Balluff BNI EIP-508-005-E002 Manual de usuario

BNI EIP-508-005-

E002

EtherNet/IP™

IP69 modules

User's Guide

www.balluff.com

Table of Contents

1General 3

1.1. Structure of the guide 3

1.2. Typographical Conventions 3

Enumerations 3

Actions 3

Syntax 3

Cross-references 3

1.3. Symbols 3

1.4. Abbreviations 3

1.5. Deviating views 3

2Safety 4

2.1. Intended use 4

2.3. General Safety Notes 4

2.4. Resistance to Aggressive Substances 4

Dangerous Voltage 4

3First Steps 5

3.1. Module Overview 5

3.2. Mechanical Connection 6

3.3. Electrical Connection 6

Power Supply 6

Grounding 6

Ethernet IP Interface 6

IO-Link / I/O Port 7

Port 7

4Technical Data 8

4.1. Dimensions 8

4.2. Mechanical Data 8

4.3. Operating conditions 8

4.4. Electrical Data 8

4.5. Ethernet 9

4.6. Function indicators 9

Module Status 9

Port 10

5Integration 11

5.1. Integration in Rockwell RS Logix 5000 11

5.2. Address Specifications 15

5.3. Data Configuration 15

5.4. Configuration Data 15

Module Configuration BNI EIP-502-105-XXX 16

Module Configuration BNI EIP-508-X05-XXX 16

Module Configuration BNI EIP-507-005-Z040, BNI EIP-527-005-Z040 16

Module Configuration BNI EIP-508-XXX-XXXX-C06 16

IO-Link Port Configuration 17

Cycle Settings 17

Validation Settings 18

Parameter Server 18

Upload Flag on the IO-Link Device 19

6Configuration via Explicit Messages 20

QuickConnect 20

Rockwell 21

Automation products that are compatible with QuickConnect 21

Balluff Network Interface EtherNet/IP™

www.balluff.com

Example with Rockwell Components 22

PLC Program 23

Fault State 26

Enable/Disable Fault State 26

Fault State Action 26

IO-Link Device Para-meterization 27

Read IO-Link Parameter 27

Write IO-Link Parameter 29

7Process Data 30

7.1. Process Data Inputs 30

Standard Input Data 30

IO-Link Input Data 31

7.2. Process Data Outputs 32

Standard Output Data 32

IO-Link Output Data 32

8Web Server 33

8.1. General Information 33

8.2. Navigation / Info 34

8.3. Login/Logout 35

8.4. "Home" dialog 36

8.5. "Ports" dialog 38

No appropriate IODD uploaded 38

Appropriate IODD uploaded 39

8.6. "IODD" dialog 41

8.7. "Config" dialog 42

8.8. "Log" dialog 44

9Appendix 46

9.1. Order number 46

9.2. Ordering information 46

www.balluff.com

1 General

1.1. Structure of the

guide

This guide is arranged so that one chapter builds upon the other.

Chapter 2: Basic safety instructions

Chapter 3: Main steps for installing the device

………

1.2. Typographical

Conventions

The following typographical conventions are used in this manual.

Enumerations

Enumeration is shown in the form of bulleted lists.

• Entry 1,

• Entry 2

Actions

Action instructions are indicated by a preceding triangle. The result of an action is indicated

by an arrow.

Action instruction 1.

Result of action.

Action instruction 2.

Actions can also be indicated as numbers in parentheses.

(1) Step 1

(2) Step 2

Syntax

Numbers:

Decimal numbers are shown without additional information (e.g. 123),

Hexadecimal numbers are shown with the additional indicator hex (e.g., 00hex) or the prefix

"0x" (e.g., 0x00).

Cross-references

Cross-references indicate where additional information on the topic is located.

1.3. Symbols

Note

This symbol indicates general notes.

Attention!

This symbol indicates a security notice which must be observed.

1.4. Abbreviations

BNI Balluff Network Interface

I Standard input port

EIP EtherNet/IP™

EMC Electromagnetic compatibility

FE Function ground

O Standard output port

1.5. Deviating views

Product views and illustrations in this manual may differ from the actual product. They are

intended only as illustrative material.

Balluff Network Interface EtherNet/IP™

www.balluff.com

2 Safety

2.1. Intended use

The BNI EIP-… is a decentralized IO-Link, input and output module for connecting to the

EtherNet/IP™ network.

2.2. Installation and

Startup

Attention!

Installation and startup are to be performed by trained technical personnel only.

Skilled specialists are people who are familiar with the work such as installation

and the operation of the product and have the necessary qualifications for these

tasks. Any damage resulting from unauthorized tampering or improper use shall

void warranty and liability claims against the manufacturer. The operator is

responsible for ensuring that the valid safety and accident prevention regulations

are observed in specific individual cases.

2.3. General Safety

Notes

Commissioning and inspection

Before commissioning, carefully read the User's Guide.

The system must not be used in applications in which the safety of persons depends on the

function of the device.

Intended use

Warranty and liability claims against the manufacturer shall be rendered void by damage

from:

• Unauthorized tampering

• Improper use

• Use, installation or handling contrary to the instructions provided in this User's

Guide.

Obligations of the owner/operator

The device is a piece of equipment in accordance with EMC Class A. This device can

produce RF noise. The owner/operator must take appropriate precautionary measures

against this for its use. The device may be used only with a power supply approved for this.

Only approved cables may be connected.

Malfunctions

In the event of defects and device malfunctions that cannot be rectified, the device must be

taken out of operation and protected against unauthorized use.

Approved use is ensured only when the housing is fully installed.

2.4. Resistance to

Aggressive

Substances

Attention!

The BNI modules always have good chemical and oil resistance. When used in

aggressive media (such as chemicals, oils, lubricants and coolants, each in a high

concentration (i.e. too little water content)), the material must first be checked for

resistance in the particular application. No defect claims may be asserted in the

event of a failure or damage to the BNI modules caused by such aggressive

media.

Dangerous

Voltage

Attention!

Before working on the device, switch off its power supply.

Note

In the interest of continuous improvement of the product,

Balluff GmbH reserves the right to change the technical data of the product and

the content of these instructions at any time without notice.

www.balluff.com

3 First Steps

3.1. Module Overview

Figure – Overview: BNI EIP-508-005-E002

1 EtherNet/IP™ port 1

2 Power OUT

3 Port 00 / 01

4 Port 02 / 03

5 Port 04 / 05

6 Port 06 / 07

7 Mounting hole

8 Port 14 / 15

9 Port 12 / 13

10 Port 10 / 11

11 Pin/port LED: signal status

12 Port 08 / 09

13 Status LED: communication / module

14 Power IN

15 EtherNet/IP™ port 2

Balluff Network Interface EtherNet/IP™

www.balluff.com

3 First Steps

3.2. Mechanical

Connection

The module is secured by means of two M6 screws and two washers.

Insulation support is available separately.

3.3. Electrical

Connection

Power Supply

7/8”, male

OUT

7/8” female

Pin Function Description

1 +24 V Actuator supply

2 +24 V Module / sensor supply

0 V GND module / sensor and actuator supply

Note

Provide sensor/bus power and actuator power from separate power sources if

possible. The total current of the module must not exceed 9 A, even if the

module is looped through a circuit.

Grounding

Note

Der FE-connection between the housing and machine must display a low

impedance and is established via the clamping bolt.

Ethernet IP

Interface

M12, D-coded, female

Function

Tx+

Transmit Data +

Rx+

Receive Data +

Tx-

Transmit Data -

Rx-

Receive Data -

www.balluff.com

3 First Steps

IO-Link / I/O Port

M12, A-coded, female

Function

+24 V, 1.6 A

Input/output 2A

GND

IO-Link/input/output 2A

n.a.

Attention!

Each output supplies maximum 2 A.

Note

For the digital sensor inputs, refer to guideline on inputs EN 61131-2, Type 2.

Note

The total current of the module must not exceed 9 A.

Note

Unused I/O ports must be provided with cover caps to comply with degree of

protection IP69.

Port

0-7

BNI EIP-508-005-E002

IN / OUT / IO-Link

Balluff Network Interface EtherNet/IP™

www.balluff.com

4 Technical Data

4.1. Dimensions

4.2. Mechanical Data

Housing material

Stainless steel (V4A)

Enclosure rating per IEC 60529

IP 69 (only when plugged-in and threaded-in)

Supply voltage

7/8" 4-pin, connector / female

Input ports / output ports

M12, A-coded (8x female)

Dimensions (W x H x D in mm)

70 x 228 x 44.1

Type of mounting

Screw mounting with 2 mounting holes

Weight

Approx. 684 g

4.3. Operating

conditions

Ambient temperature

Storage temperature

-5 °C ... 70 °C

-25 °C ... 70 °C

4.4. Electrical Data

Supply voltage

18...30.2 V DC, in accordance with EN 61131-2

Ripple

< 1%

Input current at 24 V

130 mA @ 24V

www.balluff.com

4 Technical Data

4.5. Ethernet

Ethernet IP port

2 x 10Base/100Base Tx

Connection for Ethernet IP port

M12, D-coded, female

Cable types in accordance with

IEEE 802.3

Shielded, twisted pair min. STP CAT 5/ STP CAT 5e

Data transmission rate

10/100 Mbps

Max. cable length

100 m

Flow control

Half-duplex/full-duplex (IEEE 802.33x pause)

4.6. Function

indicators

Module Status

LED

Display

Description

Green

Output power OK

Red, flashing

Low output power (< 18V)

Red

No output power (< 11V)

Green

Input power OK

Red, flashing

Low input power (< 18V)

Mod

Green, flashing

Incorrect or no configuration of the module

Green

Module is working

Red, flashing

Fixed bus clock is not possible

Red-green, flashing

Initial sequence

Netw

ork

Off

Module has no IP address

Green, flashing

Module has IP, but no connection established

Green

Connection established

Red, flashing

Connection timeout

Red-green, flashing

Initial sequence

100

Off

Bus clock: 10 Mbps

Yellow

Bus clock: 100 Mbps

LNK

Green

Data transfer

Status LEDs

Port LEDs

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Balluff

Balluff

Balluff BNI ECT-508-105-Z015 Manual de usuario

Balluff

Balluff BNI IOL-252-000-Z013 Manual de usuario

Balluff

Balluff BNI PNT-508-105-Z031-002 Manual de usuario

Balluff

Balluff BNI ECT-507-005-Z040 Manual de usuario

Balluff

Balluff BNI PBS-507-001-Z011 Manual de usuario

Balluff

Balluff BNI PNT-508-005-E002 Manual de usuario

Balluff

Balluff BNI006A Manual de usuario

Balluff

Balluff BNI EIP-306-100-Z010 Manual de usuario

Balluff

Balluff BNI EIP-502-105-Z015 Manual de usuario

Balluff

Balluff BNI IOL-302-S02-Z012-C11 Manual de usuario

Balluff

Balluff MICROPULSE BTM-AR2-001 Manual de usuario

Balluff

Balluff BNI EIP-104-105-Z015 Manual de usuario

Balluff

Balluff BNI EIP-508-105-Z067 Manual de usuario

Balluff

Balluff BNI PNT-502-102-Z015 Manual de usuario

Balluff

Balluff BNI EIP-50 105-Z015 Series Manual de instrucciones

Balluff

Balluff BIS V-6111 series Manual de lista de piezas

Balluff

Balluff BNI PBS-202-000-Z001 Suplemento

Balluff

Balluff Micropulse BTL5 Series Manual de usuario

Balluff

Balluff BNI EIP-502-105-R015 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
