Avision FL-1207H Manual de usuario

Sheet-fed Scanner

Getting Started Guide

Regulatory model: FL-1207H/FL-1213H

Avision Inc.

English

Getting Started

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows, and Windows Vista are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or

other countries.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

Getting Started

iii

Table of Contents

1. Introduction ..................................................... 1-1

2. Scanner Installation ......................................... 2-1

2.1 Installing the ADF Paper Tray........................ 2-1

2.2 Installing the ADF Output Paper Tray ............. 2-2

2.3 Installing the Scanner Driver and Connecting

the Cables .................................................. 2-3

2.3.1 Connecting to Power......................... 2-3

2.3.2 Turning on the Power ....................... 2-3

2.3.3 Installing the Scanner Driver ............. 2-4

2.3.4 Connecting to Computer ................... 2-6

3. Completing Your First Scan .............................. 3-1

3.1 Loading Your Paper...................................... 3-1

3.1.1 Notice on Using the ADF ................... 3-1

3.1.2 Loading Your Document in the ADF

Paper Tray ...................................... 3-2

3.1.3 Loading Your Cards in the ADF Paper

Tray ............................................... 3-4

3.2 Verifying Your Scanner Installation ................ 3-5

3.3 A Glance of the Scanner Properties Dialog Box 3-9

4. ISIS Interface Operation.................................. 4-1

5. Using the Buttons............................................. 5-1

5.1 Installing Button Manager V2 ........................ 5-1

5.2 Checking the Button Configurations Before

Scanning.................................................... 5-2

5.3 Scanning From One Touch of the Buttons ....... 5-4

6. Maintenance..................................................... 6-1

6.1 Cleaning the ADF ........................................ 6-1

6.2 Cleaning the Calibration Area........................ 6-3

7. Troubleshooting ............................................... 7-1

7.1 Clearing a Paper Jam ................................... 7-1

8. Specifications...................................................... a

Getting Started

1-1

1. Introduction

Congratulations on your purchase of the color sheet-fed

image scanner. With this scanner, you can scan multi-page

documents from the auto document feeder to increase your

productivity.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

Getting Started

1-2

1. Scanner Main Unit

2. ADF Paper Tray

3. ADF Output Paper Tray

4. Software CD/Quick Guide

5. USB Cable

6. Power Adapter & Power Cord

Note:

1. Only use the AC adapter DA-48M24 by APD included in the

machine. Using other AC adapters may damage the

machine and void the warranty.

2. Please unpack the packing carefully, and check the contents

against the checklist. If any items are missing or damaged,

please contact your dealer immediately.

Getting Started

2-1

2. Scanner Installation

2.1 Installing the ADF Paper Tray

Hold the ADF Paper Tray and insert two pins to the holes on

the top of the scanner as shown.

ADF

Paper

Tray

Getting Started

2-2

2.2 Installing the ADF Output Paper Tray

1. Insert the left pin of the Output Paper Tray to the lower-left

hole on the front of the scanner.

2. Gently press the right hook of the Output Paper Tray and

then insert the right pin to the lower-right hole on the front

of the scanner as indicated.

Note:

To remove the output paper tray, please first press the right

pin of the output tray. Then detach the output tray from the

scanner.

Output

Paper Tray

Getting Started

2-3

2.3 Installing the Scanner Driver and Connecting the

Cables

2.3.1 Connecting to Power

Before connecting, make sure the power switch is off.

Plug the small end of the power adaptor into the power jack of

your scanner. Insert the other end to an appropriate power

outlet.

2.3.2 Turning on the Power

Press the Power Switch button on the front panel, the Power

LED will flash. When it is finished and ready to scan, the

LED indicator will stop flashing and become steadily on. To

turn off the scanner, press the Power Switch button for

about 3 seconds, the Power LED will be off.

Getting Started

2-4

2.3.3 Installing the Scanner Driver

NOTE:

1. The Windows system CD may be required when installing

on some PC’s.

2. To ensure your computer can identify the USB scanner,

please install scanner driver first before connecting the

scanner to your computer.

3. The scanner driver contains TWAIN, ISIS and WIA driver.

If you are running Windows Me, Windows XP, or Windows

Vista, after the installation of scanner driver is completed,

this scanner allows you to scan via a TWAIN, ISIS, or a

WIA interface. Start your TWAIN-compliant image editing

software application to select a TWAIN or WIA user

interface or your ISIS software to select an ISIS user

interface. You may also launch Microsoft’s Scanner and

Camera Wizard to scan via a WIA user interface.

1. Place the supplied CD-ROM onto your CD-ROM drive.

2. The software installation graphic appears. If not, run

“setup.exe”.
