Axis Q1656-LE Manual de usuario

AXISQ1656-LEBoxCamera

RepaintingInstructions

AXISQ1656-LEBoxCamera

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

AXISQ1656-LEBoxCamera

Repainttheprouct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentoparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Materialsusedinthisproduct

•Theweathershieldisplastic.

•Therestoftheproductispowdercoated.

Disassembly

Disassemblethehousing

1.Removethescrewsandthetopcoverfromthebottomchassis.

AXISQ1656-LEBoxCamera

Repainttheprouct

1ScrewT20(4x)

2Bottomchassis

3Topcover

2.Removethescrewsandtheweathershield.

AXISQ1656-LEBoxCamera

Repainttheprouct

1ScrewT20(2x)

2eathershield

Disassemblethewallmountbracket

1.Removethescrewatthebottomofthearm.

2.Separatethesocketandthesuarenut.

3.Removethefourscrewsfromtheballjoint.

AXISQ1656-LEBoxCamera

Repainttheprouct

1ScrewT30

2Arm

3Socket

4Squarenut

5ScrewT20(4x)

6Balljoint

Masking

Maskingthetopcover

Maskthefollowingpartsofthetopcover:

1.Thefrontwindowincludingtheblackareas.

2.Thescrewholes.

3.Everythingontheinside.

4.Theventmembrane.

5.Thelabel.

AXISQ1656-LEBoxCamera

Repainttheprouct

1Frontwindow

2Screwholes(4x)

3Inside

4Ventmembrane

5Label

Maskingthebottomchassis

Maskthefollowingpartsofthebottomchassis:

1.TheIlluminatorfrontglass.

2.Everythingonthetopsideofthebottomchassis,includingthegasketandthefourscrewholes.

3.Thesurfaceundertheadapterforthewallmount.

4.Theproductlabel.

5.Thefourscrewholes.

1Illuminatorfrontglass

2Topside

3allmountsurface

4Label

Maskingtheweathershield

Masktheblackpartoftheweathershield.

AXISQ1656-LEBoxCamera

Repainttheprouct

1Black

Maskingthewallmountbracket

Maskthefollowingparts:

1.Thefourscrewholes

2.Theballjoint.

3.Thesocketteeth.

4.Theslotforthesuarenut.

1Screwhole(4x)

2Balljoint

3Socketteeth

4Slot

Repainting

1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

AXISQ1656-LEBoxCamera

Repainttheprouct

2.Letthepaintdry.

3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

4.Whenthepaintisdry,removethemaskingandreassembletheproduct.

Reassembly

Reassembletheproduct.

Formoreinformation,seetheInstallationGuideavailableataxis.com

RepaintingInstructionsVer.M1.8

AXISQ1656-LEBoxCameraDate:December2021

©AxisCommunicationsAB,2021PartNo.T10174266
