Avision FL-1006S Manual de usuario

Sheet-Fed Color Image Scanner

User’s Manual

Regulatory model: FL-1006S/FL-1011S

manual-en-250-0811-E-176U&175+-v2

Avision Inc.

User’s Manual

Trademarks

Microsoft is a U.S. registered trademark of Microsoft Corporation.

Windows, Windows Vista, Windows 7 and Windows 8 are either

registered trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied

warranties of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

User’s Manual

iii

FCC Radio Frequency Interference Statement

This product has been tested and found to comply with

the limits for a class B digital device, pursuant to Part 15

of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that may

cause undesired operation. The FCC Class B limits are

designed to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or

television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

Consult your point of purchase or service

representative for additional suggestions.

User’s Manual

European Union Regulatory Notice

Products bearing the CE marking comply with the following EU

Directives:

Low Voltage Directive 2006/95/EC

EMC Directive 2004/108/EC

Restriction of the use of certain hazardous substances

(RoHS) Directive 2011/65/EU

CE compliance of this product is valid if powered with the

correct CE-marked AC adapter provided by Avision.

This product satisfies the Class B limits of EN55022, EN55024,

safety requirements of EN60950 and ROHS requirements of

EN50581.

*This machine is certified as Class 1 LED product.

User’s Manual

Disposal of Waste Equipment by Users in Private Union

This symbol on the product or on its packaging indicates that

the product can not be disposed of with your other household

waste. Instead it should be sent to appropriate facilities for

recovery and recycling in an effort to protect human health

and the environment. Fore more information about where you

can drop off your waste equipment for recycling, please

contact your local city office, your household waste disposal

service or the shop where you purchased the product.

As an ENERGY STAR®Partner, Avision Inc. has

determined that this product meets the ENERGY

STAR guidelines for energy efficiency.

System Requirements

IBM compatible PC 586, Pentium or higher

Microsoft Windows XP(SP3), Windows Vista/Windows

7/Windows 8

USB port 2.0 (compatible with USB 1.1)

At least 100 MB of free hard disk space (500 MB is

recommended)

At least 128 MB of system memory (512 MB of RAM is

recommended)

At least 1 GB of RAM for Windows Vista/Windows 8

A CD-ROM drive

User’s Manual

Table of Contents

1. Introduction ..............................................1-1

2. Scanner Installation ..................................2-1

2.1 Installing the Scanner Driver and Connecting

the Cables .................................................. 2-2

2.1.1 Connecting to Power ......................... 2-2

2.1.2 Turning on the Power........................ 2-3

2.1.3 Installing the Scanner Driver ............. 2-3

2.1.4 Connecting to Computer.................... 2-5

3. Completing Your First Scan .......................3-1

3.1 Loading Your Paper ...................................... 3-1

3.1.1 Notice on Using the ADF.................... 3-1

3.1.2 Loading Your Document in the ADF

Paper Tray....................................... 3-2

3.1.3 Loading Your Cards in the ADF Paper Tray3-4

3.2 Verifying Your Scanner Installation ................ 3-5

3.3 A Glance of the Scanner Properties Dialog Box 3-9

4. Using the Scanner Properties Dialog Box ..4-1

4.1 Buttons on the Scanner Properties Dialog Box . 4-2

4.2 The Image Tab ............................................ 4-4

4.2.1 The Image Selection Box ................... 4-5

4.2.2 Other Image Options ........................ 4-8

4.2.3 Scanning color images .................... 4-20

4.2.4 Scanning grayscale images.............. 4-20

4.2.5 Scanning B&W images .................... 4-20

4.2.6 Editing Profiles ............................... 4-21

4.3 The Compression Tab................................. 4-24

4.4 The Color Dropout Tab ............................... 4-26

4.4.1 Color Dropout Selection .................. 4-26

4.4.2 Other Color Dropout Options............ 4-28

4.5 The Paper Tab ........................................... 4-30

4.5.1 Cropping ....................................... 4-31

4.5.2 Other Paper Selection ..................... 4-36

User’s Manual

vii

4.6 The Multi-Feed Detection Tab ...................... 4-39

4.7 The Preview Tab ........................................ 4-47

4.8 The Options Tab ........................................ 4-48

4.9 The Setting Tab......................................... 4-57

4.10 The Imprinter Tab .................................. 4-60

4.11 The Information Tab............................... 4-64

5. ISIS Interface Operation...........................5-1

6. Using the Buttons......................................6-1

6.1 Installing Button Manager V2 ........................ 6-1

6.2 Checking the Button Configurations before

Scanning .................................................... 6-2

6.3 Using Button Manager V2 with Default

Function Numbers and Predefined Tasks......... 6-4

6.4 Scanning From One Touch of the Buttons ....... 6-8

7. Maintenance ..............................................7-1

7.1 Cleaning the ADF......................................... 7-1

7.2 Cleaning the Calibration Area ........................ 7-3

7.3 Replacing the Snap-in Pad Module ................. 7-4

7.4 Replacing the ADF Roller .............................. 7-5

8. Troubleshooting ........................................8-1

8.1 Clearing a Paper Jam ................................... 8-1

8.2 Questions and Answers ................................ 8-2

8.3 Technical Service......................................... 8-4

9. Specifications ............................................9-1

Index................................................................... a

User’s Manual

1-1

1. Introduction

Congratulations on your purchase of the color sheet-fed

image scanner. With this scanner, you can scan multi-page

documents from the auto document feeder to increase your

productivity.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

1. Scanner Main Unit

2. Software CD/Quick Guide

3. USB Cable

4. Power Adapter & Power Cord

User’s Manual

1-2

Note:

1. Only use the AC adapter DA-24C24 by APD included in the

machine. Using other AC adapters may damage the

machine and void the warranty.

2. Please unpack the packing carefully, and check the

contents against the checklist. If any items are missing or

damaged, please contact your dealer immediately.
