Baby Jogger CITY ELITE SINGLE Manual de usuario
Read these
instructions carefully
before use and
keep them for
future reference.
Your child’s safety may be
affected if you do not follow
these instructions.
Assembly
Instructions
City Elite Single
Amazing 360° Turns
Make For Extreme Maneuverability
This product complies with BS EN 1888:2003 inc. A1,2,3: 2005
B
We wish you many happy journeys with your new
stroller! Your stroller is a great product, and we
are proud to manufacture it. If you have any
questions or comments, please give us a call at:
1.800.241.1848
Thank You!
1
• WARNING: DO NOT exceed 3mph. – this stroller is not designed for running,
jogging, skating or roller blading.
• WARNING: Prevent serious injury to your child by always using the
safety harness.
• WARNING: Any load attached to the handle affects the stability of the stroller.
• WARNING: It may be dangerous to leave your child unattended.
• WARNING: Recommended weight for seat pocket is 2 pounds and basket
is 4.4 pounds. Excessive weight may cause a hazardous unstable
condition to exist.
• WARNING: Stroller is not meant to be used for transporting children up or
down stairs. Damage resulting to stroller will not be covered under warranty.
• Accessories which are not approved by the manufacturer or distributor
should not be used.
• The passenger should remain seated (no standing in the stroller).
• Watch out for cars – never assume that a driver can see you and your child.
• This stroller is suitable to be used from birth.
• Total weight load recommended for this stroller is 75 lbs. / 34 kg.
(combined passenger and baggage weight.)
• This stroller seats one passenger.
• It may be unsafe to use replacement parts other than those supplied or
approved by the manufacturer.
For the sake of your precious cargo, please read
these warnings before using your stroller.
Contents
Warnings ................................. 1
Frame ...................................... 3
Front Wheel............................. 4
Rear Wheels ............................ 5
Safety Harness ......................... 6
Brake....................................... 7
Reclining Seat .......................... 8
Seat......................................... 9
Raised Kicker ........................... 10
Basket...................................... 10
Canopy.................................... 11
In Motion ................................ 12
Stroller Care............................. 13
3
1. Unpack stroller from box and set
rear wheels aside. Ensure that
storage strap is not fastened
around frame before unfolding
stroller.
4. Pull front wheel fork tips
up from underneath the
handlebar. Then, pull bottom
of frame up and away from
handlebar.
3. Adjust handlebar
downwards so it is
touching the floor.
Place canopy aside.
5. Lay stroller flat so that both ends
are resting on the floor. The
stroller will frame will click and
lock into place.
WARNING: Ensure all
locking devices are
engaged before use.
To fold: Unsnap safety strap from frame and pull up on fold strap.
Frame
2. Note that the front wheel is
stored in the under basket
for packaging. Lift kicker,
and place front wheel aside.
6. Turn stroller over.
4
Front Wheel
1 To install front wheel, lay stroller
back so the handle is resting on
the floor. Lock front wheel to
prevent the forks from swiveling.
2 Insert the front wheel into the fork tips by
aligning the axle flats with the fork tip flats.
3 Tighten by turning the wheel
lever clockwise while holding
the opposite side.
4 Close the wheel lever making sure that
it is flush with the tubing. Be sure not to
overtighten.
5
1 To install, gently slide the rear wheel’s axle into the hole in the frame until the wheel clicks into place.
2 To remove, simply press
the wheel button while
gently sliding the wheel
away from the frame.
Rear Wheels
6
Safety Harness
WARNING: Always use the crotch strap in combination with the
shoulder straps and waist belt.
1 Unclip top of shoulder
strap from the seat and
re-clip on the pair of
seat loops closest to
your child’s shoulder
height.
2 To adjust the shoulder
and crotch strap
length: Remove the
shoulder pads and slide
the plastic guide up or
down to lengthen or
shorten.
7
WARNING: Engage parking device before loading and unloading
passenger.
Brake
• Simply push
brake pedal down
to engage rear
parking brake and
lift up to release.
3 To buckle the harness: Simply
push side buckle into center
buckle until it locks into place.
To unbuckle: Push one side
of the center button and pull
the corresponding side buckle
away from the center buckle.
Repeat to unbuckle other side.
1To recline: Pinch the clamps behind the seat and on the mesh section of the seat, and slide
them down to desired recline. Pull seat down on both sides to match recline position of clamps.
Reverse steps to return to the upright position.
Reclining Seat
8
• Weather Cover: If desired, pull weather cover
down and over the seat back mesh. Secure
firmly over both sides of seat. When not in
use, roll weather cover up and fasten with
elastic loop and barrel provided under top of
the seat fabric.
