Axis P3827-PVE Manual de usuario

AXISP38PanoramicCameraSeries

AXISP3818-PVEPanoramicCamera

AXISP3827-PVEPanoramicCamera

Repaintinginstructions

AXISP38PanoramicCameraSeries

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

AXISP38PanoramicCameraSeries

Repainttheproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartsthatwillberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Thematerialusedinthedomecoverispowder-coatedaluminum.ThematerialusedintheweathershieldisASALuranS797SEUV.

AXISP38PanoramicCameraSeries

Repainttheproduct

isassembly

1Weathershield

2Screws(2x,TR20)

Screws(4x,TR20)

4Dome

5Domecover

6Cameraunit

AXISP38PanoramicCameraSeries

Repainttheproduct

7Springclip

8Springholder

9Mountingbracket

10Lid

1.Removetheweathershield,ifit’salreadyattachedtothedomecover.

2.Removethedome.

3.Removethecameraunitbypressingthetwospringholders.

4.Removethespringclipandthelid.

5.Removethedomefromthedomecoverbypressingthetwospringholders.

Repainting

1.Makesureallnecessarypreparationsofthepartstobepaintedhavebeenmade,seePreparationsonpage.

AXISP38PanoramicCameraSeries

Repainttheproduct

2.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

3.Letthepaintdry.

4.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

5.Whenthepaintisdry,removethemaskingandreassembletheproduct.

Reassembly

1.Reassemblethedomeandthedomecover.

2.Reattachthespringclipandthelid.

3.Reattachthecameraunit.

4.Reassemblethedomeandtheweathershieldandtightenthescrews(torue1.0Nm,0.7lbft).

RepaintinginstructionsVer.M2.2

AXISP38PanoramicCameraSeriesDate:August2023

©AxisCommunicationsAB,2022-2023Partno.T10185395
