Avtech DGC5645 Manual de usuario

890Z

d5105_5645_V0.9

5MP IR Bullet Camera User Manual

Please use this camera with a DVR which supports HD video recording.

Please read the instructions thoroughly before using the product.

To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.

Only operate this apparatus from the type of power source indicated on the label.

The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of

such damages.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence

of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

This exclamation point within an equilateral triangle is intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the literature accompanying the appliance.

ROHS Announcement

All lead-free products offered by the company comply with the requirements of the European law on the Restriction

of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly

“lead-free” and without the hazardous substances cited in the directive.

The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected

separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do

not dispose of these products as unsorted municipal waste.

CE Mark

This apparatus is manufactured to comply with the radio interference.

The company does not warrant that this manual will be uninterrupted or error-free. We reserve the right to revise or

remove any content in this manual at any time.

FEATURES

1. 1/2.5” CMOS Sensor with up to 5MP video output

2. Low light sensitivity

3. Quadbrid video output with TVI, CVI, AHD & CVBS

4. DWDR to increase image recognizability in overexposure and dark areas

5. Day and night 24-hour surveillance with IR effective distance up to 50 meters

6. IP66 for weather-proof application

7. Camera parameters adjustable when used with HD CCTV DVR

PACKAGE CONTENT

IR camera User manual Wrench Screws & wall plugs

SPECIFICATIONS*

Model 1 Model 2

Video Mode TVI, CVI, AHD & CVBS** switchable

Pick-up Element 1/2.5 " CMOS image sensor

Number of Pixels 2560 (H) x 1920 (V)

Video Frame Rate 5MP@ 20fps

Min. Illumination 0.1 Lux / F1.8, 0 Lux (IR LED ON) 0.1 Lux / F1.4(Wide)~F2.8(Tele),

0 Lux (IR LED ON)

S/N Ratio More than 48dB (AGC OFF)

Shutter Speed AUTO : 1/25(30) sec~1/50,000 sec

Lens f3.6mm / F1.8 motorized f2.8 ~ 12mm / F1.4 ~ F2.8

Lens Angle 96° (Horizontal) / 50° (Vertical) /

116° (Diagonal)

Wide:

113.5° (Horizontal) / 59.3° (Vertical) /

137° (Diagonal)

Tele:

33.4° (Horizontal) / 18.7° (Vertical) /

38.2° (Diagonal)

IR LED 2 units 4 units

IR Effective Distance Up to 50 meters

IR Shift YES

Day & Night Mode YES

Noise Reduction YES

IRIS Mode AES

White Balance AUTO

AGC AUTO

Sharpness Adjustable

Flickerless 50HZ / 60HZ / OFF

BLC Adjustable

DWDR YES

IP Rating IP66

Operating Temperature -20℃~ 40℃

Operating Humidity 90% or less relative humidity

Power Source (±10%) DC12V / 1A DC12V / 1A

Current Consumption (±10%) 100mA (IR lED OFF);

250mA (IR LED ON) --

Net Weight (kg) 0.36 0.94

Optional Peripherals Junction Box (AVA456-WBKT / AVA456-WHKT)

* The specifications are subject to change without notice.

** The camera can’t be accessed to change configurations in the CVBS mode.

DIMENSIONS*

Model 1

Model 2

*Dimensional Tolerance: ± 5mm

INSTALLATION

Model 1

Step1: Find the wrench supplied in the sales package, and loosen the screw as indicated below to loosen

the joint lock of the bracket.

Note: for lock, and for unlock.

Step2: Locate where to install this camera, and fasten the bracket to the ceiling or wall.

Then, adjust the viewing angle of the camera, and fasten the screw to secure the joint lock of the

bracket.

Note: for lock, and for unlock.

Model 2

Step 1: Loosen the screw as indicated below to move down the camera lens.

Then, fasten the camera to the ceiling or wall where you want to install.

1. loosen a bit

2. Move down a bit

Step 2: Adjust the viewing angle of the camera as indicated below.

Vertical Rotate Horizontal

Step 3: Power on the camera and fine-tune the viewing angle.

For details, please refer to the section, "FOCAL LENGTH & FOCUS ADJUSTMENT".

CONNECTION

1. DC12V Input Terminal

Connect the power terminal of the camera to a DC 12V regulated power supply.

Note: Please use the correct power adaptor, DC12V (regulated), to operate this unit. The power

tolerance of this unit is DC12V ± 10%. Over maximum DC 12V power input will damage this

unit.

2. Video Output Connector (VIDEO OUT)

Connect the camera video output to the video input of a DVR with 75Ωcoaxial cable.

Note: To ensure the camera has sufficient protection against moisture, an extra waterproof

measure, such as by using an insulating tape, must be used to cover the power and video

connectors after connection.

FOCAL LENGTH & FOCUS ADJUSTMENT

This function is available for Model 2 only.

Note: The access path is taking our HD CCTV recorder as an example. If you’re using other brand’s recorder,

please refer to its own user manual to know how to access the camera parameters.

Based on the recorder type you have, on the live view:

Type 1

Click twice on the channel that this camera is connected to show in full screen, and click on on the

right side to display the PTZ control panel.

Type 2

Click twice on the channel that this camera is connected to show in full screen, and click on on the

bottom left of the channel to show the PTZ control panel.

How to adjust

＋/ －Zoom in / out max Click to zoom in on the image to the largest / zoom out on the image to its

original size.

/ Zoom in / out Click to zoom in / out the image.

/ Focus near / far Click to adjust the focus of the image.

CAMERA PARAMETERS

This camera series has its own configuration menu.

Note: The camera can’t be accessed to change configurations when the video mode is switched to CVBS.

Note: The access path is taking our HD CCTV recorder as an example. If you’re using other brand’s recorder,

please refer to its own user manual to know how to access the camera parameters.

Based on the recorder type you have, on the live view:

Type 1

Click twice on the channel that this camera is connected to show in full screen, and click on on the

right side to display the PTZ control panel.

Then, click on (Enter) on the PTZ control panel to show the configuration menu of this camera, and

use the arrow keypad to choose between each option.

hen the camera menu is entered, use keypad to move between and

change those configurations.

▲▼ Move between selections.

◄► Change settings.

Call the camera parameters menu or enter the

currently-selected item.

Type 2

Click twice on the channel that this camera is connected to show in full screen, and click on on the

bottom left of the channel to show the PTZ control panel.

Then, click on (Enter) on the PTZ control panel to show the configuration menu of this camera, and

use the arrow keypad to choose between each option.

/ Move among sub-menus.

/ Change settings.

Call the camera parameters menu or enter the currently-selected item.

MENU REMARK

FORMAT Choose the video resolution and

IPS of this camera in different

video output mode.

VIDEO MODE TVI / AHD / CVI / CVBS

MAIN-MENU AE BRIGHTNESS 1 ~ 10

EXPOSURE MODE GLOBAL

BLC Manually adjust the level of BLC

from 0 ~ 8. The higher the value,

the brighter the whole image.

GAIN HIGH / MIDDLE / LOW

WDR OFF / ON Digital WDR

AWB MODE ATW

MWB Manually adjust the white balance

parameters by modifying R / B gain

parameters.

DAY - NIGHT MODE EXT Use the external light sensor we

added in the camera to detect the

surrounding light condition and

switch to color or B/W mode.

AUTO

COLOR

B/W

VIDEO SETTING CONTRAST 1 ~ 10

SHARPNESS 1 ~ 10

COLOR GAIN 1 ~ 10

NR 1 ~ 10

MIRROR DEFAULT

H Horizontal

V Vertical

HV Horizontal & vertical

RESET

EXIT Exit the menu without saving

SAVE-EXIT Save the changes and exit the

menu.
