Baby Jogger City Single Manual de usuario

Important, Keep for

Future Reference

Assembly

Instructions

City Single

Amazing 360° Turns

Make For Extreme Maneuverability

Seat

Reclines

23°

• Important, keep this booklet for future reference.

• Accessories which are not approved by the manufacturer or distributor

should not be used.

• WARNING: Prevent serious injury to your child by always using the

safety harness.

• WARNING: Any load attached to the handle affects the stability of the jogger.

• WARNING: It may be dangerous to leave child unattended.

• Always use your wrist strap – these joggers can really roll, and the

wrist strap gives you control if you should slip or fall down.

• The passenger should remain seated (no standing in the jogger).

• Watch out for cars – never assume that a driver can see you and your child.

• Never use Roller Blades while using a Baby Jogger Jogger.

• Total weight load recommended for this Jogger is 75 lbs.

(combined passenger and baggage weight.)

• This Jogger seats one passenger.

• WARNING: Recommended weight for seat pocket is 2 pounds and basket

is 10 pounds. Excessive weight may cause a hazardous unstable

condition to exist.

• It may be unsafe to use replacement parts other than those supplied or

approved by the manufacturer.

For the sake of your precious cargo, please read

these warnings before using your Baby Jogger.

Frame

1. Unpack Jogger from box

and set wheels aside.

4. The Jogger frame will click into place. 5. Flip Jogger to upright position.

3. Push footplate of Jogger

away from handle by

pushing axle of Jogger

up and out.

2. Unfold adjustable

handle while

pushing both

buttons on the sides

of Jogger handle.

1 To install front wheel,

lay jogger back so handle

is resting on floor. Lock

front wheels to prevent

the forks from swiveling.

2 Insert the front wheel

into the forktips by

aligning the axle flats

with the forktip flats.

3 Tighten by turning the

wheel lever and holding

the opposite side.

4 Close the wheel lever

making sure that it is

flush with the tubing.

Be sure not to over

tighten.

Front Wheel

Front Wheel Locking Lever

Turn to the left to lock front wheel.

• To install, gently slide the

wheel’s rear axle into the hole

in the axle end until you hear it

click into place.

• To remove, simply push in

the spring lock while pulling

out the wheel.

Rear Wheels

Adjusting safety harness:

1 Loosen the shoulder straps from their plastic guides.

2 Slide the end of each strap through pair of seat loops closest to your child’s shoulder.

Safety Harness

WARNING: Avoid serious injury from falling or sliding out.

Always use safety harness!

3 Slide the end of the shoulder strap back into plastic guide.Please note: If you feel the straps are

too tight, you may adjust their length by sliding the plastic guides toward the top of the seat.

4 Lock both sides of the strap mechanism into the center buckle. To adjust the center strap,

move its plastic guide up or down.

Brake

Rear Wheel Parking Brake

• Simply push brake pedal down to engage brake and lift up to release.

1Simply adjust seat

straps to desired

degree of recline.

2Pull on strap when you

want to return the seat

to its upright position.

3Rear flap serves as sun

canopy when seat is in

reclined position.

Simply secure it to

Velcro on seat.

Reclining Seat

4Jogger is packaged with seat support frame and can be easily removed

or inserted into the seat back if additional support is desired.

Be sure to remove the frame from the back of the seat before washing.

Seat

1 Snap seat to frame. 2 Attach bottom part of seat

to footplate with the Velcro.

3 Wrap bottom straps around

frame, thread strap through

D-ring and secure.

4 Snap safety strap to frame.
