshown inIllustration#2. TightenScrewswith Allen Wrench(B).

Illustration # 2
